JVC RX-8020VBK - Page 21

RX-8020VBK
3-8
Item
Parts number Parts name Area
Electrical parts list (Front board)
Remarks
Block No. 02
A
R 448 NRSA63J-103X MG RESISTOR
R 449 NRSA63J-103X MG RESISTOR
R 450 NRSA63J-103X MG RESISTOR
R 451 NRSA63J-103X MG RESISTOR
R 452 NRSA63J-103X MG RESISTOR
R 453 NRSA63J-103X MG RESISTOR
R 454 NRSA63J-103X MG RESISTOR
R 455 NRSA63J-471X MG RESISTOR
R 456 NRSA63J-103X MG RESISTOR
R 457 NRSA63J-103X MG RESISTOR
R 458 NRSA63J-103X MG RESISTOR
R 459 NRSA63J-221X MG RESISTOR
R 460 NRSA63J-221X MG RESISTOR
R 461 NRSA63J-221X MG RESISTOR
R 462 NRSA63J-221X MG RESISTOR
R 463 NRSA63J-221X MG RESISTOR
R 464 NRSA63J-221X MG RESISTOR
R 465 NRSA63J-331X MG RESISTOR
R 466 NRSA63J-331X MG RESISTOR
R 467 NRSA63J-221X MG RESISTOR
R 468 NRSA63J-221X MG RESISTOR
R 469 NRSA63J-221X MG RESISTOR
R 470 NRSA63J-750X MG RESISTOR
R 471 NRSA63J-750X MG RESISTOR
R 472 NRSA63J-750X MG RESISTOR
R 473 NRSA63J-152X MG RESISTOR
R 474 NRSA63J-105X MG RESISTOR
R 475 NRSA63J-220X MG RESISTOR
R 476 NRSA63J-220X MG RESISTOR
R 477 NRSA63J-0R0X MG RESISTOR
R 479 NRSA63J-181X MG RESISTOR
R 480 NRSA63J-152X MG RESISTOR
R 481 NRSA63J-222X MG RESISTOR
R 482 NRSA63J-272X MG RESISTOR
R 483 NRSA63J-392X MG RESISTOR
R 486 NRSA63J-0R0X MG RESISTOR
R 490 NRSA63J-272X MG RESISTOR
R 491 NRSA63J-392X MG RESISTOR
R 495 NRSA63J-102X MG RESISTOR
S 400 QSW0683-001Z PUSH SWITCH
(
SURROUND
)
S 401 QSW0683-001Z PUSH SWITCH
(
DSP
)
S 402 QSW0683-001Z PUSH SWITCH
(
SURR/DSP OFF
)
S 403 QSW0683-001Z PUSH SWITCH
(
TUNING UP
)
S 404 QSW0683-001Z PUSH SWITCH
(
PRESET UP
)
S 405 QSW0683-001Z PUSH SWITCH
(
FM MODE
)
S 406 QSW0683-001Z PUSH SWITCH
(
MEMORY
)
S 407 QSW0683-001Z PUSH SWITCH
(
INPUT MODE
)
S 408 QSW0683-001Z PUSH SWITCH
(
DVD
)
S 409 QSW0683-001Z PUSH SWITCH
(
DVD MULTI
)
S 410 QSW0683-001Z PUSH SWITCH
(
TUNING DOWN
)
S 411 QSW0683-001Z PUSH SWITCH
(
PRESET DOWN
)
S 412 QSW0683-001Z PUSH SWITCH
(
VCR1
)
S 413 QSW0683-001Z PUSH SWITCH
(
VCR2
)
S 414 QSW0683-001Z PUSH SWITCH
(
VIDEO
)
S 415 QSW0683-001Z PUSH SWITCH
(
CD
)
S 416 QSW0683-001Z PUSH SWITCH
(
TV/DBS
)
S 417 QSW0683-001Z PUSH SWITCH
(
CDR
)
S 418 QSW0683-001Z PUSH SWITCH
(
USB AUDIO
)
S 419 QSW0683-001Z PUSH SWITCH
(
PHONE
)
S 420 QSW0683-001Z PUSH SWITCH
(
FM/AM
)
S 421 QSW0683-001Z PUSH SWITCH
(
DIGITAL SEA
)
S 422 QSW0683-001Z PUSH SWITCH
(
LEVEL ADJUST
)
S 423 QSW0683-001Z PUSH SWITCH
(
TAPE/MD
)
S 424 QSW0683-001Z PUSH SWITCH
(
DOWN
)
S 425 QSW0683-001Z PUSH SWITCH
(
EFECT
)
S 426 QSW0683-001Z PUSH SWITCH
(
SETTING
)
S 431 QSW0683-001Z PUSH SWITCH
(
UP
)
S 480 QSW0683-001Z PUSH SWITCH
(
POWER
)
S 481 QSW0683-001Z PUSH SWITCH
(
SPK1
)
S 482 QSW0683-001Z PUSH SWITCH
(
SPK2
)
S 483 QSW0683-001Z PUSH SWITCH
(
SUBWFR
)
S 490 QSW0683-001Z PUSH SWITCH
(
DIRECT
)
S 491 QSW0683-001Z PUSH SWITCH
(
BASS
)
X 400 QAX0246-001Z C RESONATOR
X 410 QAX0320-001Z CRYSTAL
Item
Parts number Parts name Area
Remarks
A
