JVC RX-8010VBK Service Manual

RX-8010VBK/RX-8012VSL
3-18
Item
Parts number Parts name Ar
e
a
Electrical parts list
Remarks
Block No. 05
A
Item
Parts number Parts name Ar
e
a
Remarks
A
R2222 NRSA63J-333X MG RESISTOR
R2225 NRSA63J-104X MG RESISTOR
R2226 NRSA63J-104X MG RESISTOR
R2227 NRSA63J-104X MG RESISTOR
R2231 NRSA63J-333X MG RESISTOR
R2232 NRSA63J-333X MG RESISTOR
R2233 NRSA63J-333X MG RESISTOR
R2234 NRSA63J-333X MG RESISTOR
R2235 NRSA63J-333X MG RESISTOR
R2236 NRSA63J-333X MG RESISTOR
R2237 NRSA63J-683X MG RESISTOR
R2238 NRSA63J-683X MG RESISTOR
R2257 NRSA63J-104X MG RESISTOR
R2258 NRSA63J-104X MG RESISTOR
R2261 NRSA63J-104X MG RESISTOR
R2262 NRSA63J-104X MG RESISTOR
R2263 NRSA63J-103X MG RESISTOR
R2264 NRSA63J-103X MG RESISTOR
R2273 NRSA63J-103X MG RESISTOR
R2274 NRSA63J-103X MG RESISTOR
R2275 NRSA63J-682X MG RESISTOR
R2276 NRSA63J-682X MG RESISTOR
R2277 NRSA63J-105X MG RESISTOR
R2278 NRSA63J-105X MG RESISTOR
R2283 NRSA63J-103X MG RESISTOR
R2284 NRSA63J-103X MG RESISTOR
R2285 NRSA63J-113X MG RESISTOR
R2286 NRSA63J-113X MG RESISTOR
R2301 NRSA63J-103X MG RESISTOR
R2302 NRSA63J-103X MG RESISTOR
R2305 NRSA63J-102X MG RESISTOR
R2306 NRSA63J-102X MG RESISTOR
R2307 NRSA63J-104X MG RESISTOR
R2308 NRSA63J-104X MG RESISTOR
R2349 NRSA63J-303X MG RESISTOR
R2350 NRSA63J-303X MG RESISTOR
R2351 NRSA63J-113X MG RESISTOR
R2352 NRSA63J-113X MG RESISTOR
R2353 NRSA63J-222X MG RESISTOR
R2354 NRSA63J-222X MG RESISTOR
R2355 NRSA63J-103X MG RESISTOR
R2356 NRSA63J-103X MG RESISTOR
R2357 NRSA63J-223X MG RESISTOR
R2358 NRSA63J-223X MG RESISTOR
R2359 NRSA63J-103X MG RESISTOR
R2360 NRSA63J-103X MG RESISTOR
R2363 NRSA63J-104X MG RESISTOR
R2364 NRSA63J-104X MG RESISTOR
R2401 NRSA63J-103X MG RESISTOR
R2405 NRSA63J-102X MG RESISTOR
R2407 NRSA63J-104X MG RESISTOR
R2425 NRSA63J-103X MG RESISTOR
R2427 NRSA63J-104X MG RESISTOR
R2429 NRSA63J-103X MG RESISTOR
R2431 NRSA63J-113X MG RESISTOR
R2433 NRSA63J-823X MG RESISTOR
R2485 NRSA63J-102X MG RESISTOR
R2501 NRSA63J-105X MG RESISTOR
R2502 NRSA63J-473X MG RESISTOR
R2503 NRSA63J-473X MG RESISTOR
R2504 NRSA63J-473X MG RESISTOR
R2505 NRSA63J-473X MG RESISTOR
R2506 NRSA63J-473X MG RESISTOR
R2507 NRSA63J-473X MG RESISTOR
R2508 NRSA63J-473X MG RESISTOR
R2511 NRSA63J-221X MG RESISTOR
R2512 NRSA63J-221X MG RESISTOR
R2513 NRSA63J-221X MG RESISTOR
R2514 NRSA63J-103X MG RESISTOR
R2515 NRSA63J-103X MG RESISTOR
R2516 NRSA63J-103X MG RESISTOR
R2517 NRSA63J-103X MG RESISTOR
R2518 NRSA63J-221X MG RESISTOR
R2519 NRSA63J-221X MG RESISTOR
R2520 NRSA63J-221X MG RESISTOR
R2521 NRSA63J-103X MG RESISTOR
R2522 NRSA63J-103X MG RESISTOR
R2523 NRSA63J-103X MG RESISTOR
R2531 NRSA63F-511X MG RESISTOR
R2532 NRSA63F-102X MG RESISTOR
R2551 NRSA63J-183X MG RESISTOR
R2552 NRSA63J-221X MG RESISTOR
R2553 NRSA63J-221X MG RESISTOR
R2554 NRSA63J-221X MG RESISTOR
R2555 NRSA63J-221X MG RESISTOR
R2557 NRSA63J-221X MG RESISTOR
R2559 NRSA63J-221X MG RESISTOR
R2560 NRSA63J-221X MG RESISTOR
R2561 NRSA63J-112X MG RESISTOR
R2562 NRSA63J-112X MG RESISTOR
R2563 NRSA63J-112X MG RESISTOR
R2564 NRSA63J-750X MG RESISTOR
R2568 NRSA63J-221X MG RESISTOR
R2571 NRSA63J-512X MG RESISTOR
R2572 NRSA63J-512X MG RESISTOR
R2573 NRSA63J-512X MG RESISTOR
R2581 NRSA63J-221X MG RESISTOR
R2582 NRSA63J-221X MG RESISTOR
R2583 NRSA63J-221X MG RESISTOR
R2584 NRSA63J-221X MG RESISTOR
R2585 NRSA63J-221X MG RESISTOR
R2586 NRSA63J-221X MG RESISTOR
R2587 NRSA63J-221X MG RESISTOR
R2589 NRSA63J-221X MG RESISTOR
R2591 NRSA63J-221X MG RESISTOR
R2593 NRSA63J-221X MG RESISTOR
R2594 NRSA63J-221X MG RESISTOR
R2595 NRSA63J-221X MG RESISTOR
R2596 NRSA63J-221X MG RESISTOR
R2597 NRSA63J-102X MG RESISTOR
R2611 NRSA63J-473X MG RESISTOR
R2612 NRSA63J-473X MG RESISTOR
R2613 NRSA63J-473X MG RESISTOR
R2614 NRSA63J-473X MG RESISTOR
R2615 NRSA63J-473X MG RESISTOR
R2616 NRSA63J-473X MG RESISTOR
R2701 NRSA63J-473X MG RESISTOR
R2702 NRSA63J-473X MG RESISTOR
R2703 NRSA63J-473X MG RESISTOR
R2709 NRSA63J-221X MG RESISTOR
R2715 NRSA63J-432X MG RESISTOR
R2716 NRSA63J-221X MG RESISTOR
R2717 NRSA63J-221X MG RESISTOR
R2718 NRSA63J-221X MG RESISTOR
UN560 GP1FA550TZ OPT TRANSMITTER
UN561 GP1FA550RZ OPT RECEIVER
(DSP board)
UN562 GP1FA550RZ OPT RECEIVER
UN563 GP1FA550RZ OPT RECEIVER
X 581 NAX0275-001X 1COSCIALLATOR
X2501 NAX0308-001X RESONATOR
X2551 NAX0213-001X CRYSTAL
