JVC SR-HD1250US - Page 22

3-6(No.YD125<Rev.001>)
Terminal board
Block No. [0][6]
OPE board
Block No. [0][7]
R7442 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R7443 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R7451 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R7452 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R7453 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R7454 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R7455 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R7456 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
BZ7401 QAN0023-001Z BUZZER
CN7401 QGF1045F2-21X CONNECTOR FFC/FPC (1-21)
CN7402 QGF1208F1-07 CONNECTOR FFC/FPC (1-7)
CN7403 QGA2001C1-02 CONNECTOR W-B (1-2)
DI7401 QLF0200-001 FL TUBE
HD1 LS31285-001A FL HOLDER(L)
HD2 LS31286-001A FDP HOLDER(R)
S7432 QSW0683-001Z PUSH SWITCH
S7433 QSW0683-001Z PUSH SWITCH
S7434 QSW0683-001Z PUSH SWITCH
S7435 QSW0683-001Z PUSH SWITCH
S7441 QSW0683-001Z PUSH SWITCH
S7442 QSW0683-001Z PUSH SWITCH
S7443 QSW0683-001Z PUSH SWITCH
S7451 QSW0683-001Z PUSH SWITCH
S7452 QSW0683-001Z PUSH SWITCH
S7453 QSW0683-001Z PUSH SWITCH
S7454 QSW0683-001Z PUSH SWITCH
S7455 QSW0683-001Z PUSH SWITCH
S7456 QSW0683-001Z PUSH SWITCH
 Symbol No. Part No. Part Name Description Local
PW1 LSA10109-01A2H TERMINAL BOARD ASSY
IC301 MM1757FH-X IC
Q301 RT1N44HC-X DIGI TRANSISTOR
Q302 RT1N44HC-X DIGI TRANSISTOR
Q1101
2SC2412K/QRS/-X TRANSISTOR
Q1102
2SC2412K/QRS/-X TRANSISTOR
Q1103 RT1P44HC-X DIGI TRANSISTOR
Q1104
2SC2412K/QRS/-X TRANSISTOR
Q1105
2SC2412K/QRS/-X TRANSISTOR
C201 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C301 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C302 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C303 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C304 NCB31AK-105X C CAPACITOR 1uF 10V K
C305 NCB31AK-105X C CAPACITOR 1uF 10V K
C306 NCB31AK-105X C CAPACITOR 1uF 10V K
C307 NCB31AK-105X C CAPACITOR 1uF 10V K
C308 NEHM0JM-107X E CAPACITOR 100uF 6.3V M
C309 QETN1AM-477Z E CAPACITOR 470uF 10V M
C310 QETN1AM-477Z E CAPACITOR 470uF 10V M
C312 QETN0JM-108Z E CAPACITOR 1000uF 6.3V M
C313 QETN0JM-108Z E CAPACITOR 1000uF 6.3V M
C315 QETN0JM-108Z E CAPACITOR 1000uF 6.3V M
C317 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C318 NEHM0JM-226X E CAPACITOR 22uF 6.3V M
C322 NCB31AK-105X C CAPACITOR 1uF 10V K
C1111 NEHM1CM-226X E CAPACITOR 22uF 16V M
C1112 NEHM1CM-226X E CAPACITOR 22uF 16V M
C1113 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1114 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1117 NEHM1CM-226X E CAPACITOR 22uF 16V M
C1118 NEHM1CM-226X E CAPACITOR 22uF 16V M
C1119 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1120 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1123 NEHM1CM-106X E CAPACITOR 10uF 16V M
 Symbol No. Part No. Part Name Description Local
C1124 NEHM1CM-106X E CAPACITOR 10uF 16V M
C1127 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R201 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R202 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R205 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R301 NRSA63D-750X MG RESISTOR 75
Ω 1/16W D
R302 NRSA63D-750X MG RESISTOR 75
Ω 1/16W D
R303 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R307 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R308 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R309 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R314 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R315 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R316 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R317 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R318 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R319 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R320 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R321 NRSA63D-750X MG RESISTOR 75
Ω 1/16W D
R322 NRSA63D-750X MG RESISTOR 75
Ω 1/16W D
R323 NRSA63D-750X MG RESISTOR 75
Ω 1/16W D
R324 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
R325 NRSA63D-472X MG RESISTOR 4.7k
Ω 1/16W D
R326 NRSA63D-472X MG RESISTOR 4.7k
Ω 1/16W D
R327 NRSA63D-512X MG RESISTOR 5.1k
Ω 1/16W D
R328 NRSA63D-512X MG RESISTOR 5.1k
Ω 1/16W D
R1125 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R1126 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R1127 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R1128 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R1129 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R1130 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R1131 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1132 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1133 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1134 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1137 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R1138 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R1139 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R1140 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R1141 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1142 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1143 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1144 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1145 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1146 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1147 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
L301 QQL342J-4R7Z COIL 4.7uH J
CN201 QGB1231M1-23 CONNECTOR B-B (1-23)
CN202 QGB1231M1-23 CONNECTOR B-B (1-23)
CN203 QGF1208C1-05 CONNECTOR FFC/FPC (1-5)
CN204 QGA2001C1-02 CONNECTOR W-B (1-2)
CN205 QGA2001C1-03 CONNECTOR W-B (1-3)
J302 QND0159-001 S JACK
J303 QNZ0154-001 BNC CONNECTOR
J304 QNS0258-001 3.5 JACK
J1101 QNN0854-001 PIN JACK
 Symbol No. Part No. Part Name Description Local
PW1 LSA10110-01A2H OPE BOARD ASSY
CN7404 QGA2001C1-02 CONNECTOR W-B (1-2)
S7431 QSW0683-001Z PUSH SWITCH
 Symbol No. Part No. Part Name Description Local
