JVC RX-8010RBK

RX-8010RBK/RX-8012RSL
3-14
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 04
A
Item
Parts number Parts name Area
Remarks
A
R 211 NRSA63J-473X MG RESISTOR
R 212 NRSA63J-331X MG RESISTOR
R 213 NRSA63J-473X MG RESISTOR
R 214 NRSA63J-151X MG RESISTOR
R 215 NRSA63J-151X MG RESISTOR
R 216 NRSA63J-301X MG RESISTOR
R 217 NRSA63J-103X MG RESISTOR
R 218 NRSA63J-331X MG RESISTOR
R 219 NRSA63J-101X MG RESISTOR
R 220 NRSA63J-151X MG RESISTOR
R 221 NRSA63J-151X MG RESISTOR
R 222 NRSA63J-561X MG RESISTOR
R 223 NRSA63J-561X MG RESISTOR
R 224 NRSA63J-561X MG RESISTOR
R 225 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R 232 NRSA63J-470X MG RESISTOR
R 240 NRSA63J-750X MG RESISTOR
R 241 NRSA63J-750X MG RESISTOR
R 242 NRSA63J-750X MG RESISTOR
R 243 NRSA63J-750X MG RESISTOR
R 244 NRSA63J-750X MG RESISTOR
R 245 NRSA63J-750X MG RESISTOR
R 246 NRSA63J-750X MG RESISTOR
R 247 NRSA63J-750X MG RESISTOR
R 248 NRSA63J-151X MG RESISTOR
R 249 NRSA63J-151X MG RESISTOR
R 250 NRSA63J-151X MG RESISTOR
R 251 NRSA63J-151X MG RESISTOR
R 253 NRSA63J-153X MG RESISTOR
R 254 NRSA63J-153X MG RESISTOR
R 255 NRSA63J-153X MG RESISTOR
R 266 NRSA63J-750X MG RESISTOR
R 267 NRSA63J-473X MG RESISTOR
R 268 NRSA63J-750X MG RESISTOR
R 269 NRSA63J-473X MG RESISTOR
R 271 QRJ146J-3R3X UNF C RESCITOR
A
3.3 5% 1/4W
R 272 NRSA63J-750X MG RESISTOR
R 273 NRSA63J-473X MG RESISTOR
R 274 NRSA63J-750X MG RESISTOR
R 275 NRSA63J-750X MG RESISTOR
R 276 NRSA63J-750X MG RESISTOR
R 280 NRSA63J-301X MG RESISTOR
R 281 NRSA63J-301X MG RESISTOR
R 282 NRSA63J-103X MG RESISTOR
R 283 NRSA63J-103X MG RESISTOR
R 284 NRSA63J-301X MG RESISTOR
R 285 NRSA63J-301X MG RESISTOR
R 301 NRSA63J-222X MG RESISTOR
R 302 NRSA63J-222X MG RESISTOR
R 303 NRSA63J-473X MG RESISTOR
R 304 NRSA63J-473X MG RESISTOR
R 305 NRSA63J-621X MG RESISTOR
R 306 NRSA63J-621X MG RESISTOR
R 307 NRSA63J-393X MG RESISTOR
R 308 NRSA63J-393X MG RESISTOR
R 309 NRSA63J-474X MG RESISTOR
R 310 NRSA63J-474X MG RESISTOR
R 311 NRSA63J-104X MG RESISTOR
R 312 NRSA63J-104X MG RESISTOR
R 315 QRJ146J-331X UNF C RESISTOR
A
330 5% 1/4W
R 316 QRJ146J-331X UNF C RESISTOR
A
330 5% 1/4W
R 323 NRSA63J-471X MG RESISTOR
R 324 NRSA63J-471X MG RESISTOR
R 325 NRSA63J-471X MG RESISTOR
R 326 NRSA63J-471X MG RESISTOR
R 327 NRSA63J-471X MG RESISTOR
R 328 NRSA63J-471X MG RESISTOR
R 329 NRSA63J-471X MG RESISTOR
R 330 NRSA63J-471X MG RESISTOR
R 331 NRSA63J-471X MG RESISTOR
R 332 NRSA63J-471X MG RESISTOR
R 333 NRSA63J-471X MG RESISTOR
R 334 NRSA63J-471X MG RESISTOR
R 335 QRZ9005-680X F RESISTOR
A
68 1/0W
R 336 QRZ9005-680X F RESISTOR
A
68 1/0W
R 341 NRSA63J-104X MG RESISTOR
R 342 NRSA63J-104X MG RESISTOR
R 343 NRSA63J-104X MG RESISTOR
R 344 NRSA63J-104X MG RESISTOR
R 345 NRSA63J-104X MG RESISTOR
R 346 NRSA63J-104X MG RESISTOR
R 361 NRSA63J-104X MG RESISTOR
R 362 NRSA63J-104X MG RESISTOR
R 363 NRSA63J-104X MG RESISTOR
R 364 NRSA63J-104X MG RESISTOR
R 365 NRSA63J-104X MG RESISTOR
R 366 NRSA63J-104X MG RESISTOR
R 371 NRSA63J-471X MG RESISTOR
R 372 NRSA63J-471X MG RESISTOR
R 373 NRSA63J-471X MG RESISTOR
R 374 NRSA63J-471X MG RESISTOR
R 375 NRSA63J-471X MG RESISTOR
R 376 NRSA63J-471X MG RESISTOR
R 377 NRSA63J-471X MG RESISTOR
R 378 NRSA63J-471X MG RESISTOR
R 379 NRSA63J-471X MG RESISTOR
R 380 NRSA63J-471X MG RESISTOR
R 381 NRSA63J-471X MG RESISTOR
R 382 NRSA63J-471X MG RESISTOR
R 385 QRZ9005-680X F RESISTOR
A
68 1/0W
R 386 QRZ9005-680X F RESISTOR
A
68 1/0W
R 387 NRSA63J-471X MG RESISTOR
R 388 NRSA63J-471X MG RESISTOR
R 389 NRSA63J-471X MG RESISTOR
R 390 NRSA63J-471X MG RESISTOR
R 391 NRSA63J-512X MG RESISTOR
R 392 NRSA63J-512X MG RESISTOR
R 393 NRSA63J-103X MG RESISTOR
R 394 NRSA63J-103X MG RESISTOR
R 395 NRSA63J-512X MG RESISTOR
R 396 NRSA63J-512X MG RESISTOR
R 397 NRSA63J-104X MG RESISTOR
R 398 NRSA63J-104X MG RESISTOR
R1301 QRZ9005-680X F RESISTOR
A
68 1/0W
R1302 QRZ9005-680X F RESISTOR
A
68 1/0W
R1303 NRSA63J-122X MG RESISTOR
R1304 NRSA63J-122X MG RESISTOR
R1305 QRZ9005-680X F RESISTOR
A
68 1/0W
R1306 QRZ9005-680X F RESISTOR
A
68 1/0W
R1307 NRSA63J-102X MG RESISTOR
R1311 NRSA63J-104X MG RESISTOR
R1312 NRSA63J-104X MG RESISTOR
R1313 NRSA63J-102X MG RESISTOR
R1314 NRSA63J-103X MG RESISTOR
R1315 NRSA63J-103X MG RESISTOR
R1316 NRSA63J-102X MG RESISTOR
(Input board)
