JVC RX-8020VBK

RX-8020VBK
3-13
Item
Parts number Parts name Area
Electrical parts list (Input board)
Remarks
Block No. 04
A
CN240 QGB2510K1-12 CONNECTOR
CN242 QGB1214K1-10S CONNECTOR
CN243 QGB1214J1-10S CONNECTOR
CN244 QGA2501F1-04 CONNECTOR
CN311 QGB2510K1-11 CONNECTOR
CN313 QGB2510K1-12 CONNECTOR
CN351 QGB1214K1-14S CONNECTOR
CN361 QGB1214J1-14S CONNECTOR
CN371 QGB1214K1-12S 01F
CN381 QGB1214J1-12S CONNECTOR
CN393 QGA2501F1-03 CONNECTOR
CN416 QGA2501F1-06 CONNECTOR
CN501 QGB1214J1-14S CONNECTOR
CN731 QJP001-032301 SHI CR C-B WIRE
CN732 WJP0038-001A CONNECTOR
C1301 QETN1EM-476Z E CAPACITOR
47MF 20% 25V
C1302 QETN1EM-476Z E CAPACITOR
47MF 20% 25V
C1303 NCB31HK-221X C CAPACITOR
C1309 QENC1HM-106Z NP E CAPACITOR
10MF 20% 50V
C1310 QETN1CM-226Z E CAPACITOR 22MF 20% 16V
C1311 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1312 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1313 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1314 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1315 QER61HM-224Z E CAPACITOR
.22MF 20% 50V
C1316 QER61HM-224Z E CAPACITOR
.22MF 20% 50V
C1319 NCB31HK-221X C CAPACITOR
C1321 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1322 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1323 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1324 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1325 QER61HM-224Z E CAPACITOR .22MF 20% 50V
C1326 QER61HM-224Z E CAPACITOR .22MF 20% 50V
C1329 NCB31HK-221X C CAPACITOR
C1331 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1332 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1333 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1334 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1339 NCB31HK-221X C CAPACITOR
C1341 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1342 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1343 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1344 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1349 NCB31HK-221X C CAPACITOR
C1350 NCB31HK-221X C CAPACITOR
C1351 NCB31HK-221X C CAPACITOR
C1352 NCB31HK-221X C CAPACITOR
C1360 NCB31EK-223X C CAPACITOR
C1361 NCS31HJ-391X C CAPACITOR J/C/UJ
C1362 NCS31HJ-391X C CAPACITOR J/C/UJ
C1363 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1364 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1365 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1366 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1370 QETN1EM-476Z E CAPACITOR
EXCEPT E/EN
C1371 QETN1EM-476Z E CAPACITOR
EXCEPT E/EN
C1372 NCB31HK-103X C CAPACITOR
EXCEPT E/EN
C1373 QETN1EM-476Z E CAPACITOR EXCEPT E/EN
C1374 NCB31HK-103X C CAPACITOR EXCEPT E/EN
C1375 QETN1EM-226Z E CAPACITOR EXCEPT E/EN
C1376 QETN1CM-226Z E CAPACITOR EXCEPT E/EN
C1377 QETN1EM-226Z E CAPACITOR
EXCEPT E/EN
C1379 QETN1EM-226Z E CAPACITOR
EXCEPT E/EN
C1381 NCS31HJ-470X C CAPACITOR
EXCEPT E/EN
C1382 NCS31HJ-470X C CAPACITOR
EXCEPT E/EN
C1383 NCS31HJ-470X C CAPACITOR
EXCEPT E/EN
C1384 QETN1EM-476Z E CAPACITOR EXCEPT E/EN
C1385 QETN1HM-475Z E CAPACITOR EXCEPT E/EN
C1386 QETN1HM-475Z E CAPACITOR EXCEPT E/EN
C1387 NCS31HJ-470X C CAPACITOR EXCEPT E/EN
C1388 NCS31HJ-470X C CAPACITOR
EXCEPT E/EN
C1389 NCS31HJ-470X C CAPACITOR
EXCEPT E/EN
C1390 QETN1EM-476Z E CAPACITOR
EXCEPT E/EN
C1391 QETN1HM-475Z E CAPACITOR
EXCEPT E/EN
C1392 QETN1HM-475Z E CAPACITOR
EXCEPT E/EN
C1393 NCS31HJ-101X C CAPACITOR EXCEPT E/EN
C1394 NCS31HJ-101X C CAPACITOR EXCEPT E/EN
C1395 NCS31HJ-101X C CAPACITOR EXCEPT E/EN
C1396 QETN0JM-477Z E CAPACITOR EXCEPT E/EN
C1397 QETN1AM-107Z E CAPACITOR EXCEPT E/EN
C1398 QETN1AM-107Z E CAPACITOR
EXCEPT E/EN
C1411 QETN1HM-106Z E CAPACITOR
10MF 20% 50V
C1412 QETN1HM-106Z E CAPACITOR
10MF 20% 50V
C1413 QETN1HM-106Z E CAPACITOR
10MF 20% 50V
C1414 QETN1HM-106Z E CAPACITOR
10MF 20% 50V
C1428 QETN1CM-226Z E CAPACITOR 22MF 20% 16V
C1431 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1432 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C1433 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1434 QETN1HM-106Z E CAPACITOR
10MF 20% 50V
C1439 QETN1EM-476Z E CAPACITOR
47MF 20% 25V
C1440 QETN1EM-476Z E CAPACITOR
47MF 20% 25V
C1448 QETN1CM-226Z E CAPACITOR
22MF 20% 16V
C1451 QETN1HM-106Z E CAPACITOR
10MF 20% 50V
C1452 QETN1HM-106Z E CAPACITOR
10MF 20% 50V
C1453 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C1454 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C1468 QETN1CM-226Z E CAPACITOR 22MF 20% 16V
C1471 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C1472 QETN1HM-106Z E CAPACITOR
10MF 20% 50V
C1473 QETN1HM-106Z E CAPACITOR
10MF 20% 50V
C1474 QETN1HM-106Z E CAPACITOR
10MF 20% 50V
C1486 QETN1CM-226Z E CAPACITOR
22MF 20% 16V
C1487 QETN1CM-226Z E CAPACITOR
22MF 20% 16V
C1491 NCB31HK-331X C CAPACITOR
C1492 NCB31HK-331X C CAPACITOR
C1493 NCB31HK-331X C CAPACITOR
C1494 NCB31HK-331X C CAPACITOR
C1495 NCB31HK-331X C CAPACITOR
C1496 NCB31HK-331X C CAPACITOR
C1497 NCB31HK-331X C CAPACITOR
C1498 NCB31HK-331X C CAPACITOR
D 200 1SS355-X DIODE
D 201 1SS355-X DIODE
D 240 1SS355-X DIODE
D 241 1SS355-X DIODE
D1350 MA3062/H/-X ZENER DIODE EXCEPT E/EN
D1428 1SS355-X DIODE
D1429 1SS355-X DIODE
D1448 1SS355-X DIODE
D1449 1SS355-X DIODE
D1468 1SS355-X DIODE
D1469 1SS355-X DIODE
D1486 1SS355-X DIODE
D1487 1SS355-X DIODE
D1488 1SS355-X DIODE
D1489 1SS355-X DIODE
HL203 VYH7653-005 IC HOLDER
IC201 BA7625 IC
IC202 NJM2285V-W IC
IC203 MB90088PF-131 IC
IC241 BA7626 IC
Item
Parts number Parts name Area
Remarks
A
