JVC SR-HD1250US - Page 23

(No.YD125<Rev.001>)3-7
OPT DIGI board
Block No. [0][8]
D-SUB/BNC board
Block No. [0][9]
 Symbol No. Part No. Part Name Description Local
PW1 LSA10110-01A3H OPT DIGI BOARD ASSY
IC701 GP1FAV31TK0F OPT TRANSMITTER
C701 NEHM0JM-226X E CAPACITOR 22uF 6.3V M
C702 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R701 NRSA63J-4R7X MG RESISTOR 4.7
Ω 1/16W J
R702 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
CN701 QGB1238J1-11 CONNECTOR B-B (1-11)
 Symbol No. Part No. Part Name Description Local
PW1 LSA10110-02A4H D-SUB/BNC BOARD ASSY 1250EU,1250US
PW1 LSA10110-01A4H D-SUB/BNC BOARD ASSY
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
IC401 MAX3221CAE-E-X IC
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
D401 MA8120-X Z DIODE
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
D402 MA8120-X Z DIODE
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
D403 MA8120-X Z DIODE
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
D404 MA8120-X Z DIODE
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
C401 NCB31EK-104X C CAPACITOR 0.1uF 25V K
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
C402 NCB31EK-104X C CAPACITOR 0.1uF 25V K
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
C403 NCB31EK-104X C CAPACITOR 0.1uF 25V K
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
C404 NCB31EK-104X C CAPACITOR 0.1uF 25V K
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
C405 NCB31EK-104X C CAPACITOR 0.1uF 25V K
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
R401 NRSA63J-0R0X MG RESISTOR 0 Ω 1/10W J
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
R402 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
R403 NRSA63J-0R0X MG RESISTOR 0 Ω 1/10W J
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
R404 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
R405 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
R406 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R407 NRSA63D-750X MG RESISTOR 75
Ω 1/16W D
R408 NRSA63J-0R0X MG RESISTOR 0
Ω 1/10W J
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
CN401 QGF1208F1-05 CONNECTOR FFC/FPC (1-5)
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
CN402 QGA2001C1-02 CONNECTOR W-B (1-2)
CN403 QGA2001F1-03 CONNECTOR W-B (1-3)
J401 QNZ0560-002 D CONNECTOR
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
J402 QNZ0540-001 BNC CONNECTOR
K401 NQR0499-001X FERRITE BEADS
1500AC,1500AG,1500ER,
1500EU,1500KR,1500US
