Waveform (3) at ‘AMP_+/-B’ switch regulator
Always about 11v different between pin 2 and pin4 of IC101.
DC 0v line
Blue at S of Q1101- channel 1
Yellow at pin 2 of IC101 (R1110)
About
11v.
POWER SUPPLY 3/5
