JVC RX-E100SL - Page 33

RX-E100SL
3-4
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
1 LV10482-002A FRONT PANEL 1
2 VJD5429-002SS JVC MARK 1
3 E75896-003 FELT SPACER 2 FOR FRONT FOOT
4 LV20958-001A LENS 1
5 LV20991-002A POWER BUTTON 1
6 LV42096-001A INDICATOR 1
7 LV32517-001A CONTROL BUTTON 1
8 LV20959-002A SOURCE BUTTON 1
11 LV20992-001A VOLUME BUTTON 1
12 QYSBSF2608Z T.SCREW 2 F.C.B.POWER+F.PANEL
13 LV42195-001A FL SCREEN 1 TO FRONT PANEL
14 QYSBSF2608Z T.SCREW 7 F.C.B.FL+F.PANE
16 QUQ412-1738CJ FFC WIRE 1
17 QUQ412-1213CJ FFC WIRE 1
18 QYSBSG3006Z T.SCREW 4 F.PANEL+C.BASE
19 QYSBSG3006Z T.SCREW 3 F.PANEL+F.BKT
20 LV10019-003A CHASSIS BASE 1
21 LV10483-001A FRONT BRACKET 1
22 QYSBSG3006Z T.SCREW 5 C.BASE+F.BKT
23 E68587-223SM CB BKT 3
24 QYSBSG3006Z T.SCREW 3 CB BKT+C.BASE
25 E47227-021 FOOT ASS'Y 2
26 QYSBSG3006Z T.SCREW 2 FOOT ASS'Y+C.BASE
27 LV20960-001A HEAT SINK 1
28 E73525-003SS SCREW 10 TR
29 LV32433-001A H.S BRACKET
(
R
)
1
30 LV32434-001A H.S BRACKET
(
L
)
1
31 QYSBSG3008Z T.SCREW 4 H.SINK BKT+H.SINK
32 QYSBSG3006Z T.SCREW 2 H.SINK BKT+F.BKT
33 QYSBSG3006Z T.SCREW 2 AMP M.C.B+H.SINK BKT
34 QYSBSG3006Z T.SCREW 2 H.SINK BKT+C.BASE
35 QYSBSG3006Z T.SCREW 3 A.M.C.B+C.B.&CB BKT
36 LV42098-001A C.B BKT 1
37 QYSBSG3006Z T.SCREW 1 C.B.BKT+C.BASE
38 QYSBSG3006Z T.SCREW 3 T.C.B+C.BASE&F.BKT
39 QYSBSG3006Z T.SCREW 1 P.CORD C.B+C.BASE
40 QQT0327-001 POWER TRANSF
A
1 T201
41 QYSDSTL4008Z SPECIAL SCREW 4 P.TRANS
42 LV20961-008A REAR PANEL C1
LV20961-007A REAR PANEL J1
43 QYSBSGY3008M SPECIAL SCREW 3 R.PANEL+C.BASE
44 QYSBSGY3008M SPECIAL SCREW 1 R.PANEL+ud---
45 QYSBSGY3008M SPECIAL SCREW 2 TUNER
46 QUQ412-1607CJ FFC WIRE 1
48 QYSBSGY3008M SPECIAL SCREW 1 SUB WOOFER
49 QYSBSGY3008M SPECIAL SCREW 2 PIN JACK
51 QYSBSGY3008M SPECIAL SCREW 2 DIGITAL
52 QYSBSGY3008M SPECIAL SCREW 2 F.SPK TERM.+R.PANEL
(General assembly)
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
53 QYSBSGY3008M SPECIAL SCREW 2 R.SPK TERM.+R.PANEL
54 QYSBSG3006Z T.SCREW 3 INPUT M.C.B+C.BASE
55 QMPD220-200-JD POWER CORD
A
1
56 QZW0033-001 STRAIN RELIEF
A
1
57 LV20962-001A/S/ TOP COVER 1
58 QYSBSGY3008M SPECIAL SCREW 3
59 E406308-004 SPECIAL SCREW 4
60 QMF51U1-5R0-J8 FUSE
A
1 F201
61 QMF51U1-2R0-J8 FUSE
A
2 F202 F203
64 E409394-001 CAUTION LABEL J1
E409396-002 CAUTION LABEL C1
65 QYSBSG3008E T.SCREW 1
66 LV30225-0C1A FELT SPACER 2 FS400 FS401
67 QYSBSG3008E T.SCREW 1
68 QYSBSG3008E T.SCREW 1
69 QYSBSG3008E T.SCREW 2
70 QYSBSG3008E T.SCREW 1
72 LV42388-001A FUSE CAUTION 1 STICK ON REAR INSIDE
(General assembly)
