DVD loading switch board
Block No. [0][4][0][0]
TH301 NAD0025-103X N THERMISTOR 10k
Ω
X351 NAX0550-001X CRYSTAL 27.000MHz
Symbol No.
Part No. Part Name Description Local
CN1 QGF1016F3-05 CONNECTOR FFC/FPC (1-5)
S1 QSW1007-001 DETECT SWITCH
Symbol No.
Part No. Part Name Description Local
To Next Page
