JVC RX-8020VBK

RX-8020VBK
3-22
Item
Parts number Parts name Area
Electrical parts list (Micon board)
Remarks
Block No. 06
A
PW 15 QUB118-12PPPP SIN TWIST WIRE UJ ONLY
PW 16 QUB116-16PPPP PIN WIRE WITH PW26
PW 17 QUB111-18PPPP SIN TWIST WIRE UJ ONLY
PW 18 QUB112-28PPPP SIN TWIST WIRE WITH PW28
PW 19 QUB111-28PPPP SIN TWIST WIRE
WITH PW29
PW 30 QUB116-28PPPP SIN TWIST WIRE
WITH PW40
Q
51 2SD2395/EF/ TRANSISTOR
UJ ONLY
Q
52 KTD863/Y/-T TRANSISTOR
Q
53 KRC105M-T D.TRANSISTOR
Q 71 KTA1046/Y/ TRANSISTOR
Q 74 KTC3200/GL/-T TRANSISTOR
Q
901 KRC107M-T D.TRANSISTOR
Q
903 KRC105M-T D.TRANSITOR
Q
904 KRC105M-T D.TRANSITOR
Q
906 KRC105M-T D.TRANSITOR
Q
907 KRC105M-T D.TRANSITOR
Q
908 KRC105M-T D.TRANSITOR
Q
921 2SD2395/EF/ TRANSISTOR
Q
931 2SD2395/EF/ TRANSISTOR
Q 941 2SD2395/EF/ TRANSISTOR
Q
951 2SD2395/EF/ TRANSISTOR
Q
961 KTA1046/Y/ TRANSISTOR
Q
971 2SD2395/EF/ TRANSISTOR
R 51 QRJ146J-153X UNF C RESISTOR
UJ ONLY
R 52 QRL017J-332 UNF OMF RESISTO
UJ ONLY
R 53 QRJ146J-6R8X UNF C RESISTOR
6.8 5% 1/4W
R 54 QRE141J-821Y C RESISTOR
820 5% 1/4W
R 61 QRJ146J-8R2X UNF C RESISTOR
EXCEPT J/C
R 72 QRJ146J-332X UNF C RESISTOR
3.3K 5% 1/4
W
R 73 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R 74 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 91 QRL027J-471 UNF OMF.RES. 470 5% 1/2W
R 92 QRL027J-471 UNF OMF.RES. 470 5% 1/2W
R 903 QRE141J-331Y C RESISTOR
330 5% 1/4W
R 908 QRE141J-223Y C RESISTOR
22K 5% 1/4W
R 910 QRE141J-223Y C RESISTOR
22K 5% 1/4W
R 911 QRE141J-472Y C RESISTOR
4.7K 5% 1/4
W
R 913 QRT027J-3R9 UNF.MF.RES.
3.9 5% 1/2W
R 914 QRT027J-3R9 UNF.MF.RES. 3.9 5% 1/2W
R 915 QRT027J-3R9 UNF.MF.RES. 3.9 5% 1/2W
R 916 QRT027J-3R9 UNF.MF.RES. 3.9 5% 1/2W
R 918 QRL027J-180 UNF.MF.RES. 18 5% 1/2W
R 921 QRK126J-120X C RESISTOR
12 5% 1/2W
R 922 QRK126J-120X C RESISTOR
12 5% 1/2W
R 923 QRJ146J-272X UNF C RESISTOR
2.7K 5% 1/4
W
R 924 QRE141J-103Y C RESISTOR
10K 5% 1/4W
R 925 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 926 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 927 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 928 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 929 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 931 QRL017J-330 OMF RESISTOR 33 5% 1/1W
R 932 QRL017J-330 OMF RESISTOR
33 5% 1/1W
R 933 QRJ146J-272X UNF C RESISTOR
2.7K 5% 1/4
W
R 937 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 938 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 939 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 940 QRJ146J-3R3X UNF C RESISTOR 3.3 5% 1/4W
R 941 QRK126J-120X C RESISTOR 12 5% 1/2W
R 942 QRK126J-120X C RESISTOR 12 5% 1/2W
R 943 QRJ146J-272X UNF C RESISTOR 2.7K 5% 1/4
W
R 944 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 945 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 946 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 951 QRK126J-120X C RESISTOR
12 5% 1/2W
R 953 QRJ146J-222X UNF C RESISTOR
2.2K 5% 1/4
W
R 954 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 955 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 956 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 961 QRK126J-120X C RESISTOR 12 5% 1/2W
R 963 QRJ146J-222X UNF C RESISTOR
2.2K 5% 1/4
W
R 965 QRE141J-103Y C RESISTOR
10K 5% 1/4W
R 966 QRE141J-103Y C RESISTOR
10K 5% 1/4W
R 967 QRE141J-103Y C RESISTOR
10K 5% 1/4W
R 968 QRE141J-103Y C RESISTOR
10K 5% 1/4W
R 969 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 971 QRJ146J-120X UNF C RESISTOR 12 5% 1/4W
R 973 QRJ146J-332X UNF C RESISTOR 3.3K 5% 1/4
W
R 975 QRJ146J-220X UNF C RESISTOR 22 5% 1/4W
R 976 QRE141J-472Y C RESISTOR 4.7K 5% 1/4
W
R 977 QRE141J-472Y C RESISTOR
4.7K 5% 1/4
W
R 978 QRE141J-472Y C RESISTOR
4.7K 5% 1/4
W
R 979 QRE141J-472Y C RESISTOR
4.7K 5% 1/4
W
R 980 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 981 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 982 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 983 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 984 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 985 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 986 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 987 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 991 QRE141J-472Y C RESISTOR
4.7K 5% 1/4
W
R 992 QRE141J-472Y C RESISTOR
4.7K 5% 1/4
W
R 993 QRE141J-622Y C RESISTOR
6.2K 5% 1/4
W
R 994 QRE141J-512Y C RESISTOR
5.1K 5% 1/4
W
R 995 QRE141J-133Y C RESISTOR 13K 5% 1/4W
R 996 QRE141J-332Y C RESISTOR 3.3K 5% 1/4
W
R 997 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R 998 QRE141J-562Y C RESISTOR 5.6K 5% 1/4
W
R 999 QRE141J-103Y C RESISTOR
EXCEPT E/EN
RY 1 QSK0098-001 RELAY
A
T 2 QQT0281-004 POWER TRANSF
A
UJ
TA 1 QNZ0079-001Z TAB
TA 2 QNZ0079-001Z TAB
TH 71 QAD0095-4R7Z POSISTOR
VS 1 QSW0812-001 VOLTAGE SWITCH UJ ONLY
X 901 QAX0246-001Z C RESONATOR
