Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 LV10469-011A
FRONT PANEL
1
RX-8020VBKUJ
2 VJD5429-001SS JVC MARK 1
3 LV20949-007A
LENS
1
8020VBK
4 LV10470-005A
SUB PANEL
1
BK MODEL
5 LV20939-003A
PUSH BUTTON
1
POWER BK MODEL
6 LV42096-001A
INDICATOR
1
POWER
7 LV20951-001A
PUSH BUTTON
1
TUNER
8 LV20940-001A
P.BUTTON ASSY
1
DOLBY
9 LV20944-001A P.BUTTON ASSY 1 SOURCE
10 LV20942-001A
PUSH BUTTON
1
SEA
11 LV32486-001A
P.BUTTON ASSY
1
LINE STRAIGHT
12 LV42095-002A
FL SCREEN
1
13 QYSBSF2610Z
SCREW
2
FRONT C.B
14 QYSBSF2610Z
SCREW
2
15 QYSBSF2610Z
SCREW
8
FRONT C.B FL
16 QUQ412-0815CJ FFC WIRE 1
17 QUQ412-1030CJ
FFC WIRE
1
18 QYSDSG3006Z
SCREW
4
FRONT D
19 QYSBSG3006Z T.SCREW 3 FRONT U
20 QYSBSG3006Z
T.SCREW
1
EARTH LUG-F.BKT
21 LV10019-003A
CHASSIS BASE
1
22 LV10471-002A
FRONT BRACKET
1
23 QYSDSG3006Z
SCREW
7
C.B-F.B
24 LV42094-003A
H.P BKT
1
25 QYSBSG3006Z
T.SCREW
1
H.P BKT-F.B
26 VKZ4150-001 SPECIAL NUT 1
27 E68587-223SM
CB BKT
3
28 QYSBST3006Z
T.SCREW
3
C.B-BKT
29 QZF6018-001
FOOT
4
30 QYSBST3010Z
T.SCREW
4
FOOT
31 LV20984-002A
HEAT SINK
1
CORRUGATE
32 QYSBSG3012E
SCREW
10
TR
33 LV42098-001A C.B BKT 1 PRI/SEC C.B
34 QYSBST3006Z
T.SCREW
1
C.B BKT
35 LV32433-001A
H.S BRACKET(R)
1
36 LV32434-001A
H.S BRACKET(L)
1
37 QYSBSG3008Z
T.SCREW
4
H.S-BKT
38 QYSBST3006Z
T.SCREW
2
H.S BKT-F.BKT
39 QYSBSG3006Z
T.SCREW
2
H.S BKT
40 QYSBST3006Z T.SCREW 4 H.S BKT-CHASSIS
41 QYSBSG3006Z
T.SCREW
2
M.C.B
42 E65923-003
TAPPING SCREW
1
M.C.B
43 LV30225-0B2A SPACER 1
44 QYSBSG3006Z
T.SCREW
3
H.S-C.B
45 QYSBSG3006Z
T.SCREW
3
P.C.B-CHASSIS
46 QYSBSG3006Z
T.SCREW
1
C.B-CHASSIS
47 QQT0325-003
TRANSFORMER
A
1
48 QYSDSTL4008Z
SPECIAL SCREW
4
P.TRANS
Item
Parts number Parts name
Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
49 LV10660-002A
REAR PANEL
1
RX-8020VBKUJ
50 QYSBSGY3008M SPECIAL SCREW 3 R.P-C.BASE
51 QYSBSGY3008M
SPECIAL SCREW
1
52 QYSBSGY3008M
SPECIAL SCREW
2
TUNER
53 FMYH4004-001
PLASTIC RIVET
2
A.INPUT
54 QYSBSGY3008M
SPECIAL SCREW
4
A.INPUT
55 QYSBSGY3008M
SPECIAL SCREW
3
V.INPUT
56 QYSBSGY3008M
SPECIAL SCREW
3
VIDEO
57 QYSBSGY3008M SPECIAL SCREW 4 S VIDEO
58 QYSBSGY3008M
SPECIAL SCREW
6
DIGITAL
59 QYSBSGY3008M
SPECIAL SCREW
5
COMP C.B
60 QYSBSGY3008M
SPECIAL SCREW
4
SPK C.B
61 QYSBSGY3008M
SPECIAL SCREW
3
COMPULINK
62 QYSBSGY3008M
SPECIAL SCREW
2
VOL SEL
63 E409257-001
GND TERMINAL
1
64 QMPK150-200-JD POWER CORD
A
1
65 QZW0033-001
STRAIN RELIEF
A
1
66 LV20038-009A
TOP COVER
1
BK MODEL
67 LV30225-088A SPACER 1 FOR TOP COVER
68 LV30077-004A
PROTECT SHEET
1
SL
69 QYSBSGY3008M
SPECIAL SCREW
3
70 E406308-003
SPECIAL SCREW
4
71 LV32435-003A
VOL KNOB
1
BK
72 LV32488-003A
COVER
1
JACK COVER
73 QMF51W2-6R3-J8
FUSE
A
1
F 1
74 QMF51E2-R10-J1 FUSE
A
1 F 2
75 QMF51W2-3R15-J8
FUSE
A
1
F 4
76 QMF51W2-2R0-J8
FUSE
A
1
F 61
77 QMF51W2-2R0-J8
FUSE
A
1
F 62
78 E307572-001
FASTENER
1
79 E409396-003
CAUTION LABEL
1
80 E3400-444
FELT SPACER
2
FS400,FS401
81 QYSBSG3008E T.SCREW 3
82 QYSBSG3008E
T.SCREW
3
83 QYSBSG3008E
T.SCREW
1
UJ ONLY
