JVC RX-7032VSL Service Manual

3-13
DSP board
Block No. [0][6][0][0]
R1309 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R1310 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1311 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1312 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1313 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1314 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1315 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1316 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1321 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1322 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1324 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1326 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1331 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1332 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1333 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1334 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1335 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1336 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1341 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1342 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1343 NRSA63J-474X MG RESISTOR 470k
Ω 1/16W J
R1350 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R1351 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1361 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1362 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R1362 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R1363 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1364 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1365 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1366 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1367 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1368 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1369 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1370 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1431 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1432 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1433 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R1434 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R1435 NRSA63J-912X MG RESISTOR 9.1k Ω 1/16W J
R1436 NRSA63J-512X MG RESISTOR 5.1k Ω 1/16W J
R1437 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1439 QRZ9005-680X F RESISTOR 68 Ω
R1440 QRZ9005-680X F RESISTOR 68 Ω
R1441 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1443 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1445 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1446 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1447 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R1471 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1472 NRSA63J-511X MG RESISTOR 510
Ω 1/16W J
R1473 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R1474 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1475 NRSA63J-512X MG RESISTOR 5.1k
Ω 1/16W J
R1476 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1478 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R1486 NRSA63J-511X MG RESISTOR 510
Ω 1/16W J
R1487 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1490 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1505 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
CN205 QGB1214J1-10S CONNECTOR B-B (1-10)
CN361 QGB1214J1-06S CONNECTOR B-B (1-6)
CN381 QGB1214J1-18S CONNECTOR B-B (1-18)
CN501 QGB1214J1-14S CONNECTOR B-B (1-14)
CN731 QJP002-021901 SHI CR C-B WIRE
CN732 QJP001-031701 SHI CR C-B WIRE
CN733 QJP017-021701 SHI CR C-B WIRE
CN734 WJP0047-001A E-SH C WIRE C-B
CN735 QJP007-031301 CONNECTOR
J1350 QNS0089-001 3.5 JACK
J1360 QNN0548-001 4PIN JACK ASSY
J1490 QNN0284-001 PIN JACK
J1491 QNN0284-001 PIN JACK
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
IC501 DSPD56367PV150 IC DSP
IC502 NC7SU04P5-X IC(DIGITAL) Invereter
IC503 NC7S04P5-X IC(DIGITAL) Invereter
IC505 PQ070XZ1HZ-X IC Regulator
IC506 MM1563DF-X IC Regulator
IC507 PQ20VZ11-X IC
IC511 39VF0207CWHR01 IC EEPROM
IC512 IC63LV102410K-X IC CMOS SRAM
IC513 IC63LV102410K-X IC CMOS SRAM
IC514 IC63LV102410K-X IC CMOS SRAM
IC520 HA17558AF-X IC Ope. amp.
IC521 HA17558AF-X IC Ope. amp.
IC522 HA17558AF-X IC Ope. amp.
IC523 HA17558AF-X IC Ope. amp.
IC524 HA17558AF-X IC Ope. amp.
IC525 HA17558AF-X IC Ope. amp.
IC526 HA17558AF-X IC Ope. amp.
IC527 NJM2121M-X IC Op amp.
IC528 HA17558AF-X IC Ope. amp.
IC529 HA17558AF-X IC Ope. amp.
IC530 HA17558AF-X IC Ope. amp.
IC551 AK4112BVF-X IC(MICRO C ROM)
IC561 MN35505-X IC DAC
IC571 AK4527BVQP IC A/D D/A converter
IC572 NC7WZ125K8-X IC
Dual buffer with 3-
state outputs
IC573 NC7SZ74K8-X IC Clock buffer
IC581 UPD784215AGC196 IC CPU
IC582 NC7ST32P5-X IC(DIGITAL) 2-Input OR Gate
IC583 MM1563DF-X IC Regulator
Q570 DTC114YE-X TRANSISTOR
Q572 DTC114YE-X TRANSISTOR
Q2101 2SD2114K/VW/-X TRANSISTOR
Q2131 2SD2114K/VW/-X TRANSISTOR
Q2151 DTA114YE-X TRANSISTOR
Q2152 DTC114YE-X TRANSISTOR
Q2154 DTA114YE-X TRANSISTOR
Q2155 DTA114YE-X TRANSISTOR
Q2156 DTA114YE-X TRANSISTOR
Q2157 DTA114YE-X TRANSISTOR
Q2158 DTA114YE-X TRANSISTOR
Q2201 2SD2114K/VW/-X TRANSISTOR
Q2202 2SD2114K/VW/-X TRANSISTOR
Q2273 2SC2412K/RS/-X TRANSISTOR
Q2274 2SC2412K/RS/-X TRANSISTOR
Q2301 2SD2114K/VW/-X TRANSISTOR
Q2302 2SD2114K/VW/-X TRANSISTOR
Q2363 2SD2114K/VW/-X TRANSISTOR
Q2364 2SD2114K/VW/-X TRANSISTOR
Q2375 2SC2412K/RS/-X TRANSISTOR
Q2376 2SC2412K/RS/-X TRANSISTOR
Q2401 2SD2114K/VW/-X TRANSISTOR
Q2431 2SC2412K/RS/-X TRANSISTOR
Q2801 2SD2114K/VW/-X TRANSISTOR
C571 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C572 NEA70GM-107X E CAPACITOR 100uF 4V M
C573 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C577 NCS31HJ-101X C CAPACITOR 100pF 50V J
C579 NCS31HJ-101X C CAPACITOR 100pF 50V J
C581 NEA71CM-106X E CAPACITOR 10uF 16V M
C582 NEA71CM-106X E CAPACITOR 10uF 16V M
C583 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C584 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C587 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C588 NEA70JM-227X E CAPACITOR 220uF 6.3V M
C589 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C590 NEA70GM-107X E CAPACITOR 100uF 4V M
C591 NCS31HJ-471X C CAPACITOR 470pF 50V J
C2001 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2002 NEA71EM-475X E CAPACITOR 4.7uF 25V M
C2003 NCB31HK-122X C CAPACITOR 1200pF 50V K
C2004 NCB31HK-122X C CAPACITOR 1200pF 50V K
