40
English
Specifications
Designs & specifications are subject to change without notice.
Amplifier
Output Power
At stereo operation:
Front channels: 100 W per channel, min. RMS, driven into
8 Ω , 40 Hz to 20 kHz with no more than 0.8%
total harmonic distortion.
At surround operation:
Front channels: 100 W per channel, min. RMS, driven into
8 Ω at 1 kHz with no more than 0.8% total
harmonic distortion.
Center channel: 100 W, min. RMS, driven into 8 Ω at 1 kHz,
with no more than 0.8% total harmonic
distortion.
Surround channels: 100 W per channel, min. RMS, driven into
8 Ω at 1 kHz, with no more than 0.8% total
harmonic distortion.
Audio
Audio Input Sensitivity/Impedance (1 kHz):
DVD, DVD MULTI, DBS, VCR, TV:
260 mV/47 kΩ
Audio Input (DIGITAL IN)* :
Coaxial: DIGITAL 1 (DVD): 0.5 V(p-p)/75 Ω
Optical: DIGITAL 2/3 (DBS/TV):
–21 dBm to –15 dBm
(660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital
Surround (with sampling frequency—32 kHz, 44.1 kHz, 48 kHz).
Audio Output Level: VCR: 250 mV
Signal-to-Noise Ratio (’66 IHF/’78 IHF):
DVD MULTI: 87 dB/67 dB
Frequency Response (8 Ω):
DVD, DBS, VCR, TV: 20 Hz to 20 kHz (±1 dB)
Tone Control:
Bass (100 Hz): ±10 dB ±2 dB
Treble (10 kHz): ±10 dB ±2 dB
Bass Boost: +4 dB ± 1 dB at 100 Hz
Video
Video Input Sensitivity/Impedance (1 kHz):
Composite video:DVD, DBS, VCR:
1 V(p-p)/75 Ω
S-Video:DVD, DBS, VCR:
(Y:luminance): 1 V(p-p)/75 Ω
(C:chrominance): 0.286 V(p-p)/75 Ω
Component video:DVD, DBS:
(Y:luminance): 1 V(p-p)/75 Ω
(RB/PR): 0.7 V(p-p)/75 Ω
Video Output Level/Impedance (1 kHz):
Composite video: VCR, MONITOR OUT:
1 V(p-p)/75 Ω
S-Video: VCR, MONITOR OUT:
(Y:luminance): 1 V(p-p)/75 Ω
(C:chrominance): 0.286 V(p-p)/75 Ω
Component video: MONITOR OUT:
(Y:luminance): 1 V(p-p)/75 Ω
(RB/PR): 0.7 V(p-p)/75 Ω
Synchronize: Negative
FM tuner (IHF)
Tuning Range: 87.5 MHz to 108.0 MHz
Usable Sensitivity:
Monaural: 12.8 dBf (1.2 µV/75 Ω)
50 dB Quieting Sensitivity:
Monaural: 16.0 dBf (1.7 µV/75 Ω)
Stereo: 37.5 dBf (20.5 µV/75 Ω)
Stereo Separation at REC OUT: 35 dB at 1 kHz
AM tuner
Tuning Range: 530 kHz to 1 710 kHz
General
Power Requirements: AC 120 V , 60 Hz
Power Consumption: 95 W/130 VA (at operation)
2 W (in standby mode)
Dimensions (W x H x D):
17
3
/
16
inches x 2
3
/
4
inches x 13
1
/
16
inches
(435 mm x 69.5 mm x 330.5 mm)
Mass: 14.4 lbs (6.5 kg)
RX-ES1SL
