RX-8020VBK
3-11
Item
Parts number Parts name Area
Electrical parts list (Power board)
Remarks
Block No. 03
A
R1812 QRE141J-331Y C RESISTOR 330 5% 1/4W
R1813 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R1814 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R1821 QRJ146J-221X UNF C RESISTOR 220 5% 1/4W
R1822 QRJ146J-221X UNF C RESISTOR
220 5% 1/4W
R1823 QRE141J-332Y C RESISTOR
3.3K 5% 1/4
W
R1824 QRE141J-332Y C RESISTOR
3.3K 5% 1/4
W
R1825 QRE141J-332Y C RESISTOR
3.3K 5% 1/4
W
R1826 QRE141J-332Y C RESISTOR
3.3K 5% 1/4
W
R1827 QRE141J-332Y C RESISTOR 3.3K 5% 1/4
W
R1828 QRE141J-332Y C RESISTOR 3.3K 5% 1/4
W
R1829 QRE141J-332Y C RESISTOR 3.3K 5% 1/4
W
R1830 QRE141J-332Y C RESISTOR 3.3K 5% 1/4
W
R1831 QRE141J-911Y C RESISTOR 910 5% 1/4W
R1832 QRE141J-911Y C RESISTOR
910 5% 1/4W
R1833 QRE141J-391Y C RESISTOR
390 5% 1/4W
R1834 QRE141J-391Y C RESISTOR
390 5% 1/4W
R1835 QRE141J-271Y C RESISTOR
270 5% 1/4W
R1836 QRE141J-271Y C RESISTOR
270 5% 1/4W
R1841 QRJ146J-221X UNF C RESISTOR 220 5% 1/4W
R1842 QRJ146J-221X UNF C RESISTOR 220 5% 1/4W
R1851 QRJ146J-100X UNF C RESISTOR 10 5% 1/4W
R1852 QRJ146J-100X UNF C RESISTOR 10 5% 1/4W
R1853 QRJ146J-100X UNF C RESISTOR
10 5% 1/4W
R1854 QRJ146J-100X UNF C RESISTOR
10 5% 1/4W
R1855 QRZ0218-R22 C RESISTOR
1/2W
R1856 QRZ0218-R22 C RESISTOR
1/2W
R1861 QRJ125J-330 UNF OMF RESISTO
33 5% 1/2W
R1862 QRJ125J-330 UNF OMF RESISTO
33 5% 1/2W
R1863 QRL027J-100 UNF.OMF.RES. 10 5% 1/2W
R1864 QRL027J-100 UNF.OMF.RES. 10 5% 1/2W
R1871 QRE141J-391Y C RESISTOR 390 5% 1/4W
R1872 QRE141J-391Y C RESISTOR 390 5% 1/4W
R1873 QRE141J-391Y C RESISTOR
390 5% 1/4W
R1874 QRE141J-391Y C RESISTOR
390 5% 1/4W
R1875 QRE141J-201Y C RESISTOR
200 5% 1/4W
R1876 QRE141J-201Y C RESISTOR
200 5% 1/4W
R1877 QRE141J-201Y C RESISTOR
200 5% 1/4W
R1878 QRE141J-201Y C RESISTOR 200 5% 1/4W
R1891 QRE141J-102Y C RESISTOR 1.0K 5% 1/4
W
R1892 QRE141J-102Y C RESISTOR 1.0K 5% 1/4
W
R1893 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R1894 QRE141J-183Y C RESISTOR
18K 5% 1/4W
R1895 QRE141J-473Y C RESISTOR
47K 5% 1/4W
R1896 QRE141J-473Y C RESISTOR
47K 5% 1/4W
TH731 QAD0012-202 BATTERY PACK
TH783 QAD0012-202 BATTERY PACK
TH784 QAD0012-202 BATTERY PACK
TH831 QAD0012-202 BATTERY PACK
TH832 QAD0012-202 BATTERY PACK
VR787 QVP0008-501Z SEMI V RESISTOR
VR788 QVP0008-501Z SEMI V RESISTOR
