JVC RX-8020VBK - Volume and Speaker Control

RX-8020VBK
3-5
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
C 801 QFZ9076-104Z MM CAPACITOR UJ/E/EN
C 802 QFZ9076-104Z MM CAPACITOR UJ/E/EN
C 805 QFZ9076-104Z MM CAPACITOR UJ/E/EN
C 807 QEZ0588-688 E.CAPACITOR 6800MF
C 808 QEZ0588-688 E.CAPACITOR
6800MF
C 811 QCF31HZ-472Z C CAPACITOR
4700PF +80:-20%
C 816 QETN1EM-476Z E CAPACITOR
47MF 20% 25V
C 823 QETN1CM-476Z E CAPACITOR
47MF 20% 16V
C 824 QETN1EM-106Z E CAPACITOR
10MF 20% 25V
C 833 QDVB1EZ-223Y C CAPACITOR EXCEPT J/C
C 834 QDVB1EZ-223Y C CAPACITOR EXCEPT J/C
C 835 QFLC1HJ-223Z M CAPACITOR EXCEPT J/C
C 836 QFLC1HJ-223Z M CAPACITOR EXCEPT J/C
C 837 QFLC1HJ-223Z M CAPACITOR EXCEPT J/C
C 838 QFLC1HJ-223Z M CAPACITOR
EXCEPT J/C
C 839 QDVB1EZ-223Y C CAPACITOR
EXCEPT J/C
C 840 QDVB1EZ-223Y C CAPACITOR
EXCEPT J/C
C 841 QCS31HJ-221Z C CAPACITOR
EXCEPT J/C
C 842 QCS31HJ-221Z C CAPACITOR
EXCEPT J/C
C 843 QCS31HJ-221Z C CAPACITOR EXCEPT J/C
C 844 QCS31HJ-221Z C CAPACITOR EXCEPT J/C
C 845 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 846 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 847 QCS31HJ-221Z C CAPACITOR
220PF 5% 50V
C 848 QCS31HJ-221Z C CAPACITOR
220PF 5% 50V
C 850 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 851 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 852 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 853 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 881 QCBB1HK-331Y C CAPACITOR EXCEPT J/C
C 883 QCBB1HK-331Y C CAPACITOR EXCEPT J/C
C 884 QCBB1HK-331Y C CAPACITOR EXCEPT J/C
C 885 QFVJ1HJ-473Z MF CAPACITOR EXCEPT J/C
C 886 QCS31HJ-221Z C CAPACITOR
EXCEPT J/C
C 887 QFVJ1HJ-473Z MF CAPACITOR
EXCEPT J/C
C 888 QFVJ1HJ-473Z MF CAPACITOR
EXCEPT J/C
C 889 QCS31HJ-221Z C CAPACITOR
EXCEPT J/C
C 890 QCS31HJ-221Z C CAPACITOR
EXCEPT J/C
C 891 QCS31HJ-221Z C CAPACITOR EXCEPT J/C
C 892 QCS31HJ-221Z C CAPACITOR EXCEPT J/C
C 893 QCS31HJ-221Z C CAPACITOR EXCEPT J/C
CN 72 QGB2510K1-11 CONNECTOR
CN 82 QGB2510K1-09 CONNECTOR
CN701 QGB2510J1-14 CONNECTOR
CN702 QGB2510J1-14 CONNECTOR
CN703 QGB2510J1-10 CONNECTOR
CN705 QGB2510J1-12 CONNECTOR
CN706 QGB2510J1-12 CONNECTOR
CN721 QGA2501C1-03 3P CONNECTOR
CN723 QGA2501C1-04 4P CONNECTOR
CN801 QJK012-032403 SKT WIRE ASSY
CN813 QGA3901C1-04 CONNECTOR
CN814 QGA3901C1-06 CONNECTOR
CN823 QJK015-043004 SIN CR C-B WIRE
A
CN824 QJK015-063504 SIN CR C-B WIRE
A
CN831 QGD2504C1-04Z SOCKET
CN881 QGD2504C1-03Z SOCKET
D 801 30DF2-FC DIODE
D 802 30DF2-FC DIODE
D 803 30DF2-FC DIODE
D 804 30DF2-FC DIODE
D 811 MTZJ20B-T2 Z DIODE
UJ
D 816 MTZJ18C-T2 Z.DIODE
D 825 1SS133-T2 SI DIODE
D 831 1SS133-T2 SI DIODE
D 832 1SS133-T2 SI DIODE
D 841 MTZJ5.1C-T2 ZENER DIODE
D 842 1SS133-T2 SI DIODE
D 843 1SS133-T2 SI DIODE
D 844 1SS133-T2 SI DIODE
D 845 1SS133-T2 SI DIODE
D 846 1SS133-T2 SI DIODE
D 851 1SS133-T2 SI DIODE
D 852 1SS133-T2 SI DIODE
D 871 1SS133-T2 SI DIODE
EP801 QNZ0136-001Z EARTH PLATE
FW931 QUM137-08DGZ4 PARA RIBON WIRE
L 843 QQLZ005-R45 INDUCTOR EXCEPT J/C
L 844 QQLZ005-R45 INDUCTOR EXCEPT J/C
L 845 QQLZ005-R45 INDUCTOR EXCEPT J/C
Q
811 2SD2395/EF/ TRANSISTOR
Q
812 KTC3200/GL/-T TRANSISTOR
Q
823 KTC3199/GL/-T TRANSISTOR
Q
824 KTC3200/GL/-T TRANSISTOR
Q
825 KTA1268/GL/-T TRANSISTOR
Q 830 KRC109M-T D.TRANSISTOR
Q
831 KRC109M-T D.TRANSISTOR
Q
832 KRC109M-T D.TRANSISTOR
Q
833 KRC109M-T D.TRANSISTOR
Q
834 KRC109M-T D.TRANSISTOR
Q
835 KRC109M-T D.TRANSISTOR
Q
836 KRC109M-T D.TRANSISTOR
R 801 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 802 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 811 QRJ146J-120X UNF C RESISTOR
UJ/E/EN
R 812 QRK126J-332X C RESISTOR 3.3K 5% 1/2
W
R 813 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 814 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 815 QRJ146J-120X UNF C RESISTOR 12 5% 1/4W
R 816 QRL027J-332 UNF.OMF.RES.
3.3K 5% 1/2
W
R 823 QRE141J-103Y C RESISTOR
10K 5% 1/4W
R 824 QRE141J-134Y C RESISTOR
130K 5% 1/4W
R 825 QRE141J-103Y C RESISTOR
10K 5% 1/4W
R 826 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 831 QRJ146J-120X UNF C RESISTOR 12 5% 1/4W
R 832 QRJ146J-120X UNF C RESISTOR 12 5% 1/4W
R 833 QRJ146J-100X UNF C RESISTOR EXCEPT J/C
R 834 QRJ146J-100X UNF C RESISTOR EXCEPT J/C
R 837 QRJ146J-100X UNF C RESISTOR
EXCEPT J/C
R 838 QRJ146J-100X UNF C RESISTOR
EXCEPT J/C
R 841 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 842 QRE141J-823Y C RESISTOR
82K 5% 1/4W
R 843 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 844 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 845 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 851 QRJ146J-120X UNF C RESISTOR 12 5% 1/4W
R 852 QRJ146J-120X UNF C RESISTOR 12 5% 1/4W
R 855 QRJ146J-392X UNF C RESISTOR 3.9K 5% 1/4
W
R 856 QRE141J-223Y C RESISTOR
22K 5% 1/4W
R 857 QRE141J-682Y C RESISTOR
6.8K 5% 1/4
W
R 858 QRE141J-472Y C RESISTOR
4.7K 5% 1/4
W
R 859 QRE141J-223Y C RESISTOR
22K 5% 1/4W
R 860 QRE141J-682Y C RESISTOR
6.8K 5% 1/4
W
R 861 QRE141J-472Y C RESISTOR 4.7K 5% 1/4
W
R 862 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 863 QRE141J-682Y C RESISTOR 6.8K 5% 1/4
W
R 864 QRE141J-472Y C RESISTOR 4.7K 5% 1/4
W
R 865 QRE141J-472Y C RESISTOR
4.7K 5% 1/4
W
R 866 QRE141J-472Y C RESISTOR
4.7K 5% 1/4
W
R 867 QRE141J-103Y C RESISTOR
10K 5% 1/4W
R 871 QRJ146J-120X UNF C RESISTOR
12 5% 1/4W
R 885 QRJ146J-100X UNF C RESISTOR
EXCEPT J/C
