JVC RX-DP10VBK User Manual

RX-DP10VBK/RX-DP10VSL
RX-DP10RSL
3-12
Item
Parts number Parts name Ar
e
a
Electrical parts list (Amp. board)
Remarks
Block No. 01
A
R 805 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 806 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R 807 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R 808 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 809 QRJ146J-151X UNF C RESISTOR 150 5% 1/4W
R 810 QRJ146J-562X UNF C RESISTOR 5.6K 5% 1/4W
R 811 QRK126J-103X UNF C RESISTOR 10K 5% 1/2W
R 812 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 813 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R 814 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R 815 QRE141J-151Y C RESISTOR 150 5% 1/4W
R 816 QRE141J-680Y C RESISTOR 68 5% 1/4W
R 817 QRE141J-331Y C RESISTOR 330 5% 1/4W
R 818 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 819 QRE141J-391Y C RESISTOR 390 5% 1/4W
R 820 QRJ146J-121X UNF C RESISTOR 120 5% 1/4W
R 821 QRJ146J-121X UNF C RESISTOR 120 5% 1/4W
R 822 QRJ146J-272X UNF C RESISTOR 2.7K 5% 1/4W
R 823 QRJ146J-120X UNF C RESISTOR 12 5% 1/4W
R 824 QRJ146J-120X UNF C RESISTOR 12 5% 1/4W
R 825 QRJ146J-271X UNF C RESISTOR 270 5% 1/4W
R 826 QRJ146J-1R0X UNF C RESISTOR 1.0 5% 1/4W
R 827 QRJ146J-1R0X UNF C RESISTOR 1.0 5% 1/4W
R 828 QRZ0182-R10 EMIT RESISTOR 1/1W
R 829 QRZ0182-R10 EMIT RESISTOR 1/1W
R 831 QRL027J-472 UNF OMF RESISTOR 4.7K 5% 1/2W
R 832 NRSA02J-331X MG RESISTOR
R 833 NRSA02J-103X MG RESISTOR
R 835 QRJ125J-330 UNF C RESISTOR 33 5% 1/2W
R 836 QRL027J-100 UNF OMF RESISTOR 10 5% 1/2W
R 841 QRA14CF-1003Y MF RESISTOR 10 1/4W
R 842 QRA14CF-3601Y MF RESISTOR 36 1/4W
RY751 QSK0112-001 RELAY
RY771 QSK0131-001 RELAY
A
RY772 QSK0131-001 RELAY
A
RY773 QSK0131-001 RELAY
A
RY774 QSK0131-001 RELAY
A
RY901 QSK0109-001 RELAY
RY902 QSK0109-001 RELAY
RY903 QSK0109-001 RELAY
RY904 QSK0109-001 RELAY
RY905 QSK0109-001 RELAY
RY906 QSK0109-001 RELAY
R1601 QRA14CF-1001Y MF RESISTOR 10 1/4W
R1602 QRA14CF-1003Y MF RESISTOR 10 1/4W
R1603 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1604 QRE141J-331Y C RESISTOR 330 5% 1/4W
R1605 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1606 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R1607 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R1608 QRE141J-101Y C RESISTOR 100 5% 1/4W
R1609 QRJ146J-151X UNF C RESISTOR 150 5% 1/4W
R1610 QRJ146J-562X UNF C RESISTOR 5.6K 5% 1/4W
R1611 QRK126J-103X UNF C RESISTOR 10K 5% 1/2W
R1612 QRE141J-680Y C RESISTOR 68 5% 1/4W
R1613 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R1614 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R1615 QRE141J-151Y C RESISTOR 150 5% 1/4W
R1616 QRE141J-680Y C RESISTOR 68 5% 1/4W
R1617 QRE141J-331Y C RESISTOR 330 5% 1/4W
R1618 QRE141J-471Y C RESISTOR 470 5% 1/4W
R1619 QRE141J-391Y C RESISTOR 390 5% 1/4W
R1620 QRJ146J-121X UNF C RESISTOR 120 5% 1/4W
R1621 QRJ146J-121X UNF C RESISTOR 120 5% 1/4W
R1622 QRJ146J-272X UNF C RESISTOR 2.7K 5% 1/4W
R1623 QRJ146J-120X UNF C RESISTOR 12 5% 1/4W
R1624 QRJ146J-120X UNF C RESISTOR 12 5% 1/4W
R1625 QRJ146J-271X UNF C RESISTOR 270 5% 1/4W
R1626 QRJ146J-1R0X UNF C RESISTOR 1.0 5% 1/4W
R1627 QRJ146J-1R0X UNF C RESISTOR 1.0 5% 1/4W
R1628 QRZ0182-R10 EMIT RESISTOR 1/1W
R1629 QRZ0182-R10 EMIT RESISTOR 1/1W
R1631 QRL027J-472 UNF OMF RESISTOR 4.7K 5% 1/2W
R1632 NRSA02J-331X MG RESISTOR
R1633 NRSA02J-103X MG RESISTOR
R1635 QRJ125J-330 UNF C RESISTOR 33 5% 1/2W
R1636 QRL027J-100 UNF OMF RESISTOR 10 5% 1/2W
R1641 QRA14CF-1003Y MF RESISTOR 10 1/4W
R1642 QRA14CF-3601Y MF RESISTOR 36 1/4W
R1651 QRA14CF-1001Y MF RESISTOR 10 1/4W
R1652 QRA14CF-1003Y MF RESISTOR 10 1/4W
R1653 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1654 QRE141J-331Y C RESISTOR 330 5% 1/4W
R1655 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1656 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R1657 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R1658 QRE141J-101Y C RESISTOR 100 5% 1/4W
R1659 QRJ146J-151X UNF C RESISTOR 150 5% 1/4W
R1660 QRJ146J-562X UNF C RESISTOR 5.6K 5% 1/4W
R1661 QRK126J-103X UNF C RESISTOR 10K 5% 1/2W
R1662 QRE141J-680Y C RESISTOR 68 5% 1/4W
R1663 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R1664 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R1665 QRE141J-151Y C RESISTOR 150 5% 1/4W
R1666 QRE141J-680Y C RESISTOR 68 5% 1/4W
R1667 QRE141J-331Y C RESISTOR 330 5% 1/4W
R1668 QRE141J-471Y C RESISTOR 470 5% 1/4W
R1669 QRE141J-391Y C RESISTOR 390 5% 1/4W
R1670 QRJ146J-121X UNF C RESISTOR 120 5% 1/4W
R1671 QRJ146J-121X UNF C RESISTOR 120 5% 1/4W
R1672 QRJ146J-272X UNF C RESISTOR 2.7K 5% 1/4W
R1673 QRJ146J-120X UNF C RESISTOR 12 5% 1/4W
R1674 QRJ146J-120X UNF C RESISTOR 12 5% 1/4W
R1675 QRJ146J-271X UNF C RESISTOR 270 5% 1/4W
R1676 QRJ146J-1R0X UNF C RESISTOR 1.0 5% 1/4W
R1677 QRJ146J-1R0X UNF C RESISTOR 1.0 5% 1/4W
R1678 QRZ0182-R10 EMIT RESISTOR 1/1W
R1679 QRZ0182-R10 EMIT RESISTOR 1/1W
R1682 NRSA02J-331X MG RESISTOR
R1683 NRSA02J-103X MG RESISTOR
R1685 QRJ125J-330 UNF C RESISTOR 33 5% 1/2W
R1686 QRL027J-100 UNF OMF RESISTOR 10 5% 1/2W
R1691 QRA14CF-1003Y MF RESISTOR 10 1/4W
R1692 QRA14CF-3601Y MF RESISTOR 36 1/4W
R1701 QRA14CF-1001Y MF RESISTOR 10 1/4W
R1702 QRA14CF-1003Y MF RESISTOR 10 1/4W
R1703 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1704 QRE141J-331Y C RESISTOR 330 5% 1/4W
R1705 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1706 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R1707 QRE141J-202Y C RESISTOR 2.0K 5% 1/4W
R1708 QRE141J-101Y C RESISTOR 100 5% 1/4W
R1709 QRJ146J-151X UNF C RESISTOR 150 5% 1/4W
R1710 QRJ146J-562X UNF C RESISTOR 5.6K 5% 1/4W
R1711 QRK126J-103X UNF C RESISTOR 10K 5% 1/2W
R1712 QRE141J-680Y C RESISTOR 68 5% 1/4W
Item
Parts number Parts name Ar
e
a
Remarks
A
