RX-8020VBK

3-12

Item

Parts number Parts name Area

Electrical parts list (Input board)

Remarks

Block No. 04

C 201 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 202 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 203 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 204 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 205 QETN0JM-477Z E CAPACITOR

470MF 20% 6.3V

C 206 QETN1HM-475Z E CAPACITOR

4.7MF 20% 50V

C 207 QETN0JM-477Z E CAPACITOR

470MF 20% 6.3V

C 208 QETN1CM-476Z E CAPACITOR

47MF 20% 16V

C 209 QCF31HZ-103Z C CAPACITOR

.010MF +80:-20%

C 210 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 211 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 212 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 213 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%

C 214 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 215 QETN1HM-475Z E CAPACITOR

4.7MF 20% 50V

C 216 QDX31EM-473Z C CAPACITOR

C 217 QETN1AM-477Z E CAPACITOR

470MF 20% 10V

C 218 QCZ0202-155Z ML C CAPACITOR

1.5MF

C 219 QDC31HJ-150Z C CAPACITOR

C 220 QDC31HJ-100Z C CAPACITOR

C 221 QDC31HJ-470Z C CAPACITOR

C 222 QDC31HJ-270Z C CAPACITOR

C 223 NCB31HK-102X C CAPACITOR

C 224 NCS31HJ-271X C CAPACITOR

C 225 NCS31HJ-121X C CAPACITOR

C 226 NCS31HJ-470X C CAPACITOR

C 231 QETN1HM-475Z E CAPACITOR

4.7MF 20% 50V

C 241 QDX31EM-473Z C CAPACITOR

C 242 QETN1HM-475Z E CAPACITOR

4.7MF 20% 50V

C 244 QDX31EM-473Z C CAPACITOR

C 245 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 246 QDX31EM-473Z C CAPACITOR

C 247 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 249 QDX31EM-473Z C CAPACITOR

C 250 QETN1HM-475Z E CAPACITOR

4.7MF 20% 50V

C 251 QDX31EM-473Z C CAPACITOR

C 252 QETN0JM-477Z E CAPACITOR

470MF 20% 6.3V

C 253 NCS31HJ-100X C CAPACITOR

C 254 QDX31EM-473Z C CAPACITOR

C 255 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 256 QCF31HZ-103Z C CAPACITOR .010MF +80:-20%

C 257 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 258 QCF31HZ-103Z C CAPACITOR

.010MF +80:-20%

C 259 QETN1CM-476Z E CAPACITOR

47MF 20% 16V

C 260 QDX31EM-473Z C CAPACITOR

C 261 QETN1HM-475Z E CAPACITOR

4.7MF 20% 50V

C 268 NCS31HJ-470X C CAPACITOR

C 269 NCS31HJ-470X C CAPACITOR

C 270 NCS31HJ-101X C CAPACITOR

C 271 NCS31HJ-101X C CAPACITOR

C 272 QDX31EM-473Z C CAPACITOR

C 273 QDX31EM-473Z C CAPACITOR

C 274 QETN0JM-477Z E CAPACITOR

470MF 20% 6.3V

C 275 NCS31HJ-470X C CAPACITOR

C 276 NCS31HJ-470X C CAPACITOR

C 277 QETN1HM-475Z E CAPACITOR

4.7MF 20% 50V

C 280 NCS31HJ-470X C CAPACITOR

C 281 NCS31HJ-470X C CAPACITOR

C 282 NCS31HJ-470X C CAPACITOR

C 283 NCS31HJ-470X C CAPACITOR

C 284 NCS31HJ-470X C CAPACITOR

C 285 NCS31HJ-470X C CAPACITOR

C 286 NCS31HJ-470X C CAPACITOR

C 287 NCS31HJ-470X C CAPACITOR

C 301 QETN1HM-475Z E CAPACITOR

4.7MF 20% 50V

C 302 QETN1HM-475Z E CAPACITOR

4.7MF 20% 50V

C 303 NCS31HJ-101X C CAPACITOR

C 304 NCS31HJ-101X C CAPACITOR

C 305 QFLC1HJ-182Z M CAPACITOR 1800PF 5% 50V

C 306 QFLC1HJ-182Z M CAPACITOR 1800PF 5% 50V

C 307 QFLC1HJ-682Z M CAPACITOR

6800PF 5% 50V

C 308 QFLC1HJ-682Z M CAPACITOR

6800PF 5% 50V

C 309 NCS31HJ-101X C CAPACITOR

C 310 NCS31HJ-101X C CAPACITOR

C 311 QETN1HM-475Z E CAPACITOR

4.7MF 20% 50V

C 312 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 313 QETN1AM-107Z E CAPACITOR 100MF 20% 10V

C 314 QETN1AM-107Z E CAPACITOR 100MF 20% 10V

C 315 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 316 QETN1CM-476Z E CAPACITOR 47MF 20% 16V

C 321 NCB31HK-221X C CAPACITOR

C 322 NCB31HK-221X C CAPACITOR

C 323 NCB31HK-221X C CAPACITOR

EXCEPT J/C

C 324 NCB31HK-221X C CAPACITOR

EXCEPT J/C

C 325 NCB31HK-221X C CAPACITOR

EXCEPT J/C

C 326 NCB31HK-221X C CAPACITOR EXCEPT J/C

C 327 NCB31HK-221X C CAPACITOR EXCEPT J/C

C 328 NCB31HK-221X C CAPACITOR EXCEPT J/C

C 329 NCB31HK-221X C CAPACITOR EXCEPT J/C

C 330 NCB31HK-221X C CAPACITOR

EXCEPT J/C

C 331 NCB31HK-221X C CAPACITOR

EXCEPT J/C

C 332 NCB31HK-221X C CAPACITOR

EXCEPT J/C

C 333 NCB31HK-561X C CAPACITOR

C 334 NCB31HK-561X C CAPACITOR

C 335 QETN1EM-226Z E CAPACITOR

22MF 20% 25V

C 336 QETN1EM-226Z E CAPACITOR 22MF 20% 25V

C 339 NCB31HK-561X C CAPACITOR

C 341 QETN1HM-106Z E CAPACITOR 10MF 20% 50V

C 342 QETN1HM-106Z E CAPACITOR 10MF 20% 50V

C 343 QETN1HM-106Z E CAPACITOR

10MF 20% 50V

C 344 QETN1HM-106Z E CAPACITOR

10MF 20% 50V

C 361 QETN1HM-475Z E CAPACITOR

4.7MF 20% 50V

C 362 QETN1HM-475Z E CAPACITOR

4.7MF 20% 50V

C 363 QETN1HM-475Z E CAPACITOR

4.7MF 20% 50V

C 364 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 371 NCB31HK-221X C CAPACITOR EXCEPT J/C

C 372 NCB31HK-221X C CAPACITOR EXCEPT J/C

C 373 NCB31HK-221X C CAPACITOR EXCEPT J/C

C 374 NCB31HK-221X C CAPACITOR

EXCEPT J/C

C 375 NCB31HK-221X C CAPACITOR

EXCEPT J/C

C 376 NCB31HK-221X C CAPACITOR

EXCEPT J/C

C 377 NCB31HK-221X C CAPACITOR

EXCEPT J/C

C 378 NCB31HK-221X C CAPACITOR

EXCEPT J/C

C 379 NCB31HK-221X C CAPACITOR

EXCEPT J/C

C 380 NCB31HK-221X C CAPACITOR EXCEPT J/C

C 381 NCB31HK-221X C CAPACITOR EXCEPT J/C

C 382 NCB31HK-221X C CAPACITOR EXCEPT J/C

C 385 QETN1EM-226Z E CAPACITOR 22MF 20% 25V

C 386 QETN1EM-226Z E CAPACITOR

22MF 20% 25V

C 389 NCB31HK-561X C CAPACITOR

C 391 QETN1HM-106Z E CAPACITOR

10MF 20% 50V

C 392 QETN1HM-106Z E CAPACITOR

10MF 20% 50V

C 393 NCB31HK-122X C CAPACITOR

C 394 NCB31HK-122X C CAPACITOR

C 395 NCS31HJ-121X C CAPACITOR

C 396 NCS31HJ-121X C CAPACITOR

C 397 QETN1HM-106Z E CAPACITOR 10MF 20% 50V

C 398 QETN1HM-106Z E CAPACITOR

10MF 20% 50V

CN200 QGB2510K1-11 CONNECTOR

CN204 QGB1214K1-08S CONNECTOR

CN205 QGB1214J1-08S CONNECTOR

CN206 QGA2501F1-02 CONNECTOR
