SPECIFICATIONS
Type : Double cassette deck
Track system : 4-track, 2-channel
Tape speed : 4.8 cm/sec (1-7/8 inch/sec) (Normal)
9.5 cm/sec (3-3/4 inch/sec) (High)
Frequency
response
: (–20 dB recording)
Type IV tape ; 20–17,000 Hz
30–16,000 Hz (±3dB)
Type II tape ; 20–16,000 Hz
30–15,000 Hz (±3dB)
Type I tape ; 20–16,000 Hz
30–15,000 Hz (±3dB)
S/N ratio : 58 dB (S = 315 Hz, k3 = 3%,
N = A-weighted, Type IV tape)
The S/N is improved by about 15 dB at
500 Hz and by max. 20 dB at 1 kHz z
10 kHz with Dolby C NR on and
improved by 5 dB at 1 kHz and by
10 dB at above 5 kHz with Dolby B NR
on.
Improvement of
MOL
: 4 dB at 10 kHz with Dolby C NR on.
Wow and flutter : 0.08% (WRMS), ±0.2% (DIN/IEC)
Channel
separation
: 40 dB (1 kHz)
Crosstalk : 60 dB (1 kHz)
Harmonic
distortion
: k3; 0.8% (Type IV tape, 315 Hz, 0 VU)
Heads : Deck A; METAPERM head for playback
x1
Deck B; METAPERM head for
recording/playback, 2-gap fer-
rite head for erasure; combina-
tion head x 1
Motors : Electric governed DC motor for capstan
x1
DC motor for reel x 1
DC motor for mechanism drive x 1
(For both decks A and B)
Fast forward/rewind
time
: Approx. 110 sec. with C-60 cassette
Input terminals
LINE IN
(x 1 circuit)
: Input sensitivity; 80 mV (0 VU)
Input impedance; 50 kΩ
MICx1
(Monaural)
: Input sensitivity; 0.4m V (–68dBV)
(0 VU)
Matching impedance; 600 Ω z 10 kΩ
Output terminals
LINE OUT
(x 1 circuit)
: Output level; 300 mV (0 VU)
Output impedance; 5 kΩ
PHONES x 1 : Output level; 0.3 mW/8 Ω (0 VU)
Matching impedance 8 Ω–1 kΩ
Other terminals : COMPU LINK-3/SYNCHRO x 2
Power
requirement : AC 230 V, 50 Hz (B version)
AC 120 V, 60 Hz (J version)
Power
consumption : With power on 17 W
With power standby 4.0 W
Dimensions
(WxHxD)
: 435 x 139 x 331 mm
(17-3/16’’ x 5-1/2’’ x 13-1/16’’)
Mass : 5.1 kg (11.3 lbs.) (B version)
5.0 kg (11.1 lbs.) (J version)
Accessories : Pin plug cord ....................................... 2
Remote cable ...................................... 1
Design and specifications are subject to change without notice.
