3.5 Receiver assembly section
3.5.1 Removing the side panel (L) and side panel (R)
(See Fig.1)
(1) From the back side of the receiver assembly, remove two
screws A attaching the side panel (L) and side panel (R).
(2) Take out the side panel (L) and side panel (R) upward.
Fig.1
Side panel (R) Side panel (L)
A
