JVC RX-807VTN

(EEEOT ON) OL-L
ng the S.E.A. Gra
The S.E.A. Graphic Equalizer breaks down the audible frequency
range into seven bands. Each band of tones can be adjusted as dis-
ired by the listener. Thus allowing you to make the necessary ad-
justments in the presicely appropriate frequency bands.
*You can customize the sound to your taste.
*You can correct subtle frequency to suit the acoustic charac-
teristics of your listening room.
*You can compensate for the conditions of audio equipment.
Note:
The S.E.A. Graphic Equalizer does not work on the CENTER and REAR
speaker sound.
= Recalling a preset pattern
A total of 10 preset patterns can be used: 5 programmed preset pat-
terns, and 5 manual patterns which you create (SEA-A through E)
1. Press the SEA key.
SEA
co cm
\
Li) 10 400 1K 26K 6.aK 16K
The Dot Display normally shows the input signal levels.
It will change to SEA level for about 5 seconds when the SEA,
PRESET, LEVEL, FLAT, REVERSE, or FREQUENCY keys are pressed.
2. Call a preset pattern with the PRESET keys.
Co Oe ee :
im o eel emenenmnee ens Pee
preset : :
“a :
es Wo 100 1K 26K 6aK 1K
A-E: Manual patterns
F) HEAVY: For music with a heavy beat
G) CLEAR: For crisp, clear sound with transparent highs.
H) SOFT: For background music, at low volume level.
1) MOVIE: For TV, VCR, and videodisc sound.
J) VOCAL: For music that is chiefly vocal, or speech
Order
APBRPCRDPRERFR GP H PIP J P (back to the
beginning)
« After recalling these pattern, you can further change each
frequency band to suit yourself. However, since they are represen-
é tative patterns, the original, stored pattern will be unchanged.
= Creating an S.E.A. pattern
1. Press the SEA key
2. Press the FREQUENCY keys to call the desired frequency.
FREQUENCY
ey “99 wo 400 IK 25K 6.3K 18K
3. Press the LEVEL keys to adjust the S.E.A. level
CH:
<_teve_ >
Note:
When a frequency has been called, press the LEVEL keys while the
frequency is displayed (about 5 seconds). If the display is cleared
before you press the LEVEL keys, it can be recalled by pressing either
FREQUENCY keys or LEVEL keys
@ The SEA key enables you to compare the sound corrected by
S.E.A. with the original (uncorrected) sound during the procedure
for creating an S.E.A. pattern. Pressing the SEA key to turn the
S.E.A. OFF lets you hear the uncorrected sound. When you press
the S.E.A. key again, the S.E.A. pattern being created is recalled
and the corrected sound can be heard
@ To flatten the SEA characteristics
mA Cem **:
Ol eeeeneensenccusesensencnaecous =
-e
3 10 400 «1K 26K 6.3K 16K
Pressing the FLAT key while a pattern is yet to be preset will clear
it. Be careful not to press the FLAT key inadvertently
@ You can create an S.E.A. pattern using the remote contro} unit.
1. Press the SEA CONTROL key on the external panel.
2. Use the Multi Function Cursor keys.
Y
-
i
—, + : Calls a frequency band to correct.
A, V : Sets an S.E.A. level
sea
SEA PRESET Rec = eve >
MEMORY FLAT. REVERSE FREQUENCY >
@ Presetting Manual Patterns
1. Create an S_E.A. pattern to preset as instructed in ‘‘Creating an
S.E.A. pattern’.
2. Press MEMORY key to light its indicator. Call one of the patterns
to store (SEA-A through E) by pressing the PRESET keys while
the indicator is on (about 5 seconds}
event
Co sex)": 3
‘a MEMORY
63 0 400 «6tK 625K 6.3K 16K
PRESET CHEE tw:
memory {7} enaeuensrnn” eoneneenneenen
PRESET
63 10 400 «1K 26K 6.3K 16K
Order
APBPCPRDPEP (back to the beginning)
Note:
Press the MEMORY key again if the indicator turns off before you
press the PRESET keys
3. Press the MEMORY key again while the indicator.is on (about 5
seconds). Memory presetting is complete when the MEMORY in-
dicator turns off
Paces +e:
7
preset 11
@3 120 400 «1K (2.8K 6.9K 16K
The preset SEA patterns can each be given a five-character title. See
the section ‘Entering Characters’’ for further details
@ S.E.A. recording
The sound corrected by S.E.A. can be recorded on the tape deck
connected to the TAPE 1 terminals
4. Press the SEA key to turn the S.E.A. ON.
2. Adjust the S.£.A. settings (PRESET, FREQUENCY, LEVEL)
3. Press the REC key.
eC
[ }
Ce
:
my
Fk
ananeccosencca®"seusenscvnraes
|
PRESET
:
‘7
63 Oo 400 1K 2.6K 6.8K 16K
4. Operate the recording procedure.
Notes:
* SEA recording is not available with the tape deck connected to
the TAPE 2, VCR 1, and VCR 2 terminals.
© The REC key is not functional when the SURROUND key is ON.
The reverse feature offers you a noise reduction effect during tape
recording. First, record sources with emphasis on high-piched tones
by using SEA; during playback, activate reverse SEA, to cut hissing
noise inherent in tape recording.
To reverse the porality of the S.E.A. characteristics, press the
REVERSE key
Frequency band responses
63 Hz: Raise to emphasize the very low base response of organs, drums,
and contrabass. When de-emphasized, eliminated unclear response at low
frequencies.
160 Hz: Emphasize to obtain a more expanded low sound. De-emphasize
to eliminate unclear sound caused by large or nearly empty listening rooms.
400 Hz: This frequency range is the base on which music is construct-
ed. Emphasize to put real punch in your music:
1 kHz: Most effective in emphasizing or de-emphasizing the human voice.
2.5 kHz: The human hearing is most sensitive to this freuqncy. If the music
sounds hard or metallic, de-emphasize it.
6.3 kHz: This frequency band varies the tonal expression, influencing the
subtleties of the music.
16 kHz: Boosting this frequency range suitably adds to the delicacy of
highs, with cymbals and triangles resounding in a more ear-pleasing man-
ner, and provides a feeling of extension.
NLAZO8-XY
