SP-PW100
1-3
Remove the front net from the four holders that are
fixing the front net.
Note:
1.
2.
3.
Disassembly method
<Main body>
Removing the front net (See Fig.1, 2)
Remove the front net.
Remove the six screws A attaching the woofer.
Pull out the woofer toward you.
Remove the speaker cord.
Removing the woofer (See Fig.3, 4)
When it is hard to remove the front net, insert a
minus driver, etc. in the place between the
main body and the front net as shown in Fig.2
before removing the front net. Exercise care
not to damage the main body and the front net
when inserting the minus driver. For this
purpose, insert the minus driver together with
cloth and the like.
Fig.1
Fig.2
Fig.3
Fig.4
Main body
Front net
Woofer
Speaker cord (Red, Black)
Woofer
A
A
Front net
To Next Page
