JVC TM-A130SU - Dimensions and Terminal Specs

14
13-5/8 (346)
11-1/4 (284)
12-1/4 (310)
TM-A130SU
PHASE CHROMA BRIGHT CONTRAST MENU
INPUT SELECT
VOLUME/SELECT
–
+
B A
POWER
ON
OFF
11-3/8 (287)
*
*
8-5/8 (217)
Pin No. Signal
1 GND (Y)
2 GND (C)
3Y
4C
7 Dimensions
< Front View >
< Side View >
* Asterisks (
∗
) are used to indicate front panel
dimensions.
7 Y/C (Mini DIN 4 pin) terminal
specification
Unit : Inch (mm)
3
1
4
2
Y/C IN
14-5/8 (368.5)
14-3/8 (363.5)
1/16 (1.5)
1/4 (5)
3/16 (3.5)
2-5/8
(63.7)
10-3/4 (273)
