No. 51921
TM-A101G
10
BLOCK SELECT ADJUSTMENT ITEM
SIGNAL BLOCK
SERVICE ITEM CONTENTS
S01
BRIGHT
S02 CONTRAST
S03 CHROMA(PAL)
S04 CHROMA(NTSC)
S05 CHROMA(SECAM)
S06 PHASE(NTSC)
S07 BRIGHT(16:9)
S08 CONTRAST(16:9)
WHITE BALANCE
SERVICE ITEM CONTENTS
W01 R CUTOFF
W02 G CUTOFF
W03 B CUTOFF
W04 R DRIVE
W05 B DRIVE
CONTROL BLOCK
Ȫ
ȪȪ
Ȫ
These are fixed values. Don’t adjust them.
ȫ
ȫȫ
ȫ
SERVICE Number ITEM SERVICE Number ITEM
C01
MODEL
C29 REMOCON
C02 UPPER C30 S-FIELD
C03
BRIGHT POINT
LOWER C31 SDC ATT
C04 UPPER C32 DEMP F0
C05
CONTRAST POINT
LOWER C33 V. ID. SW
C06 UPPER C34 S. KILL
C07
CHROMA POINT
LOWER C35 BELL. F0
C08 UPPER C36 ABL. GAIN
C09
PHASE POINT
LOWER C37 ABL. POINT
C10 OSD HORIZONTAL POSITION C38 TRAP SW (NTSC)
C11 OSD VERTICAL FREQUENCY (50Hz) C39 TRAP SW (PAL)
C12 OSD VERTICAL FREQUENCY (60Hz) C40 TRAP Q (NTSC)
C13 VERTICAL DELAY (NTSC) C41 TRAP Q (PAL)
C14 VERTICAL DELAY (PAL) C42 TRAP F0(NTSC)
C15
VERTICAL DELAY (SECAM) C43 TRAP F0(PAL)
C16
VERTICAL DELAY (BLACK AND WHITE) C44 TOF SW (NTSC)
C17
S DELAY (NTSC) C45 TOF SW (PAL)
C18
S DELAY (PAL) C46 TOF Q (NTSC)
C19 S DELAY (SECAM) C47 TOF Q (PAL)
C20 S DELAY (BLACK AND WHITE) C48 TOF F0 (NTSC)
C21 BRIGHT (VERTICAL) C49 TOF F0 (PAL)
C22 SHARP (CENTER VALUE) C50 APA (V. NTSC)
C23 V-GUARD C51 APA (V. PAL)
C24 HOUR METER C52 APA (V. SECAM)
C25 AFC MODE C53 APA (Y/C, B/W)
C26 BURST (NTSC / PAL) C54 R-Y BLACK OFFSET
C27 BURST (SECAM) C55 B-Y BLACK OFFSET
C28 COLOUR SYSTEM C56 CONTRAST CONTROL
DEFLECTION BLOCK
SERVICE ITEM CONTENTS
D01 HORIZONTAL POSITION
D02 VERTICAL SIZE
D03 VERTICAL SIDE PIN CORRECTION
D04 VERTICAL CENTER
D05 VERTICAL LINEARITY
In addition to the ones listed above, the following DEFLECTION BLOCK are
also available.
50Hz / 4:3
D01
ϡ
D05
60Hz / 4:3
DA1
ϡ
DA5
50Hz / 16:9
DB1
ϡ
DB5
60Hz / 16:9
DC1
ϡ
DC5
SCREEN DISPLAY
INPUT SIGNAL
V. FREQ / ASPECT
To Next Page
