RX-8020VBK
3-10
Item
Parts number Parts name Area
Electrical parts list (Power board)
Remarks
Block No. 03
A
Q 772 KTC3200/GL/-T TRANSISTOR
Q
773 KTA1268/GL/-T TRANSISTOR
Q
774 KTA1268/GL/-T TRANSISTOR
Q
781 2SD637/QR/ TRANSISTOR
Q
782 2SD637/QR/ TRANSISTOR
Q
791 KTA1268/GL/-T TRANSISTOR
Q
792 KTA1268/GL/-T TRANSISTOR
Q
1701 2SC2240-BL/AB/T TRANSISTOR
Q
1702 2SC2240-BL/AB/T TRANSISTOR
Q1703 KTA1268/GL/-T TRANSISTOR
Q1731 2SD637/QR/ TRANSISTOR
Q
1751 2SD2390/OPY/-F6 TRANSISTOR
Q
1752 2SB1560/OPY/-F6 TRANSISTOR
Q
1771 KTC3200/GL/-T TRANSISTOR
Q
1772 KTA1268/GL/-T TRANSISTOR
Q
1791 KTA1268/GL/-T TRANSISTOR
Q
1801 2SC2240-BL/AB/T TRANSISTOR
Q
1802 2SC2240-BL/AB/T TRANSISTOR
Q
1803 2SC2240-BL/AB/T TRANSISTOR
Q1804 2SC2240-BL/AB/T TRANSISTOR
Q
1805 KTA1268/GL/-T TRANSISTOR
Q
1806 KTA1268/GL/-T TRANSISTOR
Q
1831 2SD637/QR/ TRANSISTOR
Q
1832 2SD637/QR/ TRANSISTOR
Q
1851 2SD2390/OPY/-F6 TRANSISTOR
Q
1852 2SD2390/OPY/-F6 TRANSISTOR
Q
1853 2SB1560/OPY/-F6 TRANSISTOR
Q
1854 2SB1560/OPY/-F6 TRANSISTOR
Q
1871 KTC3200/GL/-T TRANSISTOR
Q1872 KTC3200/GL/-T TRANSISTOR
Q
1873 KTA1268/GL/-T TRANSISTOR
Q
1874 KTA1268/GL/-T TRANSISTOR
Q
1891 KTA1268/GL/-T TRANSISTOR
Q
1892 KTA1268/GL/-T TRANSISTOR
R 701 QRE141J-222Y C RESISTOR
2.2K 5% 1/4
W
R 702 QRE141J-222Y C RESISTOR
2.2K 5% 1/4
W
R 703 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 704 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 705 QRE141J-202Y C RESISTOR 2.0K 5% 1/4
W
R 706 QRE141J-202Y C RESISTOR 2.0K 5% 1/4
W
R 707 QRE141J-202Y C RESISTOR 2.0K 5% 1/4
W
R 708 QRE141J-202Y C RESISTOR 2.0K 5% 1/4
W
R 709 QRE141J-912Y C RESISTOR
9.1K 5% 1/4
W
R 710 QRE141J-912Y C RESISTOR
9.1K 5% 1/4
W
R 711 QRE141J-621Y C RESISTOR
620 5% 1/4W
R 712 QRE141J-621Y C RESISTOR
620 5% 1/4W
R 715 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 716 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 717 QRJ146J-562X UNF C RESISTOR 5.6K 5% 1/4
W
R 718 QRJ146J-562X UNF C RESISTOR 5.6K 5% 1/4
W
R 719 QRK126J-103X C RESISTOR 10K 5% 1/2W
R 720 QRK126J-103X C RESISTOR 10K 5% 1/2W
R 721 QRJ146J-151X UNF C RESISTOR
150 5% 1/4W
R 722 QRJ146J-151X UNF C RESISTOR
150 5% 1/4W
R 723 QRE141J-391Y C RESISTOR
390 5% 1/4W
R 724 QRE141J-391Y C RESISTOR
390 5% 1/4W
R 725 QRE141J-152Y C RESISTOR
1.5K 5% 1/4
W
R 726 QRE141J-152Y C RESISTOR 1.5K 5% 1/4
W
R 727 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R 728 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R 729 QRE141J-391Y C RESISTOR 390 5% 1/4W
R 730 QRE141J-391Y C RESISTOR
390 5% 1/4W
R 731 QRE141J-391Y C RESISTOR
390 5% 1/4W
R 732 QRE141J-391Y C RESISTOR
390 5% 1/4W
R 733 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 734 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 761 QRJ146J-100X UNF C RESISTOR 10 5% 1/4W
R 762 QRJ146J-100X UNF C RESISTOR 10 5% 1/4W
R 763 QRJ146J-100X UNF C RESISTOR 10 5% 1/4W
R 764 QRJ146J-100X UNF C RESISTOR 10 5% 1/4W
R 771 QRE141J-391Y C RESISTOR
390 5% 1/4W
R 772 QRE141J-391Y C RESISTOR
390 5% 1/4W
R 773 QRE141J-391Y C RESISTOR
390 5% 1/4W
R 774 QRE141J-391Y C RESISTOR
390 5% 1/4W
R 775 QRE141J-201Y C RESISTOR
200 5% 1/4W
R 776 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 777 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 778 QRE141J-201Y C RESISTOR 200 5% 1/4W
R 779 QRZ0218-R22 C RESISTOR 1/2W
R 780 QRZ0218-R22 C RESISTOR 1/2W
R 781 QRE141J-391Y C RESISTOR
390 5% 1/4W
R 782 QRE141J-391Y C RESISTOR
390 5% 1/4W
R 783 QRE141J-621Y C RESISTOR
620 5% 1/4W
R 784 QRE141J-621Y C RESISTOR
620 5% 1/4W
R 787 QRE141J-473Y C RESISTOR
47K 5% 1/4W
R 788 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 789 QRE141J-271Y C RESISTOR 270 5% 1/4W
R 790 QRE141J-271Y C RESISTOR 270 5% 1/4W
R 791 QRJ125J-330 UNF OMF RESISTO 33 5% 1/2W
R 792 QRJ125J-330 UNF OMF RESISTO
33 5% 1/2W
R 793 QRL027J-100 UNF.OMF.RES.
10 5% 1/2W
R 794 QRL027J-100 UNF.OMF.RES.
10 5% 1/2W
R 795 QRE141J-102Y C RESISTOR
1.0K 5% 1/4
W
R 796 QRE141J-102Y C RESISTOR
1.0K 5% 1/4
W
R 797 QRE141J-153Y C RESISTOR
15K 5% 1/4W
R 798 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R1701 QRE141J-222Y C RESISTOR 2.2K 5% 1/4
W
R1702 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R1703 QRE141J-202Y C RESISTOR 2.0K 5% 1/4
W
R1705 QRE141J-123Y C RESISTOR
12K 5% 1/4W
R1711 QRE141J-331Y C RESISTOR
330 5% 1/4W
R1712 QRE141J-563Y C RESISTOR
56K 5% 1/4W
R1721 QRJ146J-221X UNF C RESISTOR
220 5% 1/4W
R1722 QRE141J-332Y C RESISTOR
3.3K 5% 1/4
W
R1723 QRE141J-332Y C RESISTOR 3.3K 5% 1/4
W
R1724 QRE141J-332Y C RESISTOR 3.3K 5% 1/4
W
R1725 QRE141J-332Y C RESISTOR 3.3K 5% 1/4
W
R1731 QRE141J-911Y C RESISTOR 910 5% 1/4W
R1732 QRE141J-391Y C RESISTOR
390 5% 1/4W
R1733 QRE141J-271Y C RESISTOR
270 5% 1/4W
R1741 QRJ146J-221X UNF C RESISTOR
220 5% 1/4W
R1751 QRJ146J-100X UNF C RESISTOR
10 5% 1/4W
R1752 QRJ146J-100X UNF C RESISTOR
10 5% 1/4W
R1753 QRZ0218-R22 C RESISTOR
1/2W
R1761 QRJ125J-330 UNF OMF RESISTO 33 5% 1/2W
R1762 QRL027J-100 UNF.OMF.RES. 10 5% 1/2W
R1771 QRE141J-391Y C RESISTOR 390 5% 1/4W
R1772 QRE141J-391Y C RESISTOR 390 5% 1/4W
R1773 QRE141J-201Y C RESISTOR
200 5% 1/4W
R1774 QRE141J-201Y C RESISTOR
200 5% 1/4W
R1791 QRE141J-102Y C RESISTOR
1.0K 5% 1/4
W
R1793 QRE141J-183Y C RESISTOR
18K 5% 1/4W
R1795 QRE141J-473Y C RESISTOR
47K 5% 1/4W
R1801 QRE141J-222Y C RESISTOR 2.2K 5% 1/4
W
R1802 QRE141J-222Y C RESISTOR 2.2K 5% 1/4
W
R1803 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R1804 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R1805 QRE141J-202Y C RESISTOR
2.0K 5% 1/4
W
R1806 QRE141J-202Y C RESISTOR
2.0K 5% 1/4
W
R1809 QRE141J-123Y C RESISTOR
12K 5% 1/4W
R1810 QRE141J-123Y C RESISTOR
12K 5% 1/4W
R1811 QRE141J-331Y C RESISTOR
330 5% 1/4W
