JVC RX-8020VBK - Page 20

RX-8020VBK
3-7
Item
Parts number Parts name Area
Electrical parts list (Front board)
Remarks
Block No. 02
A
BK400 LV42092-001A FL HOLDER(R)
BK401 LV42093-001A FL HOLDER(L)
C 400 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 401 NCB31CK-104X C CAPACITOR
C 402 NCB31CK-104X C CAPACITOR
C 404 NCB31EK-223X C CAPACITOR
C 406 NCB31HK-331X C CAPACITOR
C 407 QCZ0202-155Z ML C CAPACITOR
1.5MF
C 408 NCB31EK-223X C CAPACITOR
C 409 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 410 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 411 NCB21AK-225X C.CAPACITOR
C 412 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 420 NCB31HK-471X C CAPACITOR
C 421 NCB31HK-471X C CAPACITOR
C 422 NCB31HK-471X C CAPACITOR
C 423 NCB31HK-471X C CAPACITOR
C 424 NCB31HK-471X C CAPACITOR
C 425 NCB31HK-471X C CAPACITOR
C 430 NCB31CK-104X C CAPACITOR
C 431 NCB31EK-223X C CAPACITOR
C 432 NCS31HJ-220X C CAPACITOR
C 433 NCS31HJ-220X C CAPACITOR
C 435 NCB31CK-104X C CAPACITOR
C 436 NCB31CK-104X C CAPACITOR
C 437 NCB31CK-104X C CAPACITOR
C 438 NCB31CK-104X C CAPACITOR
C 439 NCB31CK-104X C CAPACITOR
C 440 NCB31CK-104X C CAPACITOR
C 441 QEKC1CM-106Z E CAPACITOR 10MF 20% 16V
C 442 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C 443 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C 444 NCS31HJ-331X C.CAPACITOR
C 448 NCB31CK-104X C CAPACITOR
C 456 NCB31CK-104X C CAPACITOR
C 460 NCB31CK-104X C CAPACITOR
C 461 NCB31HK-221X C CAPACITOR
EXCEPT J/C
C 462 NCB31HK-221X C CAPACITOR
EXCEPT J/C
C 463 NCS31HJ-470X C CAPACITOR EXCEPT J/C
C 464 NCS31HJ-470X C CAPACITOR EXCEPT J/C
C 465 NCS31HJ-470X C CAPACITOR EXCEPT J/C
CN406 WJP0031-001A C-B WIRE ASSY
CN410 QGF1205F1-10 CONNECTOR
CN412 QGF1205F1-08 CONNECTOR
CN420 QJK025-031301 SIN CR C-B WIRE
(
LEFT
)
CN422 QJK025-041201 SIN ID C-B WIRE
(
RIGHT
)
CN430 QGA2501C1-03 3P CONNECTOR
CN432 QGA2501C1-04 4P CONNECTOR
D 405 1SS133-T2 SI DIODE
D 410 SLR-342VC-T LED
(
FM/AM
)
D 411 SLR-342VC-T LED
(
USB
)
D 412 SLR-342VC-T LED
(
TAPE
)
D 413 SLR-342VC-T LED
(
CDR
)
D 414 SLR-342VC-T LED
(
PHONE
)
D 415 SLR-342VC-T LED
(
CD
)
D 416 SLR-342VC-T LED
(
TV/DBS
)
D 417 SLR-342VC-T LED
(
VIDEO
)
D 418 SLR-342VC-T LED
(
VCR2
)
D 419 SLR-342VC-T LED
(
VCR1
)
D 420 SLR-342VC-T LED
(
DVD MULTI
)
D 421 SLR-342VC-T LED
(
DVD
)
D 422 SLR-342VC-T LED
(
SURROUND
)
D 423 SLR-342VC-T LED
(
DSP
)
D 480 SLR-342VC-T LED
(
STANDBY
)
D 490 SLR-342VC-T LED
(
DIRECT
)
D 491 SLR-342VC-T LED
(
BASS
)
DI400 QLF0102-001 FL TUBE
IC400 MN101C35DHL1 IC
IC402 BU2092 IC
IC404 GP1UM281XK IR DETECT UNIT
IC410 PCM2702ED-X IC
IC411 NJU7241F33-X IC
J 400 QND0026-001 S JACK
J 401 QNZ0541-001 USB JACK
JS400 QSW0898-001 JOG VOLUME
K 451 NQR0201-018X INDUCTOR
K 452 NQR0201-018X INDUCTOR
K 453 NQR0201-018X INDUCTOR
K 454 NQR0201-018X INDUCTOR
K 455 NQR0201-018X INDUCTOR
PW401 QUB030-17PPHM SIN TWIST WIRE
Q
402 DTC114TKA-X TRANSISTOR
Q
403 DTC144WKA-X TRANSISTOR
Q
404 KRC107S-X DIGITAL.TR
Q
407 KRC107S-X DIGITAL.TR
Q 408 KRC107S-X DIGITAL.TR
Q
410 DTA114YKA-X TRANSISTOR
(
DIRECT
)
Q
411 DTA114YKA-X TRANSISTOR
(
BASS
)
Q
412 DTA114YKA-X TRANSISTOR
(
STANBY
)
Q
413 DTA114YKA-X TRANSISTOR
(
SURROUND
)
Q
414 DTA114YKA-X TRANSISTOR
(
DSP
)
R 400 NRSA63J-102X MG RESISTOR
R 401 NRSA63J-102X MG RESISTOR
R 402 NRSA63J-122X MG RESISTOR
R 403 NRSA63J-102X MG RESISTOR
R 404 NRSA63J-102X MG RESISTOR
R 405 NRSA63J-122X MG RESISTOR
R 406 NRSA63J-152X MG RESISTOR
R 407 NRSA63J-222X MG RESISTOR
R 408 NRSA63J-272X MG RESISTOR
R 409 NRSA63J-332X MG RESISTOR
R 410 NRSA63J-102X MG RESISTOR
R 411 NRSA63J-102X MG RESISTOR
R 412 NRSA63J-122X MG RESISTOR
R 413 NRSA63J-152X MG RESISTOR
R 414 NRSA63J-222X MG RESISTOR
R 415 NRSA63J-272X MG RESISTOR
R 416 NRSA63J-332X MG RESISTOR
R 417 NRSA63J-102X MG RESISTOR
R 418 NRSA63J-102X MG RESISTOR
R 419 NRSA63J-122X MG RESISTOR
R 420 NRSA63J-152X MG RESISTOR
R 421 NRSA63J-222X MG RESISTOR
R 422 NRSA63J-272X MG RESISTOR
R 423 NRSA63J-332X MG RESISTOR
R 424 NRSA63J-102X MG RESISTOR
R 425 NRSA63J-102X MG RESISTOR
R 426 NRSA63J-122X MG RESISTOR
R 431 NRSA63J-102X MG RESISTOR
R 432 NRSA63J-102X MG RESISTOR
R 433 NRSA63J-122X MG RESISTOR
R 434 NRSA63J-152X MG RESISTOR
R 435 NRSA63J-222X MG RESISTOR
R 436 NRSA63J-102X MG RESISTOR VER 8020J
R 437 NRSA63J-102X MG RESISTOR VER 8020D
R 438 NRSA63J-122X MG RESISTOR VER 8020E
R 439 NRSA63J-152X MG RESISTOR VER 8020A
R 440 NRSA63J-222X MG RESISTOR
VER 8020U1
R 443 NRSA63J-102X MG RESISTOR
NTSC
R 445 NRSA63J-103X MG RESISTOR
R 446 NRSA63J-103X MG RESISTOR
R 447 NRSA63J-103X MG RESISTOR
Item
Parts number Parts name Area
Remarks
A
