RX-DP10VBK/RX-DP10VSL
RX-DP10RSL
3-54
Item
Parts number Parts name Ar
e
a
Electrical parts list
(Audio/video input & outpat board)
Remarks
Block No. 02
A
Item
Parts number Parts name Ar
e
a
Remarks
A
C2405 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C2406 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C2407 NCB31HK-223X C CAPACITOR
C2408 NCB31HK-223X C CAPACITOR
C2411 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2412 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2413 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2414 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2415 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C2416 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C2417 NCB31HK-223X C CAPACITOR
C2418 NCB31HK-223X C CAPACITOR
C2421 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2422 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2423 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2424 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2425 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C2426 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C2427 NCB31HK-223X C CAPACITOR
C2428 NCB31HK-223X C CAPACITOR
C2501 NCF21CZ-225X C CAPACITOR
C2502 NCF21CZ-225X C CAPACITOR
C2503 NCF21CZ-105X C CAPACITOR
C2504 NCF21CZ-105X C CAPACITOR
D 240 1SS355-X DIODE
D 351 1SS355-X DIODE
D 401 1SS133-T2 SI DIODE
D 402 1SS133-T2 SI DIODE
D2311 1SS133-T2 SI DIODE
D2501 1SS355-X DIODE
D2502 1SS355-X DIODE
D2503 1SS355-X DIODE
D2504 1SS355-X DIODE
D2505 1SS355-X DIODE
D2506 1SS355-X DIODE
D2507 1SS355-X DIODE
D2508 1SS355-X DIODE
FL301 QQR0590-001 FILTER
FL302 QQR0590-001 FILTER
IC201 NJM4580E-W IC
IC202 TC9164AF-X IC
IC204 NJM4580E-W IC
IC211 TC9162AF-X IC
IC213 TC9162AF-X IC
IC221 TC9459F-X IC
IC222 TC9459F-X IC
IC223 TC9459F-X IC
IC224 TC9459F-X IC
IC241 NJM4580E-W IC
IC242 NJM4580E-W IC
IC251 NJM4580E-W IC
IC252 NJM4580E-W IC
IC253 NJM4580E-W IC
IC254 NJM4580E-W IC
IC271 NJM4580E-W IC
IC272 NJM4580E-W IC
IC273 NJM4580E-W IC
IC281 NJM4580E-W IC
IC282 NJM2903M-XE IC
IC283 NJM78L05A-T IC
IC311 SAA6588 IC
IC321 TC9163AF-X IC
IC401 BA7625 IC
IC402 NJM2285V-W IC
IC403 MB90088PF-131 IC
IC431 BA7625 IC
IC432 BA7626 IC
IC461 BU4051BC IC
J 201 QNN0392-001 PIN JACK
J 202 QNN0392-001 PIN JACK
J 203 QNN0396-001 PIN JACK
J 321 QNN0392-001 PIN JACK
J 322 QNN0393-001 PIN JACK
J 323 QNN0396-001 PIN JACK
J 324 QNN0394-001 PIN JACK
J 401 QNN0402-001 PIN JACK
J 402 QNN0403-001 PIN JACK
J 403 QNN0403-001 PIN JACK
J 431 QND0090-001 S JACK
J 432 QND0029-001 DIN CONNECTOR
J 433 QND0029-001 DIN CONNECTOR
J 434 QND0089-001 S JACK
L 321 QQL231K-121Y INDUCTOR
L 322 QQL231K-121Y INDUCTOR
L 401 QQL231K-220Y INDUCTOR
Q
201 KRA104M-T D TRANSISTOR
Q
211 2SC3576-JVC-T TRANSISTOR
Q
212 2SC3576-JVC-T TRANSISTOR
Q
213 2SC3576-JVC-T TRANSISTOR
Q
214 2SC3576-JVC-T TRANSISTOR
Q
215 2SC3576-JVC-T TRANSISTOR
Q
216 2SC3576-JVC-T TRANSISTOR
Q
217 2SC3576-JVC-T TRANSISTOR
Q
218 2SC3576-JVC-T TRANSISTOR
Q
219 2SC3576-JVC-T TRANSISTOR
Q
240 KRC105M-T D TRANSISTOR
Q
323 2SC3576-JVC-T TRANSISTOR
Q
324 2SC3576-JVC-T TRANSISTOR
Q
325 2SC3576-JVC-T TRANSISTOR
Q
329 2SC3576-JVC-T TRANSISTOR
Q
330 2SC3576-JVC-T TRANSISTOR
Q
332 DTC114YKA-X CHIP D TRANSISTOR
Q
334 DTC114YKA-X CHIP D TRANSISTOR
Q
342 DTA114YKA-X TRANSISTOR
Q
343 DTA114YKA-X TRANSISTOR
Q
345 DTA114YKA-X TRANSISTOR
Q
351 KRC105M-T D TRANSISTOR
Q
401 KTA1267/YG/-T TRANSISTOR
Q
402 KTA1267/YG/-T TRANSISTOR
Q
403 KRC110M-T TRANSISTOR
Q
404 KRC107M-T D TRANSISTOR
Q
405 KTA1267/YG/-T TRANSISTOR
Q
406 KTA1267/YG/-T TRANSISTOR
Q
407 KTA1267/YG/-T TRANSISTOR
Q
431 KTA1267/YG/-T TRANSISTOR
Q
432 KTA1267/YG/-T TRANSISTOR
Q
433 KTA1267/YG/-T TRANSISTOR
Q
434 KTA1267/YG/-T TRANSISTOR
Q
461 DTC114EKA-X TRANSISTOR
Q
462 DTC114EKA-X TRANSISTOR
Q
463 DTC114EKA-X TRANSISTOR
Q
464 KTC3199/GL/-T TRANSISTOR
Q
465 KTC3199/GL/-T TRANSISTOR
Q
466 KTC3199/GL/-T TRANSISTOR
Q
467 KTA1267/YG/-T TRANSISTOR
Q
2501 KTC3199/GL/-T TRANSISTOR
