JVC RX-8020VBK

RX-8020VBK
3-14
Item
Parts number Parts name Area
Electrical parts list (Input board)
Remarks
Block No. 04
A
IC242 BA7625 IC
IC301 NJM4580D-D IC
IC302 TC9164AF-X IC
IC303 BA15218F-XE IC
IC304 BA15218F-XE IC
IC371 TC9163AF-X IC
IC372 BA15218F-XE IC
IC380 TC9162AF-X IC
IC381 TC9459F-X IC
IC382 TC9459F-X IC
IC383 TC9459F-X IC
IC384 TC9459F-X IC
IC386 BA15218F-XE IC
IC388 TC74HC4053AF-X I.C EXCEPT E/EN
IC389 TC74HC4053AF-X I.C
EXCEPT E/EN
IC390 NJM2580M-X I.C
EXCEPT E/EN
IC396 BA15218F-XE IC
IC397 BA15218F-XE IC
IC398 BA15218F-XE IC
IC399 BA15218F-XE IC
J 201 QNN0078-001 PIN JACK
J 202 QNN0011-001 PIN JACK
J 203 QNN0011-001 PIN JACK
J 241 QND0097-001 S-CONNECTOR
J 242 QND0098-001 DIN CONNECTOR
J 243 QND0099-001 S JACK
J 301 QNN0056-001 PIN JACK
J 302 QNN0056-001 PIN JACK
J 303 QNN0058-001 PIN JACK
J 371 QNN0056-001 PIN JACK
J 372 QNN0056-001 PIN JACK
J 373 QNN0056-001 PIN JACK
J1350 QNS0089-001 3.5 JACK
J1351 QNS0077-001 3.5 JACK
J1352 QNS0089-001 3.5 JACK
EXCEPT E/EN
J1360 QNN0483-001 PIN JACK
J1380 QNN0391-001 PIN JACK
EXCEPT E/EN
J1490 QNN0484-001 PIN JACK
J1491 QNN0485-001 PIN JACK
L 200 NQL085J-220X INDUCTOR
Q
200 KTA1267/YG/-T TRANSISTOR
Q
201 KTA1267/YG/-T TRANSISTOR
Q
202 KRC110M-T TR
Q
203 KRC107M-T D.TRANSISTOR
Q
204 KTA1267/YG/-T TRANSISTOR
Q
205 KTA1267/YG/-T TRANSISTOR
Q
206 KTA1267/YG/-T TRANSISTOR
Q
207 KTA1267/YG/-T TRANSISTOR
Q 208 DTC123YSA-T D.TRANSISTOR
Q
240 KTA1267/YG/-T TRANSISTOR
Q
241 KTA1267/YG/-T TRANSISTOR
Q
242 KTA1267/YG/-T TRANSISTOR
Q
243 KTA1267/YG/-T TRANSISTOR
Q
244 KRC110M-T TRANSISTOR
Q
245 KRC110M-T TRANSISTOR
Q
246 KRC107M-T D.TRANSISTOR
Q
247 KRC107M-T D.TRANSISTOR
Q1310 KRA104S-X DIGITAL.TR
Q
1313 2SC3576-JVC-T TRANSISTOR
Q
1314 2SC3576-JVC-T TRANSISTOR
Q
1324 2SC3576-JVC-T TRANSISTOR
Q
1333 2SC3576-JVC-T TRANSISTOR
Q
1334 2SC3576-JVC-T TRANSISTOR
Q
1421 2SC3576-JVC-T TRANSISTOR
Q
1422 2SC3576-JVC-T TRANSISTOR
Q
1428 KRC107S-X DIGITAL.TR
Q1429 KRA104S-X DIGITAL.TR
Q
1441 2SC3576-JVC-T TRANSISTOR
Q
1442 2SC3576-JVC-T TRANSISTOR
Q
1445 2SC3576-JVC-T TRANSISTOR
Q
1447 KRA104S-X DIGITAL.TR
Q
1448 KRC107S-X DIGITAL.TR
Q
1449 KRA104S-X DIGITAL.TR
Q
1461 2SC3576-JVC-T TRANSISTOR
Q
1462 2SC3576-JVC-T TRANSISTOR
Q1468 KRC107S-X DIGITAL.TR
Q1469 KRA104S-X DIGITAL.TR
Q
1481 2SC3576-JVC-T TRANSISTOR
Q
1482 2SC3576-JVC-T TRANSISTOR
Q
1486 KRA104S-X DIGITAL.TR
Q
1487 KRA104S-X DIGITAL.TR
R 200 NRSA63J-750X MG RESISTOR
R 201 NRSA63J-750X MG RESISTOR
R 202 NRSA63J-750X MG RESISTOR
R 203 NRSA63J-750X MG RESISTOR
R 204 NRSA63J-750X MG RESISTOR
R 205 NRSA63J-750X MG RESISTOR
R 206 NRSA63J-750X MG RESISTOR
R 207 NRSA63J-331X MG RESISTOR
R 208 NRSA63J-331X MG RESISTOR
R 209 NRSA63J-473X MG RESISTOR
R 210 NRSA63J-331X MG RESISTOR
R 211 NRSA63J-473X MG RESISTOR
R 212 NRSA63J-331X MG RESISTOR
R 213 NRSA63J-473X MG RESISTOR
R 214 NRSA63J-151X MG RESISTOR
R 215 NRSA63J-151X MG RESISTOR
R 216 NRSA63J-301X MG RESISTOR
R 217 NRSA63J-103X MG RESISTOR
R 218 NRSA63J-331X MG RESISTOR
R 219 NRSA63J-101X MG RESISTOR
R 220 NRSA63J-151X MG RESISTOR
R 221 NRSA63J-181X MG RESISTOR
R 222 NRSA63J-561X MG RESISTOR
R 223 NRSA63J-561X MG RESISTOR
R 224 NRSA63J-561X MG RESISTOR
R 225 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R 231 NRSA63J-222X MG RESISTOR
R 232 NRSA63J-470X MG RESISTOR
R 240 NRSA63J-750X MG RESISTOR
R 241 NRSA63J-750X MG RESISTOR
R 242 NRSA63J-750X MG RESISTOR
R 243 NRSA63J-750X MG RESISTOR
R 244 NRSA63J-750X MG RESISTOR
R 245 NRSA63J-750X MG RESISTOR
R 246 NRSA63J-750X MG RESISTOR
R 247 NRSA63J-750X MG RESISTOR
R 248 NRSA63J-181X MG RESISTOR
R 249 NRSA63J-151X MG RESISTOR
R 250 NRSA63J-181X MG RESISTOR
R 251 NRSA63J-151X MG RESISTOR
R 253 NRSA63J-153X MG RESISTOR
R 254 NRSA63J-153X MG RESISTOR
R 255 NRSA63J-153X MG RESISTOR
R 266 NRSA63J-750X MG RESISTOR
R 267 NRSA63J-473X MG RESISTOR
R 268 NRSA63J-750X MG RESISTOR
R 269 NRSA63J-473X MG RESISTOR
R 271 QRJ146J-3R3X UNF C RESISTOR
A
3.3 5% 1/4W
R 272 NRSA63J-750X MG RESISTOR
R 273 NRSA63J-473X MG RESISTOR
R 274 NRSA63J-750X MG RESISTOR
Item
Parts number Parts name Area
Remarks
A
