JVC RX-8020VBK

RX-8020VBK
3-21
Item
Parts number Parts name Area
Electrical parts list (Micon board)
Remarks
Block No. 06
A
C 1 QCZ9104-472 C.CAPACITOR
A
4700PF
C 51 QFLC2AJ-472Z M CAPACITOR 4700PF 5% 100V
C 52 QETM1JM-477 E CAPACITOR UJ
C 53 QCF31HZ-472Z C CAPACITOR UJ ONLY
C 54 QETN1CM-477Z E CAPACITOR
470MF 20% 16V
C 55 QCF31HZ-472Z C CAPACITOR
4700PF +80:-20%
C 61 QFLC2AJ-104Z M CAPACITOR
.10MF 5% 100V
C 62 QFLC2AJ-104Z M CAPACITOR
.10MF 5% 100V
C 63 QFLC2AJ-104Z M CAPACITOR
.10MF 5% 100V
C 65 QETM1VM-338 E CAPACITOR 3300MF 20% 35V
C 66 QETM1VM-108 E.CAPACITOR 1000MF 20% 35V
C 68 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 69 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 70 QETN1HM-227Z E CAPACITOR 220MF 20% 50V
C 71 QETN1JM-107Z E CAPACITOR
100MF 20% 63V
C 72 QETN1HM-226Z E CAPACITOR
22MF 20% 50V
C 73 QETN1HM-226Z E CAPACITOR
22MF 20% 50V
C 74 QETN1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 91 QCBB1HK-471Y C CAPACITOR
EXCEPT J/C
C 92 QCBB1HK-471Y C CAPACITOR EXCEPT J/C
C 901 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 902 QCZ0202-155Z ML C CAPACITOR 1.5MF
C 903 QETN0JM-228Z E CAPACITOR 2200MF 20% 6.3V
C 904 QETN1HM-225Z E CAPACITOR
2.2MF 20% 50V
C 905 QDVB1EZ-223Y C CAPACITOR
C 921 QETN1EM-107Z E CAPACITOR
100MF 20% 25V
C 922 QCF31HZ-472Z C CAPACITOR
4700PF +80:-20%
C 931 QETN1CM-477Z E CAPACITOR
470MF 20% 16V
C 932 QCF31HZ-472Z C CAPACITOR
4700PF +80:-20%
C 941 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C 942 QCF31HZ-472Z C CAPACITOR 4700PF +80:-20%
C 951 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C 952 QCF31HZ-472Z C CAPACITOR 4700PF +80:-20%
C 961 QETN1EM-107Z E CAPACITOR
100MF 20% 25V
C 962 QCF31HZ-472Z C CAPACITOR
4700PF +80:-20%
C 971 QETN1EM-107Z E CAPACITOR
100MF 20% 25V
C 972 QCF31HZ-472Z C CAPACITOR
4700PF +80:-20%
C 975 QETN0JM-477Z E CAPACITOR
470MF 20% 6.3V
C 981 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 982 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 983 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 984 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 985 QCBB1HK-103Y C CAPACITOR
.010MF 10% 50V
C 991 QFLC1HJ-562Z M CAPACITOR
5600PF 5% 50V
C 992 QFLC1HJ-562Z M CAPACITOR
5600PF 5% 50V
C 993 QCBB1HK-101Y C CAPACITOR
100PF 10% 50V
C 994 QCBB1HK-271Y C CAPACITOR
270PF 10% 50V
CN 55 QGD2504C1-03Z SOCKET
CN 56 QGD2504C1-04Z SOCKET
CN 71 QGB2510J1-11 CONNECTOR
CN 81 QGB2510J1-09 CONNECTOR
CN101 QGB2501J1-12 CONNECTOR
CN201 QGB2510J1-11 CONNECTOR
CN241 QGB2510J1-12 CONNECTOR
CN301 QGB2510J1-11 CONNECTOR
CN303 QGB2510J1-12 CONNECTOR
CN400 QGF1205C1-10 CONNECTOR
CN402 QGF1205C1-08 CONNECTOR
CN601 QGB2510J1-07 CONNECTOR
CN811 QGA3901F2-03 CONNECTOR
CN931 QGD2504C1-04Z SOCKET
CN932 QGD2504C1-03Z SOCKET
CN933 WJP0041-001A E-SH C WIRE C-B
D 51 11ES2-T4 DIODE
D 52 11ES2-T4 DIODE
D 53 11ES2-T4 DIODE
D 54 11ES2-T4 DIODE
D 55 MTZJ12C-T2 ZENER DIODE UJ ONLY
D 56 MTZJ6.2B-T2 ZENER DIODE
D 57 1SS133-T2 SI DIODE
D 61 10E2-FD DIODE
D 62 11ES2-T4 DIODE
D 63 10E2-FD DIODE
D 64 11ES2-T4 DIODE
D 71 11ES2-T4 DIODE
D 72 11ES2-T4 DIODE
D 73 11ES2-T4 DIODE
D 74 MTZJ33C-T2 Z DIODE
D 75 MTZJ8.2C-T2 ZENER DIODE
D 900 11ES2-T4 DIODE
D 901 11ES2-T4 DIODE
D 902 11ES2-T4 DIODE
D 904 1SS133-T2 SI DIODE
D 921 MTZJ5.6C-T2 ZENER DIODE
D 931 MTZJ6.2C-T2 Z DIODE
D 941 MTZJ5.6C-T2 ZENER DIODE
D 951 MTZJ13C-T2 ZENER DIODE
D 955 1SS133-T2 SI DIODE
D 956 1SS133-T2 SI DIODE
D 961 MTZJ13C-T2 ZENER DIODE
D 971 MTZJ10C-T2 Z.DIODE
D 975 1SS133-T2 SI DIODE
D 976 1SS133-T2 SI DIODE
D 977 1SS133-T2 SI DIODE
D 978 1SS133-T2 SI DIODE
D 979 1SS133-T2 SI DIODE
D 993 1SS133-T2 SI DIODE
EP 1 E409182-001SM GRAND TERMINAL
EP 51 QNZ0136-001Z EARTH PLATE
EP 91 E406523-001SM GND BKT
EP901 QNZ0136-001Z EARTH PLATE
FC 1 QNG0020-001Z FUSE CLIP
F001
FC 2 QNG0020-001Z FUSE CLIP
F001
FC 3 QNG0020-001Z FUSE CLIP
F002
FC 4 QNG0020-001Z FUSE CLIP F002
FC 5 QNG0020-001Z FUSE CLIP F004
FC 6 QNG0020-001Z FUSE CLIP F004
FC 61 QNG0020-001Z FUSE CLIP F061
FC 62 QNG0020-001Z FUSE CLIP
F061
FC 63 QNG0020-001Z FUSE CLIP
F062
FC 64 QNG0020-001Z FUSE CLIP
F062
FL991 QQR0590-001 FILTER
FL992 QQR0590-001 FILTER
FW 51 QUM137-10DGZ4 PARA RIBON WIRE
FW831 QUM134-08DGZ4 PARA RIBON WIRE
FW881 QUM213-44DGZ4 SEMI V RESISTOR
HL901 VYH7237-002 IC HOLDER
HS 51 E70945-H40B HEAT SINK UJ ONLY
HS921 E70945-H40B HEAT SINK
HS931 E70945-H40B HEAT SINK
HS941 E70945-H40B HEAT SINK
HS951 E70306-001 HEAT SINK
HS961 E70306-001 HEAT SINK
HS971 E70306-001 HEAT SINK
IC901 MN101C49GJY IC
A
IC903 IC-PST9139-T IC
J 91 QNS0022-001 JACK
PW 10 QUB111-12PPPP SIN TWIST WIRE
UJ ONLY
PW 11 QUB116-10PPPP SIN TWIST WIRE
UJ ONLY
PW 12 QUB112-14PPPP SIN TWIST WIRE
UJ ONLY
PW 13 QUB111-14PPPP SIN TWIST WIRE
WITH PW23
PW 14 QUB114-12PPPP SIN TWIST WIRE
UJ ONLY
