JVC UX-G375A

MODEL MARK MODEL MARK MODEL MARK MODEL MARK
UX-G375A A UX-G375B B UX-G375E C UX-G375EN D
UX-G375EV E UX-G375UP F UX-G375US G UX-G375UT H
UX-G375UW I UX-G377E J UX-G377EN K UX-G377EV L
UX-G377UT M UX-G395BE N UX-G395BEN O UX-G395BEY P
UX-G395WE Q UX-G395WEN R UX-G395WEY S
Safe Symbol No. Parts No. Parts Name Description QTY Local
41 CD6013230100120 SCREW 6013-230100120 2
A,B,C,D,E,F,G,I,N,O,P,Q,
R,S
41 CD6013230100200 SCREW 6013-230100200 2 H,J,K,L,M
42 CD6013230100120 SCREW 6013-230100120 1
A,B,C,D,E,F,G,I,N,O,P,Q,
R,S
42 CD6013230100200 SCREW 6013-230100200 1 H,J,K,L,M
43 CD6013230100120 SCREW 6013-230100120 2
A,B,C,D,E,F,G,I,N,O,P,Q,
R,S
43 CD6013230100200 SCREW 6013-230100200 2 H,J,K,L,M
44 CD6013230100120 SCREW 6013-230100120 2
A,B,C,D,E,F,G,I,N,O,P,Q,
R,S
44 CD6013230100200 SCREW 6013-230100200 2 H,J,K,L,M
45 CD6013230100120 SCREW 6013-230100120 2
A,B,C,D,E,F,G,I,N,O,P,Q,
R,S
45 CD6013230100200 SCREW 6013-230100200 2 H,J,K,L,M
46 CD6012226100110 SCREW 6012-226100110 1
47 CD6014230100110 SCREW 6014-230100110 6 A,B,C,D,E,F,G,I,N,O,P
47 CD6014230100200 SCREW 6014-230100200 6 H,J,K,L,M,Q,R,S
48 CD6023230100300 SCREW 6023-230100300 2
49 CD6024230080100 SCREW 6024-230080100 1 A,B,C,D,E,F,G,I,N,O,P
49 CD6024230080200 SCREW 6024-230080200 1 H,J,K,L,M,Q,R,S
50 CD6024230080100 SCREW 6024-230080100 2 A,B,C,D,E,F,G,I,N,O,P
50 CD6024230080200 SCREW 6024-230080200 2 H,J,K,L,M,Q,R,S
51 CD6024230080100 SCREW 6024-230080100 1 A,B,C,D,E,F,G,I,N,O,P
51 CD6024230080200 SCREW 6024-230080200 1 H,J,K,L,M,Q,R,S
52 CD6034226060100 SCREW 6034-226060100 2
53 CD7111092000700 RATING LABEL 7111-092000700 1 A
53 CD7111092000100 RATING LABEL 7111-092000100 1 B,C,D
53 CD7111092000200 RATING LABEL 7111-092000200 1 E
53 CD7111092000500 RATING LABEL 7111-092000500 1 F
53 CD7111092000300 RATING LABEL 7111-092000300 1 G,H
53 CD7111092000900 RATING LABEL 7111-092000900 1 I
53 CD7111091900100 RATING LABEL 7111-091900100 1 J,K
53 CD7111091900200 RATING LABEL 7111-091900200 1 L
53 CD7111091900400 RATING LABEL 7111-091900400 1 M
53 CD7111039500101 RATING LABEL 7111-039500101 1 N,O
53 CD7111039500301 RATING LABEL 7111-039500301 1 P
53 CD7111039500201 RATING LABEL 7111-039500201 1 Q,R
53 CD7111039500401 RATING LABEL 7111-039500401 1 S
54 LV44603-003A LASER CAUTION 7112-081000100 1
! 55 CD2001250250120 FUSE 2001-250250120 1
! 55 or CD2001250250100 FUSE 2001-250250100 1 N,O,P,Q,R,S
56 CD6013230060300 SCREW 6013-230060300 1
57 CD6013230060300 SCREW 6013-230060300 1
58 CD6210081200200 PC CUT SHEET 6210-081200200 1
59 CD2401000000070 VFD 2401-000000070 1
60 CD5601081000100 VFD HOLDER 5601-081000100 1
61 CD5601081000200 LED BKT 5601-081000200 1
! 62 CD2904225007000 POWER CORD 2904-225007000 1 A
! 62 CD2905123007000 POWER CORD 2905-123007000 1 B
! 62 CD2902223007000 POWER CORD 2902-223007000 1
C,D,E,G,H,I,J,K,L,N,O,P,
Q,R,S
! 62 CD2911225007010 POWER CORD 2911-225007010 1 F
! 62 CD2908212507000 POWER CORD 2908-212507000 1 M
! 62 or CD2902225007060 POWER CORD 2902-225007060 1 N,O,P,Q,R,S
63 CD3001000180130 WIRE 3001-000180130 1
64 CD3502050152010 CONNECTOR WIRE 3502-050152010 1
65 CD3502060252000 CONNECTOR WIRE 3502-060252000 1
66 CD3002100120920 FFC WIRE 3002-100120920 1
67 CD3002200090910 FFC WIRE 3002-200090910 1
68 CD3002160150900 FFC WIRE 3002-160150900 1
69 CD3002160140900 FFC WIRE 3002-160140900 1
69 or CD3002160105900 FFC WIRE 3002-160105900 1 A
70 CD3801000000360 TUNER MODULE 3801-000000360 1 A,F,G,H,I,M
70 CD3801000000370 TUNER MODULE 3801-000000370 1 B
70 CD3801000000350 TUNER MODULE 3801-000000350 1 C,D,E,J,K,L,N,O,P,Q,R,S
71 CD4401120001120 CD MECHANISM 4401-120001120 1
72 CD8949050900200 CD MECHANISM
LOADER
8949-050900200 1
73 CD8031000004100 UL PVC TUBE 8031-000004100 1
A,B,C,D,E,F,G,H,I,J,K,L,M
! 74 CD3307020200010 VOLTAGE SELECT SW 3307-020200010 1 G,H,I,M
75 CD3501020083900 CONNECTOR WIRE 3501-020083900 1 G,H,I,M
76 CD6011226080100 SCREW 6011-226080100 2 A,F,G,H,I,M
77 CD7111092000800 UT LABEL 7111-092000800 1 H
77 CD7111091900300 UT LABEL 7111-091900300 1 M
78 CD7128081200100 CLASS 1 LABEL 7128-081200100 1 F,H,M
79 CD6304041500100 FUSE HOLDER 6304-041500100 2
79 or CD6304041500200 FUSE HOLDER 6304-041500200 2 N,O,P,Q,R,S
80 CD2712900090000 FERRITE CORE 2712-900090000 1
81 CD2712104030000 FERRITE CORE 2712-104030000 1
(No.MB729<Rev.004>)5/
24
