35
Center unit (XV-THD7/XV-THD5)
Output power
Front:
140 W per channel, RMS at 4 Ω at 1 kHz, with 10 % total
harmonic distortion.
Center:
130 W, RMS at 4 Ω at 1 kHz, with 10 % total harmonic
distortion.
Surround:
130 W per channel, RMS at 4 Ω at 1 kHz, with 10 % total
harmonic distortion.
Subwoofer:
140 W, RMS at 4 Ω at 100 Hz, with 10 % total harmonic
distortion.
Audio section
Digital Input*
DIGITAL IN
OPTICAL: –21 dBm to –15 dBm (660 nm
±30 nm)
Only for XV-THD7
COAXIAL: 0.5 V(p-p)/75 Ω
Analog input: For XV-THD7:
VIDEO 2 AUDIO IN
For XV-THD5:
AUDIO IN
Analog output: Only for XV-THD7:
AUDIO OUT
Video section
Video System: PAL/NTSC
Horizontal Resolution: 500 lines
Signal-to-Noise Ratio: 64 dB
Video Output Level
Composite: 1.0 V(p-p)/75 Ω
S-video-Y: 1.0 V(p-p)/75 Ω
S-video-C: For PAL: 0.3 V(p-p)/75 Ω
For NTSC: 0.286 V(p-p)/75 Ω
Component-Y: 1.0 V(p-p)/75 Ω
Component-P
B/PR: 0.7 V(p-p)/75 Ω
Video Input Sensitivity/Impedance
(VIDEO IN for XV-THD5/VIDEO 2 IN for XV-THD7)
Composite: 1.0 V(p-p)/75 Ω
S-video-Y: 1.0 V(p-p)/75 Ω
S-video-C: For PAL: 0.3 V(p-p)/75 Ω
For NTSC: 0.286 V(p-p)/75 Ω
HDMI
HDMI Input (VIDEO 1 IN) (Only for XV-THD7):
PASS THROUGH (up to 225 MHz)
HDMI Output (MONITOR OUT):
For PAL: 576p/720p/1080i
For NTSC: 480p/720p/1080i
USB storage
USB Specification: Compatible with USB 2.0 Full
Speed
Compatible Device: Mass Storage Class
Compatible File System: FAT16, FAT32
Bus Power Supply: Max. 500 mA
Tuner section
Tuner Range
FM: 87.50 MHz to 108.00 MHz
AM:
At 10 kHz intervals
For Saudi Arabia: 530 kHz to 1 600 kHz
For the other countries: 530 kHz to 1 710 kHz
At 9 kHz intervals
For Saudi Arabia: 531 kHz to 1 602 kHz
For the other countries: 531 kHz to 1 710 kHz
General
Power Requirements:
AC 110 V/127 V/220 V - 240 V , 50/60 Hz
(selectable with the voltage selector)
Power Consumption: 160 W (during operation)
4.0 W (in standby mode)
Dimensions (W
× H × D): 435 mm × 115 mm × 270 mm
Mass: 6.8 kg
* Corresponding to Linear PCM, Dolby Digital, and DTS
Digital Surround (with sampling frequency — 32 kHz,
44.1 kHz, 48 kHz)
Subwoofer
For SP-THD7W (TH-D7)
Type: Bass-Reflex Type
Speaker: 20 cm cone
× 1
Power Handling Capacity: 140 W
Impedance: 4 Ω
Frequency Range: 28 Hz to 200 Hz
Sound Pressure Level: 75 dB/W
•m
Dimensions (W
× H × D): 353.5 mm × 351 mm × 248 mm
Mass: 8.5 kg
For SP-THD5W (TH-D5)
Type: Bass-Reflex Type
Speaker: 16 cm cone
× 1
Power Handling Capacity: 140 W
Impedance: 4 Ω
Frequency Range: 30 Hz to 200 Hz
Sound Pressure Level: 75 dB/W
•m
Dimensions (W
× H × D): 353.5 mm × 351 mm × 174 mm
Mass: 6.3 kg
Specifications
References
TH-D7D5[U]EN.book Page 35 Wednesday, June 13, 2007 10:19 AM
