POWER SUPPLY 1/5
note
The power supply circuits for 2005 year of RX-D… series are similar. One main
difference is the ‘D+5V_HDMI’ is not in models RX-D201/202/301/302.
There are two AC power transformers in the unit.
1. T101 for standby power: supplies D+5V and B+5V_Mi DC power for CPU IC501
and RY+9V (power ON/OFF relay circuit).
2. T102 for unit operation after power on: There are more than 15 different DC
voltages provided for unit operation after power is turned on.
The DC voltages: +B, AMP+B, AMP-B+12V and DCDC_-B+12V all vary (along
with output volume) referenced to ground. The ‘–B’ voltage is -50v~ -62v
referenced to ground. The label ‘DCDC_-B+12V’ DC voltage means this is the
DC voltage supply to the DCDC converter circuit, the +12 DC refers to –B; if
referenced to ground, it is -38v~-50v.
The +B and AMP+B voltages are higher in models RX-D402/702, because the
output power is higher than RX-D201/202.
The +2.5v, DCDC_+12V, DCDC_-B+12V, AMP-B+12V, D+5V_DSP and
D+5V_HDMI are not produced in the main PCB.
You could check all of the voltages at the indicated (underlined) locations
without any extension cable, before or after power is turned on. (See the next
page)
Some additional DC voltages are produced in ‘Regulate PCB’ and ‘Master clock
PCB’.
