JVC TM-A130SU - Technical Specifications

13
SPECIFICATIONS
* Illustrations used in this manual are for explanatory purposes only. The appearance of the actual product may differ slightly.
* Dimensions and weight are approximate.
* E. & O. E. Design and specifications subject to change without notice.
MODEL
Type
Color system
Picture tube
TM-A130SU
VIDEO A
Audio power output
Built-in speaker
Environmental conditions
Input terminals
Color video monitor
NTSC (3.58), PAL
13" measured diagonally,
90° deflection, in-line gun,
vertical line trio type
(phosphor stripe pitch 0.64 mm)
Effective screen size Width 11-1/8" (280.8 mm)
Height 8-3/8" (210.6 mm)
Diagonal 13-1/4" (335.4 mm)
Scanning frequency
H : 15.734 kHz (NTSC), 15.625 kHz (PAL)
V : 59.94 Hz (NTSC), 50 Hz (PAL)
Horizontal resolution
320 TV lines or more (NTSC)
Composite video: 1 line, BNC connector x 2,
1 Vp-p, 75 Ω negative sync
(bridge connection possible, auto termination)
Composite video: 1 line, BNC connector x 2,
1 Vp-p, 75 Ω negative sync
(bridge connection possible, auto termination)
Y/C-separated: 1 line, mini-DIN 4-pin connector x 1
Y: 1.0 Vp-p, 75 Ω
C: 0.286 Vp-p, 75 Ω (NTSC), 0.3 Vp-p, 75 Ω (PAL)
1 line (monaural), RCA pin x 2, 0.5 V rms, high-impedance
(bridge connection possible)
1 line (monaural), RCA pin x 2, 0.5 V rms, high-impedance
(bridge connection possible)
1 W (monaural)
8 cm round x 1, impedance of 8 Ω
Operation temperature: 0 – 40 °C (32 – 104 °F)
Operation humidity: 20 – 80% (non-condensing)
120V AC, 50/ 60 Hz
0.87 A (120 V AC)
26.9 lbs (12.2 kg)
AC power cord [7.87 ft (2.4 m)] x 1
Width 13-5/8" (346 mm)
Height 12-1/4" (310 mm)
Depth 14-5/8" (368.5 mm)
Power requirements
Power consumption
Dimensions
Weight
Accessory
VIDEO B
AUDIO B
AUDIO A
