Electrical parts list (DSP board)
Remarks
Block No. 05
A
IC650 JCV8006 IC
IC652 NJM2121M-X IC
IC653 M62446FP-X IC
IC654 TC74HCT04AF-X IC
IC655 NJM4580E-W IC
IC656 NJM4580E-W IC
IC658 TC7S04FU-X IC
IC659 TC7WH74FU-X IC
IC660 TC7S04FU-X IC
IC661 XCA56367PV150 IC
IC666 XCA56367PV150 IC
IC667 39VF0207CWHM03 IC
IC668 W24L010AJ-12-X IC
IC669 W24L010AJ-12-X IC
IC670 W24L010AJ-12-X IC
IC671 UPD784215AGC165 IC
IC672 TC7S04FU-X IC
IC673 AK4112AVF-X IC
IC674 TC7WH241FU-X IC
IC681 TC74VHC157FT-X IC
IC682 TC74VHC157FT-X IC
IC683 TC74VHC74FT-X IC
IC684 TC7WH74FU-X IC
IC685 TC7WH241FU-X IC
IC686 NJM4580E-W IC
IC687 NJM4580E-W IC
IC690 PQ20VZ11-X IC
IC691 PQ3DZ53-X IC
IC692 PQ3DZ53-X IC
IC693 PQ3DZ53-X IC
IC695 PQ3DZ53-X IC
IC696 PQ3DZ53-X IC
IC998 NJM2903M-XE IC
IC999 LM45CIM3-X IC
J 501 QNN0448-001 PIN JACK
J 502 QNN0448-001 PIN JACK
J 503 QNN0448-001 PIN JACK
J3701 QNN0404-001 PIN JACK
K3181 NQR0229-001X FERRITE BEADS
K3182 NQR0229-001X FERRITE BEADS
K3183 NQR0229-001X FERRITE BEADS
K3184 NQR0229-001X FERRITE BEADS
K3281 NQR0229-001X FERRITE BEADS
K3282 NQR0229-001X FERRITE BEADS
K3283 NQR0229-001X FERRITE BEADS
K3284 NQR0229-001X FERRITE BEADS
K3381 NQR0229-001X FERRITE BEADS
K3382 NQR0229-001X FERRITE BEADS
K3383 NQR0229-001X FERRITE BEADS
K3384 NQR0229-001X FERRITE BEADS
K3481 NQR0229-001X FERRITE BEADS
K3482 NQR0229-001X FERRITE BEADS
K3483 NQR0229-001X FERRITE BEADS
K3484 NQR0229-001X FERRITE BEADS
K3701 NQR0269-004X FERRITE BEADS
K3702 NQR0269-004X FERRITE BEADS
K3703 QQR0779-001Z INDUCTOR
K3704 QQR0779-001Z INDUCTOR
LC635 NQR0322-001X EMI FILTER
LC640 NQR0322-001X EMI FILTER
LC645 NQR0322-001X EMI FILTER
LC650 NQR0322-001X EMI FILTER
LC661 NQR0322-001X EMI FILTER
LC666 NQR0322-001X EMI FILTER
LC667 NQR0322-001X EMI FILTER
LC668 NQR0322-001X EMI FILTER
LC669 NQR0322-001X EMI FILTER
LC670 NQR0322-001X EMI FILTER
LC671 NQR0322-001X EMI FILTER
LC673 NQR0322-001X EMI FILTER
LC691 NQR0322-001X EMI FILTER
LC692 NQR0322-001X EMI FILTER
Q
3103 2SC2412K/RS/-X CHIP TRANSISTOR
Q
3104 2SC2412K/RS/-X CHIP TRANSISTOR
Q
3105 DTA114YE-X TRANSISTOR
Q
3107 2SD1328/ST/-X TRANSISTOR
Q
3108 2SD1328/ST/-X TRANSISTOR
Q
3161 2SC2412K/RS/-X CHIP TRANSISTOR
Q
3162 2SC2412K/RS/-X CHIP TRANSISTOR
Q
3163 DTA114YE-X TRANSISTOR
Q
3203 2SC2412K/RS/-X CHIP TRANSISTOR
Q
3207 2SD1328/ST/-X TRANSISTOR
Q
3208 2SD1328/ST/-X TRANSISTOR
Q
3261 2SC2412K/RS/-X CHIP TRANSISTOR
Q
3263 DTA114YE-X TRANSISTOR
Q
3265 DTA114YE-X TRANSISTOR
Q
3266 2SD1328/ST/-X TRANSISTOR
Q
3291 DTC114YE-X TRANSISTOR
Q
3301 DTA114YE-X TRANSISTOR
Q
3303 2SC2412K/RS/-X CHIP TRANSISTOR
Q
3304 2SC2412K/RS/-X CHIP TRANSISTOR
Q
3307 2SD1328/ST/-X TRANSISTOR
Q
3308 2SD1328/ST/-X TRANSISTOR
Q
3361 2SC2412K/RS/-X CHIP TRANSISTOR
Q
3362 2SC2412K/RS/-X CHIP TRANSISTOR
Q
3363 DTA114YE-X TRANSISTOR
Q
3403 2SC2412K/RS/-X CHIP TRANSISTOR
Q
3404 2SC2412K/RS/-X CHIP TRANSISTOR
Q
3407 2SD1328/ST/-X TRANSISTOR
Q
3408 2SD1328/ST/-X TRANSISTOR
Q
3461 2SC2412K/RS/-X CHIP TRANSISTOR
Q
3462 2SC2412K/RS/-X CHIP TRANSISTOR
Q
3463 DTA114YE-X TRANSISTOR
Q
3921 DTC114YE-X TRANSISTOR
R 501 NRSA63J-750X MG RESISTOR
R 502 NRSA63J-750X MG RESISTOR
R 503 NRSA63J-750X MG RESISTOR
R 504 NRSA63J-750X MG RESISTOR
R 505 NRSA63J-750X MG RESISTOR
R 506 NRSA63J-750X MG RESISTOR
R 521 NRSA63J-472X MG RESISTOR
R 522 NRSA63J-472X MG RESISTOR
R 523 NRSA63J-102X MG RESISTOR
R 524 NRSA63J-112X MG RESISTOR
R 525 NRSA63J-473X MG RESISTOR
R 526 NRSA63J-750X MG RESISTOR
R 527 NRSA63J-472X MG RESISTOR
R 528 NRSA63J-472X MG RESISTOR
R 529 NRSA63J-102X MG RESISTOR
R 530 NRSA63J-112X MG RESISTOR
R 531 NRSA63J-473X MG RESISTOR
R 532 NRSA63J-750X MG RESISTOR
R 533 NRSA63J-472X MG RESISTOR
R 534 NRSA63J-472X MG RESISTOR
R 535 NRSA63J-102X MG RESISTOR
R 536 NRSA63J-112X MG RESISTOR
Item
Parts number Parts name Ar
e
a
Remarks
A
