JVC SP-PW100 Service Manual

3-7
SP-PW100
Item
Parts number Parts name Ar
ea
Remarks
A
RY881 QSK0109-001 RELAY
A
R8101 QRE141J-474Y C RESISTOR 470K 5% 1/4W
R8102 QRE141J-474Y C RESISTOR 470K 5% 1/4W
R8103 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R8104 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R8105 QRE141J-683Y C RESISTOR 68K 5% 1/4W
R8106 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R8107 QRE141J-182Y C RESISTOR 1.8K 5% 1/4W
R8108 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R8109 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R8110 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R8111 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R8112 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R8113 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R8114 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R8115 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R8116 QRE141J-393Y C RESISTOR 39K 5% 1/4W
R8117 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R8118 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R8119 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R8120 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R8121 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R8122 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R8123 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R8124 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R8125 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R8126 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R8127 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R8128 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R8129 QRE141J-684Y C RESISTOR 680K 5% 1/4W
R8201 QRZ9005-100X F RESISTOR
A
10 1/4W
R8202 QRZ9015-101X F RESISTOR
A
100 1/4W
R8203 QRZ9015-101X F RESISTOR
A
100 1/4W
R8204 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R8205 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R8206 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R8207 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R8208 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R8209 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R8210 QRT01DJ-R33X MF RESISTOR
A
5% 1W
R8211 QRT01DJ-R33X MF RESISTOR
A
5% 1W
R8212 QRE141J-122Y C RESISTOR 1.2K 5% 1/4W
R8213 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R8214 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R8215 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R8216 QRZ9005-100X F RESISTOR
A
10 1/4W
R8217 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R8218 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R8219 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R8220 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R8221 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R8222 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R8223 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R8224 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R8225 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R8226 QRE141J-561Y C RESISTOR 560 5% 1/4W
R8227 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R8228 QRE141J-271Y C RESISTOR 270 5% 1/4W
R8229 QRT01DJ-R33X MF RESISTOR
A
5% 1/1W
R8233 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R8252 QRE141J-100Y C RESISTOR 10 5% 1/4W
R8501 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R8502 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R8503 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R8504 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R8505 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R8506 QRE141J-105Y C RESISTOR 1.0M 5% 1/4W
R8507 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R8512 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R8514 QRE141J-105Y C RESISTOR 1.0M 5% 1/4W
R8515 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R8516 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R8517 QRE141J-564Y C RESISTOR 560K 5% 1/4W
R8518 QRE141J-220Y C RESISTOR 22 5% 1/4W
R8519 QRE141J-514Y C RESISTOR 510K 5% 1/4W
R8520 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R8521 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R8522 QRE141J-181Y C RESISTOR 180 5% 1/4W
R8523 QRE141J-220Y C RESISTOR 22 5% 1/4W
R8701 QRZ9005-100X F RESISTOR
A
10 1/4W
R8702 QRZ9005-100X F RESISTOR
A
10 1/4W
R8703 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R8704 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R8705 QRZ9005-100X F RESISTOR
A
10 1/4W
R8801 QRJ146J-222X UNF C RESISTOR
A
2.2K 5% 1/4W
R8802 QRJ146J-222X UNF C RESISTOR
A
2.2K 5% 1/4W
R8803 QRJ146J-222X UNF C RESISTOR 2.2K 5% 1/4W
R8811 QRE141J-622Y C RESISTOR 6.2K 5% 1/4W
R8812 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R8921 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R8922 QRZ9006-4R7X F RESISTOR
A
4.7 1/4W
S8101 QSW0834-001 PUSH SWITCH PHASE CHANGE
S8901 QSW0632-001 PUSH SWITCH
A
VR811 QVQ0021-B14 V RESISTOR
VR812 QVQ0300-B24 V.RES.
WC881 QZW0038-001 WIRE CLAMP
Z 892 QNG0003-001Z FUSE CLIP
A
Z 893 QNG0003-001Z FUSE CLIP
A
Z 894 QNG0003-001Z FUSE CLIP
A
Z 895 QNG0003-001Z FUSE CLIP
A
Z 897 QNG0003-001Z FUSE CLIP
A
Z 898 QNG0003-001Z FUSE CLIP
A
Electrical parts list (Main board)
Block No. 01
Item
Parts number Parts name Ar
ea
Remarks
A

JVC SP-PW100 Specifications

General

Brand	JVC
Model	SP-PW100
Category	Subwoofer
Language	English
