JVC RX-8020VBK

RX-8020VBK
3-17
Item
Parts number Parts name Area
Electrical parts list (DSP board)
Remarks
Block No. 05
A
C 571 NCB31HK-103X C CAPACITOR
C 572 NEA70GM-107X E CAPACITOR
C 573 NCF31CZ-104X C CAPACITOR
C 577 NCS31HJ-101X C CAPACITOR
C 579 NCS31HJ-101X C CAPACITOR
C 581 NEA71CM-106X E.CAPACITOR
C 582 NEA71CM-106X E.CAPACITOR
C 583 NEA70JM-476X E.CAPACITOR
C 584 NCF31AZ-105X C CAPACITOR
C 587 NCF31CZ-104X C CAPACITOR
C 588 NEA70JM-227X E CAPACITOR
C 589 NCF31CZ-104X C CAPACITOR
C 590 NEA70GM-107X E CAPACITOR
CN581 QGB1214K1-14S CONNECTOR
CN587 QGB2510K1-07 CONNECTOR
C2001 NCB31HK-182X C CAPACITOR
C2002 NCB31HK-182X C CAPACITOR
C2003 NCB31HK-682X C CAPACITOR
C2004 NCB31HK-682X C CAPACITOR
C2005 NCF31CZ-104X C CAPACITOR
C2006 NCF31CZ-104X C CAPACITOR
C2007 NCB31HK-272X C CAPACITOR
C2008 NCB31HK-272X C CAPACITOR
C2009 NEA71EM-475X E.CAPACITOR.
C2010 NEA71EM-475X E.CAPACITOR.
C2011 NEA71EM-475X E.CAPACITOR.
C2012 NEA71EM-475X E.CAPACITOR.
C2101 NCB31HK-102X C CAPACITOR
C2107 NEA71EM-475X E.CAPACITOR.
C2127 NCF31CZ-104X C CAPACITOR
C2128 NCF31CZ-104X C CAPACITOR
C2130 NEA71HM-475X E.CAPACITOR.
C2131 NCB31CK-823X C CAPACITOR
C2132 NFV41HJ-333X C CAPACITOR
C2152 NCF31CZ-104X C CAPACITOR
C2153 NCF31CZ-104X C CAPACITOR
C2154 NCB31CK-823X C CAPACITOR
C2155 NFV41HJ-333X C CAPACITOR
C2181 NCS31HJ-330X C CAPACITOR
C2182 NEA71EM-475X E.CAPACITOR.
C2201 NCB31HK-272X C CAPACITOR
C2202 NCB31HK-272X C CAPACITOR
C2207 NEA71HM-475X E.CAPACITOR.
C2208 NEA71HM-475X E.CAPACITOR.
C2211 NCB31HK-102X C CAPACITOR
C2212 NCB31HK-102X C CAPACITOR
C2213 NCF31CZ-104X C CAPACITOR
C2214 NCF31CZ-104X C CAPACITOR
C2215 NCB31HK-103X C CAPACITOR
C2216 NCB31HK-103X C CAPACITOR
C2230 NEA71HM-475X E.CAPACITOR.
C2237 NCS31HJ-330X C CAPACITOR
C2238 NCS31HJ-330X C CAPACITOR
C2251 NCF31CZ-104X C CAPACITOR
C2252 NCF31CZ-104X C CAPACITOR
C2255 NCF31CZ-104X C CAPACITOR
C2256 NCF31CZ-104X C CAPACITOR
C2261 NEA71EM-475X E.CAPACITOR.
C2262 NEA71EM-475X E.CAPACITOR.
C2281 NEA71EM-475X E.CAPACITOR.
C2282 NEA71EM-475X E.CAPACITOR.
C2283 NCS31HJ-330X C CAPACITOR
C2284 NCS31HJ-330X C CAPACITOR
C2285 NCS31HJ-471X C CAPACITOR
C2286 NCS31HJ-471X C CAPACITOR
C2287 NCF31CZ-104X C CAPACITOR
C2288 NCF31CZ-104X C CAPACITOR
C2289 NCS31HJ-471X C CAPACITOR
C2290 NCS31HJ-471X C CAPACITOR
C2291 NCB31HK-332X C CAPACITOR
C2292 NCB31HK-332X C CAPACITOR
C2301 NCB31HK-102X C CAPACITOR
C2302 NCB31HK-102X C CAPACITOR
C2307 NEA71HM-225X E.CAPACITOR.
C2308 NEA71HM-225X E.CAPACITOR.
C2351 NEA71HM-105X E.CAPACITOR.
C2352 NEA71HM-105X E.CAPACITOR.
C2353 NCS31HJ-330X C CAPACITOR
C2354 NCS31HJ-330X C CAPACITOR
C2355 NCF31CZ-104X C CAPACITOR
C2356 NCF31CZ-104X C CAPACITOR
C2357 NEA71HM-225X E.CAPACITOR.
C2358 NEA71HM-225X E.CAPACITOR.
C2359 NCS31HJ-821X C CAPACITOR
C2360 NCS31HJ-821X C CAPACITOR
C2401 NCB31HK-102X C CAPACITOR
C2407 NEA71HM-225X E.CAPACITOR.
C2431 NCF31CZ-104X C CAPACITOR
C2432 NCF31CZ-104X C CAPACITOR
C2433 NCS31HJ-330X C CAPACITOR
C2434 NEA71HM-225X E.CAPACITOR.
C2435 NCS31HJ-821X C CAPACITOR
C2481 NEA70JM-476X E.CAPACITOR
C2501 NCB31HK-123X C CAPACITOR
C2502 NCB31HK-103X C CAPACITOR
C2503 NCB31HK-103X C CAPACITOR
C2504 NCB31HK-103X C CAPACITOR
C2505 NCB31HK-103X C CAPACITOR
C2506 NCB31HK-103X C CAPACITOR
C2507 NCB31HK-103X C CAPACITOR
C2508 NCB31HK-103X C CAPACITOR
C2509 NCB31HK-103X C CAPACITOR
C2510 NCB31HK-103X C CAPACITOR
C2511 NCB31HK-103X C CAPACITOR
C2512 NCB31HK-103X C CAPACITOR
C2513 NCB31HK-103X C CAPACITOR
C2514 NCB31HK-103X C CAPACITOR
C2515 NCB31HK-103X C CAPACITOR
C2516 NCB31HK-103X C CAPACITOR
C2517 NCB31HK-103X C CAPACITOR
C2518 NCB31HK-103X C CAPACITOR
C2519 NCB31HK-103X C CAPACITOR
C2520 NCB31HK-103X C CAPACITOR
C2521 NCB31HK-103X C CAPACITOR
C2522 NCB31HK-103X C CAPACITOR
C2523 NCF31CZ-104X C CAPACITOR
C2529 NEA70GM-107X E CAPACITOR
C2530 NCF31CZ-104X C CAPACITOR
C2531 NCF31CZ-104X C CAPACITOR
C2532 NEA70GM-107X E CAPACITOR
C2533 NCF31CZ-104X C CAPACITOR
C2534 NCF31CZ-104X C CAPACITOR
C2535 NEA70GM-107X E CAPACITOR
C2536 NCF31CZ-104X C CAPACITOR
C2537 NEA70GM-107X E CAPACITOR
C2560 NCF31CZ-104X C CAPACITOR
C2561 NCF31CZ-104X C CAPACITOR
C2562 NCF31CZ-104X C CAPACITOR
C2563 NCF31CZ-104X C CAPACITOR
C2564 NCS31HJ-101X C CAPACITOR
C2565 NCF31CZ-104X C CAPACITOR
C2566 NCF31CZ-104X C CAPACITOR
