39
7 Center unit (XV-THC60/XV-THC30)
Audio section
Digital input*:
DIGITAL IN (DBS): –21 dBm to –15 dBm
(OPTICAL) (660 nm E30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital
Surround (with sampling frequency — 32 kHz, 44.1 kHz,
48 kHz)
Analog input: AUX IN (VCR)
Video section
Video System: PAL/NTSC
Horizontal Resolution: 500 lines
Signal-to-Noise Ratio: 64 dB
Video output level
Composite: 1.0 V(p-p)/75 Ω
S-video-Y: 1.0 V(p-p)/75 Ω
S-video-C: For PAL: 0.3 V(p-p)/75 Ω
For NTSC: 0.286 V(p-p)/75 Ω
Component-Y: 1.0 V(p-p)/75 Ω
Component-P
B/PR: 0.7 V(p-p)/75 Ω
Video input sensitivity/Impedance (VCR IN)
Composite: 1.0 V(p-p)/75 Ω
S-video-Y: 1.0 V(p-p)/75 Ω
S-video-C: For PAL: 0.3 V(p-p)/75 Ω
For NTSC: 0.286 V(p-p)/75 Ω
USB storage
USB specification: Compatible with the USB 2.0 Full-
Speed
Compatible device: Mass Storage Class
Compatible file system: FAT16, FAT32
Bus power supply: Max. 500 mA
Tuner section
Tuning Range
FM: 87.50 MHz to 108.00 MHz
AM: At 10 kHz intervals
530 kHz to 1 710 kHz
At 9 kHz intervals
531 kHz to 1 710 kHz
General
Power Requirements: AC 110-240 V , 50/60 Hz
Power Consumption: 25 W (at operation)
1.2 W (in standby mode)
Dimensions (W M H M D):
400 mm M 85 mm M 316 mm
Mass: 3.8 kg
7 Subwoofer (SP-PWC60)
Amplifier section
Front/Center/Surround: 135 W per channel, RMS at 4 Ω at
1 kHz, with 10 % total harmonic
distortion.
Subwoofer: 135 W, RMS at 4 Ω at 100 Hz, with
10 % total harmonic distortion.
Speaker section
Speaker unit: 16 cm Bass-reflex
Power Handling Capacity: 140 W
Impedance: 4 Ω
Frequency Range: 30 Hz to 200 Hz
Sound Pressure Level: 75 dB/
W·m
General
Power Requirements: AC 110 V/ AC 127 V/
AC 220 - 240 V , 50/60 Hz
Power Consumption: 135 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):
171 mm M 411 mm M 458 mm
Mass: 12.3 kg
7 Subwoofer (SP-PWC30)
Amplifier section
Front/Center/Surround: 135 W per channel, RMS at 4 Ω at
1 kHz, with 10 % total harmonic
distortion.
Subwoofer: 135 W, RMS at 4 Ω at 100 Hz, with
10 % total harmonic distortion.
Speaker section
Speaker unit: 16 cm Bass-reflex
Power Handling Capacity: 140 W
Impedance: 4 Ω
Frequency Range: 30 Hz to 200 Hz
Sound Pressure Level: 74 dB/
W·m
General
Power Requirements: AC 110 V/ AC 127 V/
AC 220 - 240 V , 50/60 Hz
Power Consumption: 135 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):
170 mm M 411 mm M 458 mm
Mass: 11.5 kg
Specifications
References
TH-C6030[UW].book Page 39 Tuesday, August 1, 2006 3:49 PM
