Specifications shown are for SP mode unless specified otherwise.
● E. & O.E. Design and specifications subject to change without
notice. Don’t service the product yourself.
Specifications
GENERAL
Power requirement : AC 120 Vd, 60 Hz
Power consumption
Power on : 19 W
Power off : 1.6 W
Temperature
Operating : 5°C to 40°C (41°F to 104°F)
Storage : –20°C to 60°C (–4°F to140°F)
Operating position : Horizontal only
Dimensions (W x H x D) : 435 mm x 94 mm x 242 mm
(17-3/16" x 3-3/4" x 9-3/4")
Weight : 2.8 kg (6.2 lbs)
Format : S-VHS/VHS NTSC standard
Maximum recording time
SP : 210 min. with ST-210 video cassette
EP : 630 min. with ST-210 video cassette
VIDEO/AUDIO
Signal system : NTSC-type color signal and EIA
monochrome signal, 525 lines/
60 fields
Recording/Playback
system
: DA-4 (Double Azimuth) head helical
scan system
Signal-to-noise ratio : 45 dB
Horizontal resolution
VHS : 230 lines
S-VHS : 400 lines
Frequency range
Normal audio : 70 Hz to 10,000 Hz
Hi-Fi audio : 20 Hz to 20,000 Hz
Input/Output : RCA connectors (IN x 2, OUT x 1)
S-video connectors (IN x 2, OUT x 1)
TUNER
Tuning system : Frequency-synthesized tuner
Channel coverage
VHF : Channels 2–13
UHF : Channels 14–69
CATV : 113 Channels
RF output : Channel 3 or 4 (switchable; preset to
Channel 3 when shipped) 75 ohms,
unbalanced
TIMER
Clock reference : Quartz
Program capacity : 1-year programmable timer/
8programs
Memory backup time : Approx. 27 months
Estimated figure base on supplied
fresh battery; actual performance may
differ.
ACCESSORIES
Provided accessories : Infrared remote control unit,
“AA” battery x 2,
S-video cable (4-pin),
RF cable (F-type)
Audio/Video cable
BNC/RCA adapter x 2
