SPECIFICATION
Center unit (XV-THS3)
*1 : Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with sampling frequency - 32 kHz, 44.1 kHz, 48kHz)
Front speakers (SP-THS3F)
Center speaker (SP-THS3F)
Surround speakers (SP-THS3F)
Subwoofer (SP-WS3)
Designs & specifications are subject to change without notice.
Audio section Total Harmonic Distortion 0.02%
Digital input*1 OPTICAL DIGITAL IN: -21 dBm to -15 dBm (660 nm E30 nm)
Video section Video System PAL
Horizontal Resolution 500 lines
Signal-to-Noise Ratio 64 dB (Composite signal when "RGB" is selected)
Video output level Composite: 1.0 V(p-p)/75 W
S-video-Y: 1.0 V(p-p)/75 Ω
S-video-C: 0.3 V(p-p)/75 Ω
Component-Y: 1.0 V(p-p)/75 Ω
Component-PB/PR: 0.7 V(p-p)/75 Ω
Tuner section Tuning Range FM: 87.50 MHz to 108.00 MHz
AM: 522 kHz to 1 629 kHz
General Power Requirements AC 230 V , 50 Hz
Power Consumption 75 W (at operation), 1.0 W (in standby mode)
Dimensions (W × H × D) 360 mm × 65 mm × 370 mm
Mass 5.3 kg
Type 1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker 8.0 cm cone M 1
Power Handling Capacity 52 W
Impedance 6 Ω
Frequency Range 85 Hz to 20 000 Hz
Sound Pressure Level 82 dB/W·m
Dimensions (W × H × D) 105 mm × 118 mm × 98 mm
Mass 0.60 kg each
Type 1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker 8.0 cm cone M 1
Power Handling Capacity 52 W
Impedance 6 Ω
Frequency Range 85 Hz to 20 000 Hz
Sound Pressure Level 82 dB/W·m
Dimensions (W × H × D) 105 mm × 118 mm × 98 mm
Mass 0.65 kg
Type 1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker 8.0 cm cone M 1
Power Handling Capacity 52 W
Impedance 6 Ω
Frequency Range 85 Hz to 20 000 Hz
Sound Pressure Level 80 dB/W·m
Dimensions (W × H × D) 105 mm × 118 mm × 98 mm
Mass 0.55 kg each
Type 1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker 16.0 cm cone M 1
Power Handling Capacity 52 W
Impedance 6 Ω
Frequency Range 40 Hz to 1 800 Hz
Sound Pressure Level 85 dB/W·m
Dimensions (W × H × D) 139 mm × 350 mm × 408 mm
Mass 4.0 kg
