RX-DP10VBK/RX-DP10VSL
RX-DP10RSL
3-44
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
145 QYSBSGY3008E
SPECIAL SCREW
2
TUNER
146 QYSBSGY3008E
SPECIAL SCREW
2
DCS
147 QYSBSGY3008E
SPECIAL SCREW
5
SPK
148 E409257-001
GND TERMINAL
1
149 QMPK230-205-JC
POWER CORD
E,EN
A
1
QMPN100-200-JD
POWER CORD
B
A
1
150 QZW0033-001
STRAIN RELIEF
A
1
151 LV40911-001A
LABEL
1
152 LV10538-005A/S/
TOP COVER
1
153 QYSBSGY3008E
SPECIAL SCREW
3
TOP COVER
154 E406308-004
SPECIAL SCREW
8
TOP SL-MODEL
155 LV32819-001A
VOL KNOB
1
156 LV33243-001A
PROTECT SHEET
1
157 LV42405-001A
VOL RING
1
158 QUQ412-1619DJ
FFC WIRE
1
FRONT1-MOTHER
159 QUQ412-2019DJ
FFC WIRE
1
FRONT1-MOTHER
160 QUQ412-1513DJ
FFC WIRE
1
TUNER-AUDIO2
161 QUQ412-1605DJ
FFC WIRE
1
VIDEO1-VIDEO2
162 VKZ4001-018
WIRE HOLDER
1
163 VKZ4001-111S
WIRE CLAMP
2
164 LV33163-001A
BARRIER
2
165 QYSBSGG3008E
T.SCREW
3
166 QMF51E2-4R0-J1
FUSE
A
1
F21
167 QMF51E2-R50-J1
FUSE
A
1
F41
168 QMF51E2-2R0-J1
FUSE
A
1
F42
169 QMF51E2-2R0-J1
FUSE
A
2
F61,F62
170 E409396-002
CAUTION LABEL
1
171 QWTJ809-240
GLASS TUBE
1
172 QYSBSG3008E
T.SCREW
1
HS41
173 QYSBSG3008E
T.SCREW
1
HS42
174 QYSBSG3008E
T.SCREW
1
HS61
175 QYSBSG3008E
T.SCREW
1
HS62
176 QYSBSG3008E
T.SCREW
1
HS63
179 LV32827-002A
LED HOLDER
1
D1034
180 LV42783-001A
EARTH PLATE
1
181 LV30225-0D3A
SPACERW
1
182 LV30225-0D4A
SPACER
1
184 LV30226-029A
SPACER
1
185 EXO150010H09S11
FELT SPACER
1
186 LV30225-074A
SPACER
1
187 QMR0008-001
TH PROTECTOR
1
TF2
188 QYSBSG3008E
T.SCREW
1
189 WJM0260-001A
E-SI C WIRE C-F
1
190 QYSDSG3008E
T.SCREW
1
191 QMR0007-001
TH PROTECTOR
1
TF1
192 QYSBSG3008E
T.SCREW
1
193 WJM0261-001A
E-SI C WIRE C-F
1
194 LV32842-001A
PROTECT SHEET
1
195 QMF51E2-R10-J1
FUSE
A
1
F23
