JVC RX-8020VBK

RX-8020VBK
3-18
Item
Parts number Parts name Area
Electrical parts list (DSP board)
Remarks
Block No. 05
A
C2567 NCF31CZ-104X C CAPACITOR
C2568 NEA71HM-105X E.CAPACITOR.
C2571 NCF31CZ-104X C CAPACITOR
C2572 NEA70GM-107X E CAPACITOR
C2573 NCF31CZ-104X C CAPACITOR
C2574 NEA70GM-107X E CAPACITOR
C2575 NCF31CZ-104X C CAPACITOR
C2576 NEA70GM-107X E CAPACITOR
C2605 NCF31AZ-105X C CAPACITOR
C2607 NCS31HJ-221X C CAPACITOR
C2701 NCS31HJ-270X C CAPACITOR
C2702 NCS31HJ-270X C CAPACITOR
C2703 NEA71CM-106X E.CAPACITOR
C2704 NEA71CM-106X E.CAPACITOR
C2705 NCF31CZ-104X C CAPACITOR
C2706 NCF31CZ-104X C CAPACITOR
C2707 NEA71CM-106X E.CAPACITOR
C2708 NEA71HM-225X E.CAPACITOR
C2709 NCF31CZ-104X C CAPACITOR
C2710 NCF31CZ-104X C CAPACITOR
C2711 NEA71CM-106X E.CAPACITOR
C2712 NCF31CZ-104X C CAPACITOR
C2751 NEA71CM-106X E.CAPACITOR
C2752 NCF31CZ-104X C CAPACITOR
C2801 NCB31HK-102X C CAPACITOR
C2802 NCB31HK-102X C CAPACITOR
C2807 NEA71HM-225X E.CAPACITOR.
C2808 NEA71HM-225X E.CAPACITOR.
C2853 NCS31HJ-330X C CAPACITOR
C2854 NCS31HJ-330X C CAPACITOR
C2855 NCF31CZ-104X C CAPACITOR
C2856 NCF31CZ-104X C CAPACITOR
C2857 NEA71HM-225X E.CAPACITOR.
C2858 NEA71HM-225X E.CAPACITOR.
C2859 NCS31HJ-821X C CAPACITOR
C2860 NCS31HJ-821X C CAPACITOR
EP561 E409182-001SM GRAND TERMINAL
IC501 DSPC56367PV150 IC
IC502 TC7S04FU-X IC
IC503 TC7S04FU-X IC
IC505 PQ070XZ1HZ-X IC
IC506 PQ070XZ1HZ-X IC
IC511 39VF0207CWHP02 IC
IC512 IS63LV102410K-X IC
IC513 IS63LV102410K-X IC
IC514 IS63LV102410K-X IC
IC521 BA15218F-XE IC
IC522 BA15218F-XE IC
IC523 BA15218F-XE IC
IC524 BA15218F-XE IC
IC525 BA15218F-XE IC
IC526 BA15218F-XE IC
IC527 NJM2121M-X IC
IC528 BA15218F-XE IC
IC529 BA15218F-XE IC
IC530 BA15218F-XE IC
IC571 AK4586VQ IC
IC572 AK4382AVT-X IC
IC581 UPD784215AGC188 IC(MICRO C ROM) FLASH
IC582 TC7SET32FU-X IC
IC583 PQ070XZ1HZ-X IC
J 564 QNN0347-001 PIN JACK
K2606 NQR0269-004X FERRITE BEADS
LC505 NQR0450-001X EMI FILTER
LC506 NQR0450-001X EMI FILTER
LC507 NQR0450-001X EMI FILTER
PW503 QUB220-08HPHP SIN TWIST WIRE TO PW504
Q
570 DTC114YE-X TRANSISTOR
Q
572 DTC114YE-X TRANSISTOR
Q
2101 2SD1328/ST/-X TRANSISTOR
Q
2131 2SD1328/ST/-X TRANSISTOR
Q
2151 DTA114YE-X TRANSISTOR
Q
2152 DTC114YE-X TRANSISTOR
Q
2154 DTA114YE-X TRANSISTOR
Q
2155 DTA114YE-X TRANSISTOR
Q2156 DTA114YE-X TRANSISTOR
Q2157 DTA114YE-X TRANSISTOR
Q
2201 2SD1328/ST/-X TRANSISTOR
Q
2202 2SD1328/ST/-X TRANSISTOR
Q
2273 2SC2412K/RS/-X CHIP TRANSISTOR
Q
2274 2SC2412K/RS/-X CHIP TRANSISTOR
Q
2301 2SD1328/ST/-X TRANSISTOR
Q
2302 2SD1328/ST/-X TRANSISTOR
Q
2363 2SD1328/ST/-X TRANSISTOR
Q
2364 2SD1328/ST/-X TRANSISTOR
Q2401 2SD1328/ST/-X TRANSISTOR
Q
2431 2SC2412K/RS/-X CHIP TRANSISTOR
Q
2801 2SD1328/ST/-X TRANSISTOR
Q
2802 2SD1328/ST/-X TRANSISTOR
R 570 NRSA63J-103X MG RESISTOR
R 573 NRSA63J-432X MG RESISTOR
R 574 NRSA63J-432X MG RESISTOR
R 575 NRSA63J-432X MG RESISTOR
R 576 NRSA63J-432X MG RESISTOR
R 577 NRSA63J-822X MG RESISTOR
R 578 NRSA63J-822X MG RESISTOR
R 579 NRSA63J-822X MG RESISTOR
R 580 NRSA63J-822X MG RESISTOR
R 582 NRSA63J-103X MG RESISTOR
R 585 NRSA63J-103X MG RESISTOR
R 586 NRSA63J-103X MG RESISTOR
R 587 NRSA63J-103X MG RESISTOR
R 588 NRSA63J-103X MG RESISTOR
R 589 NRSA63F-202X MG RESISTOR
R 590 NRSA63F-122X MG RESISTOR
R2001 NRSA63J-104X MG RESISTOR
R2002 NRSA63J-104X MG RESISTOR
R2003 NRSA63J-102X MG RESISTOR
R2004 NRSA63J-102X MG RESISTOR
R2005 NRSA63J-102X MG RESISTOR
R2006 NRSA63J-102X MG RESISTOR
R2007 NRSA63J-102X MG RESISTOR
R2008 NRSA63J-102X MG RESISTOR
R2101 NRSA63J-103X MG RESISTOR
R2105 NRSA63J-102X MG RESISTOR
R2107 NRSA63J-104X MG RESISTOR
R2127 NRSA63J-473X MG RESISTOR
R2128 NRSA63J-473X MG RESISTOR
R2129 NRSA63J-100X MG RESISTOR
R2130 NRSA63J-222X MG RESISTOR
R2131 NRSA63J-103X MG RESISTOR
R2132 NRSA63J-103X MG RESISTOR
R2133 NRSA63J-103X MG RESISTOR
R2151 NRSA63J-100X MG RESISTOR
R2152 NRSA63J-103X MG RESISTOR
R2153 NRSA63J-103X MG RESISTOR
R2181 NRSA63J-513X MG RESISTOR
R2182 NRSA63J-822X MG RESISTOR
R2183 NRSA63J-104X MG RESISTOR
R2191 NRSA63J-105X MG RESISTOR
R2194 NRSA63J-105X MG RESISTOR
R2195 NRSA63J-105X MG RESISTOR
