Introduction
The numbers refer to the pages in which the parts are explained.
■ Activating the buttons on the main unit
Before using the buttons on the main unit, place
your hand over the front of the main unit. The but-
tons, controls and indicators gradually start illumi-
nating.
■ Using the ¢/4 and [VOL +/–] controls
To operate the ¢/4 control on the right front
of the main unit, vertically slide your finger on the
area between ¢ and 4.
Similarly, to operate the [VOL +/–] control, slide your
finger on the
area
between [VOL +] and [VOL –].
■ Opening the front cover
To use the buttons and terminals concealed under
the front cover, use your finger to pull open the part
indicated with [ 2 PULL OPEN].
Front view
Remote control sensor
Refer to “Display window” shown on page 4.
Rear view
Part description
* The [MIC] terminal and the [MIC VOLUME] control are provided only on the models for countries/areas
other than Australia.
