JVC TH-S3

3-16
Trans board
Block No. [0][2][0][0]
 Symbol No. Part No. Part Name Description Local
Q951 KTB772/Y/ TRANSISTOR
Q952 KTC3199/GL/-T TRANSISTOR
Q953 KTC3199/GL/-T TRANSISTOR
Q954 KTC3199/GL/-T TRANSISTOR
Q955 KTC3199/GL/-T TRANSISTOR
Q3400 KRC102M-T DIGI TRANSISTOR
S3B,
S3E,
S3EE,
S3EN,
S3EV
Q3401 KRC102M-T DIGI TRANSISTOR
S3B,
S3E,
S3EE,
S3EN,
S3EV
Q3402 KRA102M-T DIGI TRANSISTOR
S3B,
S3E,
S3EE,
S3EN,
S3EV
Q3403 KRC102M-T DIGI TRANSISTOR
S3B,
S3E,
S3EE,
S3EN,
S3EV
D950 1SS133-T2 DIODE
D951 1N4003S-T5 SI DIODE
D953 MTZJ5.6B-T2 Z DIODE
D954 MTZJ3.6B-T2 Z DIODE
D955 1N4003S-T5 SI DIODE
 C950 QCZ9105-472 C CAPACITOR 4700pF 250V M
C951 QETM1EM-108 E CAPACITOR 1000uF 25V M
C954 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C955 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C956 QETN1HM-106Z E CAPACITOR 10uF 50V M
C957 QETN1CM-107Z E CAPACITOR 100uF 16V M
C958 QETN1CM-107Z E CAPACITOR 100uF 16V M
 C959 QFZ9075-683 MPP CAPACITOR 0.068uF AC275V M
 C960 QCZ9079-101 C CAPACITOR 100pF AC250V K
 C961 QCZ9079-101 C CAPACITOR 100pF AC250V K
C2780 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C2781 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C2782 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C2783 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C2784 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C3400 QCBB1HK-331Y C CAPACITOR 330pF 50V K
S3B,
S3E,
S3EE,
S3EN,
S3EV
C3401 QCBB1HK-331Y C CAPACITOR 330pF 50V K
S3B,
S3E,
S3EE,
S3EN,
S3EV
C3402 QCBB1HK-331Y C CAPACITOR 330pF 50V K
S3B,
S3E,
S3EE,
S3EN,
S3EV
C3405 QCBB1HK-331Y C CAPACITOR 330pF 50V K
S3B,
S3E,
S3EE,
S3EN,
S3EV
C3406 QCSB1HJ-470Y C CAPACITOR 47pF 50V J
S3B,
S3E,
S3EE,
S3EN,
S3EV
C3407 QCSB1HJ-470Y C CAPACITOR 47pF 50V J
S3B,
S3E,
S3EE,
S3EN,
S3EV
C3408 QCSB1HJ-470Y C CAPACITOR 47pF 50V J
S3B,
S3E,
S3EE,
S3EN,
S3EV
C3409 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
S3B,
S3E,
S3EE,
S3EN,
S3EV
C3410 QCSB1HJ-470Y C CAPACITOR 47pF 50V J
S3B,
S3E,
S3EE,
S3EN,
S3EV
R953 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R954 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R955 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R956 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R957 QRE141J-271Y C RESISTOR 270
Ω 1/4W J
R958 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R2780 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R2781 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R3400 QRE141J-202Y C RESISTOR 2k
Ω 1/4W J
S3B,
S3E,
S3EE,
S3EN,
S3EV
R3401 QRE141J-202Y C RESISTOR 2k Ω 1/4W J
S3B,
S3E,
S3EE,
S3EN,
S3EV
R3402 QRE141J-821Y C RESISTOR 820 Ω 1/4W J
S3B,
S3E,
S3EE,
S3EN,
S3EV
R3403 QRE141J-123Y C RESISTOR 12k Ω 1/4W J
S3B,
S3E,
S3EE,
S3EN,
S3EV
R3404 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
S3B,
S3E
,S3EE
,S3EN
,S3EV
R3405 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
S3B,
S3E,
S3EE,
S3EN,
S3EV
R3406 QRE141J-393Y C RESISTOR 39k Ω 1/4W J
S3B,
S3E,
S3EE,
S3EN,
S3EV
R3407 QRE141J-151Y C RESISTOR 150 Ω 1/4W J
S3B,
S3E,
S3EE,
S3EN,
S3EV
R3409 QRE141J-151Y C RESISTOR 150
Ω 1/4W J
S3B,
S3E,
S3EE,
S3EN,
S3EV
R3411 QRE141J-393Y C RESISTOR 39k
Ω 1/4W J
S3B,
S3E,
S3EE,
S3EN,
S3EV
R3412 QRE141J-750Y C RESISTOR 75
Ω 1/4W J
S3B,
S3E,
S3EE,
S3EN,
S3EV
R3413 QRE141J-750Y C RESISTOR 75
Ω 1/4W J
S3B,
S3E,
S3EE,
S3EN,
S3EV
 Symbol No. Part No. Part Name Description Local
