40
7 Center unit (XV-THC90)
Audio section
Digital input*:
DIGITAL IN (DBS): –21 dBm to –15 dBm
(OPTICAL) (660 nm E30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital
Surround (with sampling frequency — 32 kHz, 44.1 kHz,
48 kHz)
Analog input: AUX IN (VCR)
TAPE IN
Analog output: TAPE OUT
Video section
Video System: PAL/NTSC
Horizontal Resolution: 500 lines
Signal-to-Noise Ratio: 64 dB
Video output level
Composite: 1.0 V(p-p)/75 Ω
S-video-Y: 1.0 V(p-p)/75 Ω
S-video-C: For PAL: 0.3 V(p-p)/75 Ω
For NTSC: 0.286 V(p-p)/75 Ω
Component-Y: 1.0 V(p-p)/75 Ω
Component-P
B/PR: 0.7 V(p-p)/75 Ω
Video input sensitivity/Impedance (VCR IN)
Composite: 1.0 V(p-p)/75 Ω
S-video-Y: 1.0 V(p-p)/75 Ω
S-video-C: For PAL: 0.3 V(p-p)/75 Ω
For NTSC: 0.286 V(p-p)/75 Ω
USB storage
USB specification: Compatible with the USB 2.0 Full-
Speed
Compatible device: Mass Storage Class
Compatible file system: FAT16, FAT32
Bus power supply: Max. 500 mA
Tuner section
Tuning Range
FM: 87.50 MHz to 108.00 MHz
AM: At 10 kHz intervals
530 kHz to 1 710 kHz
At 9 kHz intervals
531 kHz to 1 710 kHz
General
Power Requirements: AC 240 V , 50 Hz
Power Consumption: 25 W (at operation)
1.2 W (in standby mode)
Dimensions (W M H M D):
400 mm M 85 mm M 316 mm
Mass: 3.8 kg
7 Subwoofer (SP-PWC90)
Amplifier section
Front/Center/Surround: 140 W per channel, RMS at 4 Ω at
1 kHz, with 10 % total harmonic
distortion.
Subwoofer: 300 W, RMS at 4 Ω at 40 Hz, with 10 %
total harmonic distortion.
Speaker section
Speaker unit: 25 cm Bass-reflex
Power Handling Capacity: 300 W
Impedance: 4 Ω
Frequency Range: 25 Hz to 200 Hz
Sound Pressure Level: 74 dB/
W·m
General
Power Requirements: AC 110 V/ AC 127 V/
AC 220 - 240 V , 50/60 Hz
Power Consumption: 110 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):
264 mm M 481 mm M 459 mm
Mass: 17.6 kg
7 Satellite Speakers — SP-XTHC90
Front speakers (SP-THC90F)
Type: 2-way 3-speaker Bass reflex type
(Magnetically shielded Type)
Speaker: 13.5 cm cone M 2
6.0 cm cone M 1
Power Handling Capacity: 140 W
Impedance: 4 Ω
Frequency Range: 60 Hz to 20 000 Hz
Sound Pressure Level: 89 dB/
W·m
Dimensions (W M H M D):
270 mm M 1 027.5 mm M 320 mm
Mass: 8.8 kg each
Center speaker (SP-THC90C)
Type: 2-way 3-speaker Bass reflex type
(Magnetically shielded Type)
Speaker: 10.5 cm cone M 2
4.0 cm cone M 1
Power Handling Capacity: 140 W
Impedance: 4 Ω
Frequency Range: 65 Hz to 20 000 Hz
Sound Pressure Level: 89 dB/
W·m
Dimensions (W M H M D):
400 mm M 141 mm M 171.5 mm
Mass: 3.8 kg
Surround speakers (SP-THC90S)
Type: 2-way Bass reflex type
Speaker: 10.5 cm cone M 1
4.0 cm cone M 1
Power Handling Capacity: 140 W
Impedance: 4 Ω
Frequency Range: 75 Hz to 20 000 Hz
Sound Pressure Level: 81 dB/
W·m
Dimensions (W M H M D):
140 mm M 228.5 mm M 174 mm
Mass: 1.7 kg each
Designs & specifications are subject to change without notice.
Specifications
References
