Item
Parts number Parts name Ar
e
a
Electrical parts list
(Audio/video input & outpat board)
Remarks
Block No. 02
A
Item
Parts number Parts name Ar
e
a
Remarks
A
R 409 NRSA63J-473X MG RESISTOR
R 410 NRSA63J-331X MG RESISTOR
R 411 NRSA63J-473X MG RESISTOR
R 412 NRSA63J-331X MG RESISTOR
R 413 NRSA63J-331X MG RESISTOR
R 414 NRSA63J-473X MG RESISTOR
R 415 NRSA63J-151X MG RESISTOR
R 416 NRSA63J-151X MG RESISTOR
R 417 NRSA63J-301X MG RESISTOR
R 418 NRSA63J-103X MG RESISTOR
R 419 NRSA63J-331X MG RESISTOR
R 420 NRSA63J-101X MG RESISTOR
R 421 NRSA63J-121X MG RESISTOR
R 422 NRSA63J-151X MG RESISTOR
R 423 NRSA63J-561X MG RESISTOR
R 424 NRSA63J-561X MG RESISTOR
R 425 NRSA63J-561X MG RESISTOR
R 426 QRJ146J-1R0X UNF C RESISTOR
A
1.0 5% 1/4W
R 431 NRSA63J-750X MG RESISTOR
R 432 NRSA63J-750X MG RESISTOR
R 433 NRSA63J-750X MG RESISTOR
R 434 NRSA63J-750X MG RESISTOR
R 435 NRSA63J-473X MG RESISTOR
R 436 NRSA63J-750X MG RESISTOR
R 437 NRSA63J-750X MG RESISTOR
R 438 NRSA63J-750X MG RESISTOR
R 439 NRSA63J-750X MG RESISTOR
R 440 NRSA63J-473X MG RESISTOR
R 441 NRSA63J-750X MG RESISTOR
R 442 NRSA63J-750X MG RESISTOR
R 443 NRSA63J-750X MG RESISTOR
R 444 NRSA63J-750X MG RESISTOR
R 445 NRSA63J-750X MG RESISTOR
R 446 NRSA63J-750X MG RESISTOR
R 447 NRSA63J-473X MG RESISTOR
R 448 NRSA63J-121X MG RESISTOR
R 449 NRSA63J-121X MG RESISTOR
R 450 NRSA63J-151X MG RESISTOR
R 451 NRSA63J-151X MG RESISTOR
R 452 QRJ146J-6R8X UNF C RESISTOR
A
6.8 5% 1/4W
R 453 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R 461 NRSA63J-562X MG RESISTOR
R 462 NRSA63J-562X MG RESISTOR
R 463 NRSA63J-562X MG RESISTOR
R 464 NRSA63J-562X MG RESISTOR
R 465 NRSA63J-562X MG RESISTOR
R 466 NRSA63J-223X MG RESISTOR
R 467 NRSA63J-223X MG RESISTOR
R 468 NRSA63J-223X MG RESISTOR
R 469 NRSA63J-104X MG RESISTOR
R 470 NRSA63J-334X MG RESISTOR
R 471 NRSA63J-472X MG RESISTOR
R 472 NRSA63J-472X MG RESISTOR
R 473 NRSA63J-472X MG RESISTOR
R 474 NRSA63J-103X MG RESISTOR
R 475 NRSA63J-103X MG RESISTOR
R 476 NRSA63J-103X MG RESISTOR
RY240 QSK0125-001 RELAY
RY351 QSK0125-001 RELAY
R1351 QRZ9005-331X F RESISTOR
A
330 1/4W
R2051 NRSA63J-334X MG RESISTOR
R2052 NRSA63J-334X MG RESISTOR
R2053 NRSA63J-104X MG RESISTOR
R2054 NRSA63J-104X MG RESISTOR
R2055 NRSA63J-104X MG RESISTOR
R2056 NRSA63J-104X MG RESISTOR
R2057 QRZ9005-680X F RESISTOR
A
68 1/4W
R2058 QRZ9005-680X F RESISTOR
A
68 1/4W
R2059 NRSA63J-334X MG RESISTOR
R2060 NRSA63J-334X MG RESISTOR
R2061 NRSA63J-104X MG RESISTOR
R2062 NRSA63J-104X MG RESISTOR
R2063 NRSA63J-104X MG RESISTOR
R2064 NRSA63J-104X MG RESISTOR
R2065 QRZ9005-680X F RESISTOR
A
68 1/4W
R2066 QRZ9005-680X F RESISTOR
A
68 1/4W
R2067 NRSA63J-334X MG RESISTOR
R2068 NRSA63J-334X MG RESISTOR
R2069 NRSA63J-104X MG RESISTOR
R2070 NRSA63J-104X MG RESISTOR
R2071 NRSA63J-104X MG RESISTOR
R2072 NRSA63J-104X MG RESISTOR
R2073 QRZ9005-680X F RESISTOR
A
68 1/4W
R2074 QRZ9005-680X F RESISTOR
A
68 1/4W
R2075 NRSA63J-334X MG RESISTOR
R2076 NRSA63J-334X MG RESISTOR
R2077 NRSA63J-104X MG RESISTOR
R2078 NRSA63J-104X MG RESISTOR
R2079 NRSA63J-104X MG RESISTOR
R2080 NRSA63J-104X MG RESISTOR
R2081 QRZ9005-680X F RESISTOR
A
68 1/4W
R2082 QRZ9005-680X F RESISTOR
A
68 1/4W
R2211 NRSA63J-102X MG RESISTOR
R2212 NRSA63J-102X MG RESISTOR
R2213 NRSA63J-102X MG RESISTOR
R2214 NRSA63J-102X MG RESISTOR
R2215 NRSA63J-102X MG RESISTOR
R2216 NRSA63J-102X MG RESISTOR
R2259 NRSA63J-333X MG RESISTOR
R2260 NRSA63J-333X MG RESISTOR
R2261 NRSA63J-333X MG RESISTOR
R2262 NRSA63J-333X MG RESISTOR
R2263 NRSA63J-333X MG RESISTOR
R2264 NRSA63J-333X MG RESISTOR
R2265 NRSA63J-333X MG RESISTOR
R2266 NRSA63J-333X MG RESISTOR
R2267 NRSA63J-333X MG RESISTOR
R2268 NRSA63J-333X MG RESISTOR
R2269 NRSA63J-102X MG RESISTOR
R2270 NRSA63J-102X MG RESISTOR
R2273 NRSA63J-102X MG RESISTOR
R2274 NRSA63J-102X MG RESISTOR
R2275 QRZ9005-680X F RESISTOR
A
68 1/4W
R2276 QRZ9005-680X F RESISTOR
A
68 1/4W
R2301 NRSA63J-682X MG RESISTOR
R2302 NRSA63J-682X MG RESISTOR
R2303 NRSA63J-102X MG RESISTOR
R2304 NRSA63J-102X MG RESISTOR
R2311 NRSA63J-102X MG RESISTOR
R2312 NRSA63J-474X MG RESISTOR
R2313 NRSA63J-103X MG RESISTOR
R2314 NRSA63J-103X MG RESISTOR
R2315 NRSA63J-102X MG RESISTOR
R2316 NRSA63J-103X MG RESISTOR
R2317 NRSA63J-103X MG RESISTOR
R2351 QRA14CF-1001Y MF RESISTOR 10 1/4W
