JVC RX-7032VSL Service Manual

3-12
Input board
Block No. [0][5][0][0]
R1894 QRE141J-183Y C RESISTOR 18k Ω 1/4W J
R1895 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R1896 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R1901 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R1902 QRE141J-683Y C RESISTOR 68k Ω 1/4W J
R1903 QRE141J-202Y C RESISTOR 2k
Ω 1/4W J
R1905 QRE141J-123Y C RESISTOR 12k
Ω 1/4W J
R1911 QRE141J-331Y C RESISTOR 330 Ω 1/4W J
R1912 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
R1921 QRJ146J-221X UNF C RESISTOR 220 Ω 1/4W J
R1922 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1923 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1924 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1925 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R1931 QRE141J-911Y C RESISTOR 910 Ω 1/4W J
R1932 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R1933 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R1941 QRJ146J-221X UNF C RESISTOR 220 Ω 1/4W J
R1951 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R1952 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R1953 QRZ0218-R22 EMIT RESISTOR 0.22
Ω
R1961 QRJ125J-330 UNF C RESISTOR 33 Ω 1/2W J
R1962 QRL027J-100 OMF RESISTOR 10 Ω 2W J
R1971 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R1972 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R1973 QRE141J-201Y C RESISTOR 200 Ω 1/4W J
R1991 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R1993 QRE141J-183Y C RESISTOR 18k Ω 1/4W J
R1994 QRE141J-201Y C RESISTOR 200 Ω 1/4W J
R1995 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
VR787 QVP0008-501Z TRIM RESISTOR 500 Ω
VR788 QVP0008-501Z TRIM RESISTOR 500 Ω
L791 QQLZ003-1R0 COIL 1uH
L792 QQLZ003-1R0 COIL 1uH
L1761 QQLZ005-R45 COIL 0.45uH
L1861 QQLZ005-R45 COIL 0.45uH
L1862 QQLZ005-R45 COIL 0.45uH
L1961 QQLZ005-R45 COIL 0.45uH
CN711 QGB2510K1-12 CONNECTOR B-B (1-12)
CN712 QGB2510K1-12 CONNECTOR B-B (1-12)
CN713 QGB2510K1-10 CONNECTOR B-B (1-10)
CN714 QGA2501F1-02 CONNECTOR W-B (1-2)
CN715 QGB2510K1-12 CONNECTOR B-B (1-12)
CN716 QGB2510K1-12 CONNECTOR B-B (1-12)
CN717 QGA2001F1-03 CONNECTOR W-B (1-3)
CN718 QGB2510K1-10 CONNECTOR B-B (1-10)
CN719 QGA2501F1-03 CONNECTOR W-B (1-3)
CN722 QGA2001F1-02 CONNECTOR W-B (1-2)
TH731 QAD0012-202 THERMISTOR 2k
Ω L
TH783 QAD0012-202 THERMISTOR 2k
Ω L
TH784 QAD0012-202 THERMISTOR 2k
Ω L
TH831 QAD0012-202 THERMISTOR 2k Ω L
TH832 QAD0012-202 THERMISTOR 2k
Ω L
TH901 QAD0012-202 THERMISTOR 2k
Ω L
 Symbol No. Part No. Part Name Description Local
IC304 HA17558AF-X IC Ope. amp.
IC380 TC9162AF-X IC
IC381 TC9459F-X IC
IC382 TC9459F-X IC
IC383 TC9459F-X IC
IC384 TC9459F-X IC
IC386 HA17558AF-X IC Ope. amp.
IC397 HA17558AF-X IC Ope. amp.
IC399 HA17558AF-X IC Ope. amp.
Q1310 KRA104S-X DIGI TRANSISTOR
Q1313 2SC3576-JVC-T TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q1314 2SC3576-JVC-T TRANSISTOR
Q1324 2SC3576-JVC-T TRANSISTOR
Q1333 2SC3576-JVC-T TRANSISTOR
Q1334 2SC3576-JVC-T TRANSISTOR
Q1441 2SC3576-JVC-T TRANSISTOR
Q1445 2SC3576-JVC-T TRANSISTOR
Q1447 KRA104S-X DIGI TRANSISTOR
Q1490 KRA104S-X DIGI TRANSISTOR
Q1491 2SC3576-JVC-T TRANSISTOR
Q1492 2SC3576-JVC-T TRANSISTOR
C333 NCS31HJ-681X C CAPACITOR 680pF 50V J
C334 NCS31HJ-681X C CAPACITOR 680pF 50V J
C361 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C362 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C363 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C364 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1301 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1302 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1303 NCB31HK-221X C CAPACITOR 220pF 50V K
C1309 QENC1HM-106Z BP E CAPACITOR 10uF 50V M
C1310 QETN1CM-226Z E CAPACITOR 22uF 16V M
C1311 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1312 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1313 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1314 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1315 QER61HM-224Z E CAPACITOR 0.22uF 50V M
C1316 QER61HM-224Z E CAPACITOR 0.22uF 50V M
C1319 NCB31HK-221X C CAPACITOR 220pF 50V K
C1321 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1322 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1323 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1324 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1325 QER61HM-224Z E CAPACITOR 0.22uF 50V M
C1326 QER61HM-224Z E CAPACITOR 0.22uF 50V M
C1329 NCB31HK-221X C CAPACITOR 220pF 50V K
C1331 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1332 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1333 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1334 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1339 NCB31HK-221X C CAPACITOR 220pF 50V K
C1341 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1343 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1344 QETN1CM-226Z E CAPACITOR 22uF 16V M
C1349 NCB31HK-221X C CAPACITOR 220pF 50V K
C1350 NCB31HK-221X C CAPACITOR 220pF 50V K
C1360 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C1361 NCB31HK-681X C CAPACITOR 680pF 50V K
C1362 NCB31HK-681X C CAPACITOR 680pF 50V K
C1363 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1364 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1365 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1366 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1367 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C1431 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1433 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1439 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1440 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1471 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1474 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1494 NCB31HK-331X C CAPACITOR 330pF 50V K
R333 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R334 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R361 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R362 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R363 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R364 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R365 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R366 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1301 QRZ9005-680X F RESISTOR 68
Ω
R1302 QRZ9005-680X F RESISTOR 68 Ω
R1303 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R1304 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R1305 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1306 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1307 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R1308 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
