RX-7010RBK/RX-7012RSL
3-13
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 03
A
Item
Parts number Parts name Area
Remarks
A
IC427 BA15218F-XE IC
IC428 M62446FP-X IC
IC701 MN101C35DHK1 IC
IC702 IC-PST9139-T IC
IC703 GP1U281X IC
J 404 QNN0389-001 PIN JACK DVD-FL/FR
J 405 QNN0388-001 PIN JACK
J 406 QNN0060-001 PIN JACK SW OUT
JS701 QSW0898-001 JOG VOLUME
701 DTC114YKA-X D TRANSISTOR
702 DTC114TKA-X TRANSISTOR
703 DTC144WKA-X TRANSISTOR
704 DTC114YKA-X D TRANSISTOR
707 DTC114YKA-X D TRANSISTOR
708 DTC114YKA-X D TRANSISTOR
709 DTC114YKA-X D TRANSISTOR
711 DTA144EKA-X TRANSISTOR
1401 KTA1046/Y/ TRANSISTOR
A
1402 2SD2395/EF/ TRANSISTOR
A
1403 2SD2395/EF/ TRANSISTOR
A
1404 2SD2395/EF/ TRANSISTOR
A
1405 2SD2395/EF/ TRANSISTOR
A
1406 KTC3203/OY/-T TRANSISTOR
A
1407 KTC3203/OY/-T TRANSISTOR
A
1408 KTA1271/OY/-T TRANSISTOR
A
1409 2SK301/PQ/-T TRANSISTOR(FET)
1410 2SK301/PQ/-T TRANSISTOR(FET)
1411 2SK301/PQ/-T TRANSISTOR(FET)
1412 2SK301/PQ/-T TRANSISTOR(FET)
1413 2SC3576-JVC-T TRANSISTOR
1414 2SC3576-JVC-T TRANSISTOR
1415 KRA104M-T D TRANSISTOR
1416 KRC104M-T D TRANSISTOR
1417 2SC3576-JVC-T TRANSISTOR
1418 2SC3576-JVC-T TRANSISTOR
1419 2SC3576-JVC-T TRANSISTOR
1420 KRA104M-T D TRANSISTOR
1421 2SC3576-JVC-T TRANSISTOR
1422 2SC3576-JVC-T TRANSISTOR
1423 KRA104M-T D TRANSISTOR
1424 KRA104M-T D TRANSISTOR
1425 2SC3576-JVC-T TRANSISTOR
1426 2SC3576-JVC-T TRANSISTOR
1431 KRC104M-T D TRANSISTOR
1432 KRC104M-T D TRANSISTOR
1433 KRC104M-T D TRANSISTOR
1434 2SD2395/EF/ TRANSISTOR
A
1435 2SD2395/EF/ TRANSISTOR
A
R 451 NRSA63J-471X MG RESISTOR
R 452 NRSA63J-471X MG RESISTOR
R 453 NRSA63J-471X MG RESISTOR
R 454 NRSA63J-471X MG RESISTOR
R 455 NRSA63J-471X MG RESISTOR
R 456 NRSA63J-471X MG RESISTOR
R 475 NRSA63J-203X MG RESISTOR
R 476 NRSA63J-273X MG RESISTOR
R 477 QRZ9006-4R7X F RESISTOR
A
4.7 1/0W
R 478 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R 479 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R 480 NRSA63J-153X MG RESISTOR
R 483 NRSA63J-102X MG RESISTOR
R 484 NRSA63J-104X MG RESISTOR
R 485 NRSA63J-102X MG RESISTOR
R 486 NRSA63J-104X MG RESISTOR
R 487 NRSA63J-102X MG RESISTOR
R 488 NRSA63J-104X MG RESISTOR
R 489 NRSA63J-562X MG RESISTOR
R 490 NRSA63J-562X MG RESISTOR
R 491 NRSA63J-153X MG RESISTOR
R 492 NRSA63J-0R0X MG RESISTOR
R 493 NRSA63J-0R0X MG RESISTOR
R 494 NRSA63J-0R0X MG RESISTOR
R 495 NRSA63J-0R0X MG RESISTOR
R 701 NRSA63J-472X MG RESISTOR
R 702 NRSA63J-223X MG RESISTOR
R 703 NRSA63J-103X MG RESISTOR
R 704 NRSA63J-471X MG RESISTOR
R 705 NRSA63J-103X MG RESISTOR
R 706 NRSA63J-103X MG RESISTOR
R 707 NRSA63J-103X MG RESISTOR
R 708 NRSA63J-103X MG RESISTOR
R 709 NRSA63J-103X MG RESISTOR
R 710 NRSA63J-103X MG RESISTOR
R 711 NRSA63J-104X MG RESISTOR
R 712 NRSA63J-103X MG RESISTOR
R 713 NRSA63J-103X MG RESISTOR
R 714 NRSA63J-103X MG RESISTOR
R 715 NRSA63J-103X MG RESISTOR
R 716 NRSA63J-103X MG RESISTOR
R 717 NRSA63J-103X MG RESISTOR
R 718 NRSA63J-103X MG RESISTOR
R 719 NRSA63J-221X MG RESISTOR
R 720 NRSA63J-222X MG RESISTOR
R 721 NRSA63J-103X MG RESISTOR
R 722 NRSA63J-102X MG RESISTOR
R 723 NRSA63J-102X MG RESISTOR
R 724 NRSA63J-122X MG RESISTOR
R 725 NRSA63J-152X MG RESISTOR
R 726 NRSA63J-222X MG RESISTOR
R 727 NRSA63J-272X MG RESISTOR
R 728 NRSA63J-103X MG RESISTOR
R 729 NRSA63J-102X MG RESISTOR
R 730 NRSA63J-102X MG RESISTOR
R 731 NRSA63J-122X MG RESISTOR
R 732 NRSA63J-152X MG RESISTOR
R 733 NRSA63J-222X MG RESISTOR
R 734 NRSA63J-272X MG RESISTOR
R 735 NRSA63J-392X MG RESISTOR
R 736 NRSA63J-103X MG RESISTOR
R 737 NRSA63J-102X MG RESISTOR
R 738 NRSA63J-102X MG RESISTOR
R 739 NRSA63J-122X MG RESISTOR
R 740 NRSA63J-152X MG RESISTOR
R 741 NRSA63J-222X MG RESISTOR
R 742 NRSA63J-272X MG RESISTOR
R 743 NRSA63J-103X MG RESISTOR
R 744 NRSA63J-102X MG RESISTOR
R 745 NRSA63J-102X MG RESISTOR
R 746 NRSA63J-122X MG RESISTOR
R 747 NRSA63J-152X MG RESISTOR
R 748 NRSA63J-222X MG RESISTOR
R 749 NRSA63J-272X MG RESISTOR
R 750 NRSA63J-103X MG RESISTOR
R 751 NRSA63J-102X MG RESISTOR
R 752 NRSA63J-102X MG RESISTOR
R 753 NRSA63J-122X MG RESISTOR
(System control & Audio board)
