MODEL MARK MODEL MARK MODEL MARK MODEL MARK
UX-G375A A UX-G375B B UX-G375E C UX-G375EN D
UX-G375EV E UX-G375UP F UX-G375US G UX-G375UT H
UX-G375UW I UX-G377E J UX-G377EN K UX-G377EV L
UX-G377UT M UX-G395BE N UX-G395BEN O UX-G395BEY P
UX-G395WE Q UX-G395WEN R UX-G395WEY S
Safe Symbol No. Parts No. Parts Name Description QTY Local
General assembly <M1MM>
1 CD5001092000200 FRONT CABINET 5001-092000200 1 A,F,G,I
1 CD5001092000100 FRONT CABINET 5001-092000100 1 B,C,D,E,N,O,P
1 CD5001091900300 FRONT CABINET 5001-091900300 1 H,M
1 CD5001091900100 FRONT CABINET 5001-091900100 1 J,K,L
1 CD5001039500100 FRONT CABINET 5001-039500100 1 Q,R,S
2 CD5002081000300 REAR CABINET 5002-081000300 1 A,B,F
2 CD5002081000400 REAR CABINET 5002-081000400 1 C,D,E,N,O,P
2 CD5002081000101 REAR CABINET 5002-081000101 1 G,I
2 CD5002081600101 REAR CABINET 5002-081600101 1 H,M
2 CD5002081600300 REAR CABINET 5002-081600300 1 J,K,L
2 CD5002039500100 REAR CABINET 5002-039500100 1 Q,R,S
3 CD5002081000200 BOTTOM CABINET 5002-081000200 1
A,B,C,D,E,F,G,H,I,J,K,L,M
,N,O,P
3 CD5002039500200 BOTTOM CABINET 5002-039500200 1 Q,R,S
4 CD5201081000100 CD DOOR 5201-081000100 1 A,B,C,D,E,F,G,I,N,O,P
4 CD5201081600100 CD DOOR 5201-081600100 1 H,J,K,L,M
4 CD5201039500100 CD DOOR 5201-039500100 1 Q,R,S
5 CD5401092000100 DEMO BUTTON 5401-092000100 1 A,B,C,D,E,F,G,I,N,O,P
5 CD5401091900100 DEMO BUTTON 5401-091900100 1 H,J,K,L,M
5 CD5401039500100 DEMO BUTTON 5401-039500100 1 Q,R,S
6 CD5307092000100 VOLUME KNOB 5307-092000100 1 A,B,C,D,E,F,G,I
6 CD5307091900100 VOLUME KNOB 5307-091900100 1 H,J,K,L,M
6 CD5307081000100 VOLUME KNOB 5307-081000100 1 N,O,P,Q,R,S
7 CD5403081000200 CONTROL BUTTON 5403-081000200 1 A,B,C,D,E,F,G,I,N,O,P
7 CD5403081600100 CONTROL BUTTON 5403-081600100 1 H,J,K,L,M
7 CD5403039500100 CONTROL BUTTON 5403-039500100 1 Q,R,S
8 CD5408081000100 POWER BUTTON 5408-081000100 1 A,B,C,D,E,F,G,I,N,O,P
8 CD5408081600100 POWER BUTTON 5408-081600100 1 H,J,K,L,M
8 CD5408039500100 POWER BUTTON 5408-039500100 1 Q,R,S
9 CD5413081000100 SOUND BUTTON 5413-081000100 1 A,B,C,D,E,F,G,I,N,O,P
9 CD5413081600100 SOUND BUTTON 5413-081600100 1 H,J,K,L,M
9 CD5416039500300 SOUND BUTTON 5416-039500300 1 Q,R,S
10 CD5403081000100 TUNER BUTTON 5403-081000100 1 A,B,C,D,E,F,G,I,N,O,P
10 CD5416081600100 TUNER BUTTON 5416-081600100 1 H,J,K,L,M
10 CD5416039500100 TUNER BUTTON 5416-039500100 1 Q,R,S
11 CD5404081000100 CD BUTTON 5404-081000100 1 A,B,C,D,E,F,G,I,N,O,P
11 CD5416081600200 CD BUTTON 5416-081600200 1 H,J,K,L,M
11 CD5416039500200 CD BUTTON 5416-039500200 1 Q,R,S
12 CD5416081000100 USB BUTTON 5416-081000100 1 A,B,C,D,E,F,G,I,N,O,P
12 CD5416081600300 USB BUTTON 5416-081600300 1 H,J,K,L,M
12 CD5416039500400 USB BUTTON 5416-039500400 1 Q,R,S
13 CD5424081000100 AUDIO BUTTON 5424-081000100 1 A,B,C,D,E,F,G,I,N,O,P
13 CD5424081600100 AUDIO BUTTON 5424-081600100 1 H,J,K,L,M
13 CD5424039500100 AUDIO BUTTON 5424-039500100 1 Q,R,S
14 CD5501092000100 DISPLAY LENS 5501-092000100 1 A,B,C,D,E,F,G,I
14 CD5501091900100 DISPLAY LENS 5501-091900100 1 H,J,K,L,M
14 CD5501039500100 DISPLAY LENS 5501-039500100 1 N,O,P,Q,R,S
15 CD5607081000200 FRONT PCB BKT 5607-081000200 1 A
15 CD5607081000101 FRONT PCB BKT 5607-081000101 1
B,C,D,E,F,G,H,I,J,K,L,M,
N,O,P,Q,R,S
16 CD5618081000100 POWER BTN BKT 5618-081000100 1
17 CD5624081000200 BACK PCB BKT 5624-081000200 1 A
17 CD5624081000100 BACK PCB BKT 5624-081000100 1
B,C,D,E,F,G,H,I,J,K,L,M,
N,O,P,Q,R,S
18 CD5905081000100 VOLUME RING 5905-081000100 1
19 CD5913081000100 COSMETIC FRAME 5913-081000100 1
20 CD5939081000100 PLASTIC WASHER 5939-081000100 2
21 CD6204081000200 PCB SHIELD TOP 6204-081000200 1
21 or CD6204081000101 PCB SHIELD TOP 6204-081000101 1 N,O,P,Q,R,S
22 CD6211080700200 FIXING PLATE 6211-080700200 3
23 CD6217081000100 GROUND PLATE 6217-081000100 1
24 CD6303081000100 CONNECTOR BKT 6303-081000100 1
24 or CD6303081000200 CONNECTOR BKT 6303-081000200 1 N,O,P,Q,R,S
25 CD6404081100200 SILICON FOOT 6404-081100200 4
26 CD6406081000100 EVA 6406-081000100 1
27 CD6600081000500 HEAT SINK 6600-081000500 1
27 or CD6600081000100 HEAT SINK 6600-081000100 1 N,O,P,Q,R,S
28 CD8024000000100 FIBRE WASHER 8024-000000100 1
29 CD6210081000200 PC CUT SHEET 6210-081000200 1
29 or CD6210081000300 PC CUT SHEET 6210-081000300 1 N,O,P,Q,R,S
30 CD6011226060100 SCREW 6011-226060100 4
31 CD6011226060100 SCREW 6011-226060100 2
32 CD6011226080100 SCREW 6011-226080100 6
33 CD6011226080100 SCREW 6011-226080100 7
34 CD6011226080100 SCREW 6011-226080100 4
35 CD6011226080100 SCREW 6011-226080100 1
37 CD6013230120100 SCREW 6013-230120100 4
38 CD6013217060100 SCREW 6013-217060100 5
39 CD6013230100120 SCREW 6013-230100120 2 A,B,C,D,E,F,G,I,N,O,P
39 CD6013230100200 SCREW 6013-230100200 2 H,J,K,L,M,Q,R,S
40 CD6013230100120 SCREW 6013-230100120 2 A,B,C,D,E,F,G,I,N,O,P
40 CD6013230100200 SCREW 6013-230100200 2 H,J,K,L,M,Q,R,S
(No.MB729<Rev.004>)4/
