JVC RX-DP10VBK User Manual

RX-DP10VBK/RX-DP10VSL
RX-DP10RSL
3-58
Item
Parts number Parts name Ar
e
a
Electrical parts list (Power supply board)
Remarks
Block No. 03
A
Item
Parts number Parts name Ar
e
a
Remarks
A
C 1 QER61CM-107Z E CAPACITOR 100MF 20% 16V
C 21 QCZ9104-472 C CAPACITOR
A
4700PF
C 22 QFN32AK-472Z M CAPACITOR 4700PF 10% 100V
C 23 QETM1EM-228 E CAPACITOR 2200MF 20% 25V
C 24 QCF31HZ-472Z C CAPACITOR 4700PF +80:-20%
C 25 QETN1CM-477Z E CAPACITOR 470MF 20% 16V
C 41 QFVJ1HJ-104Z MF CAPACITOR 0.1MF 5% 50V
C 42 QETM1EM-478 E CAPACITOR 4700MF 20% 25V
C 43 QCF31HZ-472Z C CAPACITOR 4700PF +80:-20%
C 44 QEHR1EM-107Z E CAPACITOR 100MF 20% 25V
C 45 QCF31HZ-472Z C CAPACITOR 4700PF +80:-20%
C 46 QEHR1EM-107Z E CAPACITOR 100MF 20% 25V
C 47 QCF31HZ-472Z C CAPACITOR 4700PF +80:-20%
C 48 QEHR1EM-107Z E CAPACITOR 100MF 20% 25V
C 49 QEHR1EM-107Z E CAPACITOR 100MF 20% 25V
C 50 QCF31HZ-472Z C CAPACITOR 4700PF +80:-20%
C 51 QETN1JM-227Z E CAPACITOR 220MF 20% 63V
C 52 QETN1HM-226Z E CAPACITOR 22MF 20% 50V
C 53 QETN1HM-226Z E CAPACITOR 22MF 20% 50V
C 54 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 55 QFN31HJ-473Z M CAPACITOR 0.047MF 5% 50V
C 56 QFN31HJ-473Z M CAPACITOR 0.047MF 5% 50V
C 60 QEHC1EM-227Z E CAPACITOR 220MF 20% 25V
C 61 QFN32AJ-104Z M CAPACITOR 0.1MF 5% 100V
C 62 QFN32AJ-104Z M CAPACITOR 0.1MF 5% 100V
C 63 QFN32AJ-104Z M CAPACITOR 0.1MF 5% 100V
C 64 QFN32AJ-104Z M CAPACITOR 0.1MF 5% 100V
C 65 QFN32AJ-104Z M CAPACITOR 0.1MF 5% 100V
C 66 QETM1VM-228 E CAPACITOR 2200MF 20% 35V
C 67 QETM1VM-228 E CAPACITOR 2200MF 20% 35V
C 68 QCF31HZ-472Z C CAPACITOR 4700PF +80:-20%
C 69 QEHC1EM-227Z E CAPACITOR 220MF 20% 25V
C 70 QCF31HZ-472Z C CAPACITOR 4700PF +80:-20%
C 71 QEHC1EM-107Z E CAPACITOR 100MF 20% 25V
C 72 QCF31HZ-472Z C CAPACITOR 4700PF +80:-20%
C 73 QEHC1EM-227Z E CAPACITOR 220MF 20% 25V
C 74 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 75 QEHR1VM-107Z E CAPACITOR 100MF 20% 35V
C 76 QCF31HZ-472Z C CAPACITOR 4700PF +80:-20%
C 81 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 82 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 83 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
CN 1 QGF1205C1-16 CONNECTOR
CN 2 QGF1205C1-20 CONNECTOR
CN 3 QGB2510J1-11 CONNECTOR
CN 4 QGB2510J1-04 CONNECTOR
CN 5 QGB2510J1-20 CONNECTOR
CN 6 QGB1214J1-20S CONNECTOR
CN 7 QGB1214J1-16S CONNECTOR
CN 8 QGB2510J1-15 CONNECTOR
CN 11 QGA2001C1-08 8P PLUG ASSY
CN 15 QGB2510J1-07 CONNECTOR
CN 16 QGA2001C1-11 11P PLUG ASSY
CN 17 QGA2001C1-05 5P PLUG ASSY
CN 25 QGA2001C1-07 7P PLUG ASSY
CN 41 QGA7901C1-02 CONNECTOR
CN 42 QGA2001F1-05 5P PLUG ASSY
CN 43 QGA2001F1-08 CONNECTOR
CN 45 QGA2001F1-06 6P PLUG ASSY
CN 61 QGA7901C1-04 CONNECTOR
CN 63 QGA2001C1-08 8P PLUG ASSY
CN 64 QGA2001C1-03 3P PLUG ASSY
CN 65 QGA2501C1-02 2P CONNECTOR
CN 66 QGA2001C1-02 2P PLUG ASSY
CN 67 QGA2001C1-02 2P PLUG ASSY
D 1 1SS133-T2 SI DIODE
D 2 1SS133-T2 SI DIODE
D 3 MTZJ4.7B-T2 ZENER DIODE
D 4 1SS133-T2 SI DIODE
D 5 1SS133-T2 SI DIODE
D 6 1SS133-T2 SI DIODE
D 7 1SS133-T2 SI DIODE
D 21 1SR35-400A-T5 DIODE
A
D 22 1SR35-400A-T5 DIODE
A
D 23 1SR35-400A-T5 DIODE
A
D 24 1SR35-400A-T5 DIODE
A
D 25 1SS133-T2 SI DIODE
D 26 MTZJ6.2A-T2 ZENER DIODE
D 41 1GWJ42-T5 DIODE
A
D 42 1GWJ42-T5 DIODE
A
D 43 1GWJ42-T5 DIODE
A
D 44 1GWJ42-T5 DIODE
A
D 45 1SS133-T2 SI DIODE
D 46 MTZJ6.2C-T2 ZENER DIODE
D 47 1SS133-T2 SI DIODE
D 48 MTZJ6.2C-T2 ZENER DIODE
D 49 1SS133-T2 SI DIODE
D 50 MTZJ6.2C-T2 ZENER DIODE
D 51 1SS133-T2 SI DIODE
D 52 MTZJ6.8C-T2 ZENER DIODE
D 53 1SR35-400A-T5 DIODE
A
D 55 MTZJ36C-T2 ZENER DIODE
D 56 MTZJ8.2C-T2 ZENER DIODE
D 61 1SR35-400A-T5 DIODE
A
D 62 1SR35-400A-T5 DIODE
A
D 63 1SR35-400A-T5 DIODE
A
D 64 1SR35-400A-T5 DIODE
A
D 65 1SS133-T2 SI DIODE
D 66 MTZJ15C-T2 ZENER DIODE
D 67 1SS133-T2 SI DIODE
D 68 MTZJ13C-T2 ZENER DIODE
D 69 1SS133-T2 SI DIODE
D 70 MTZJ15C-T2 ZENER DIODE
D 71 1SS133-T2 SI DIODE
D 72 1SS133-T2 SI DIODE
D 73 MTZJ24C-T2 ZENER DIODE
EP 22 QNZ0136-001Z EARTH PLATE
EP 61 QNZ0136-001Z EARTH PLATE
FC 21 QNG0020-001Z FUSE CLIP F21
FC 22 QNG0020-001Z FUSE CLIP F21
FC 25 QNG0020-001Z FUSE CLIP F23
FC 26 QNG0020-001Z FUSE CLIP F23
FC 41 QNG0020-001Z FUSE CLIP F41
FC 42 QNG0020-001Z FUSE CLIP F41
FC 43 QNG0020-001Z FUSE CLIP F42
FC 44 QNG0020-001Z FUSE CLIP F42
FC 61 QNG0020-001Z FUSE CLIP F61
FC 62 QNG0020-001Z FUSE CLIP F61
FC 63 QNG0020-001Z FUSE CLIP F62
FC 64 QNG0020-001Z FUSE CLIP F62
HS 41 E70306-005 HEAT SINK
HS 42 E70306-005 HEAT SINK
HS 61 E70306-001 HEAT SINK
HS 62 E70306-001 HEAT SINK
HS 63 E70306-001 HEAT SINK
J 81 QNS0061-001 6.3 JACK
