MODEL MARK MODEL MARK MODEL MARK MODEL MARK
UX-G375A A UX-G375B B UX-G375E C UX-G375EN D
UX-G375EV E UX-G375UP F UX-G375US G UX-G375UT H
UX-G375UW I UX-G377E J UX-G377EN K UX-G377EV L
UX-G377UT M UX-G395BE N UX-G395BEN O UX-G395BEY P
UX-G395WE Q UX-G395WEN R UX-G395WEY S
Safe Symbol No. Parts No. Parts Name Description QTY Local
82 CD6700081000100 FELT CLOTH 6700-081000100 5
83 CD2712000130000 FERRITE CORE 2712-000130000 2
Electrical parts list MCU board <01>
IC201 1506780515000-C IC 1506-780515000 1
A,B,C,D,E,F,G,H,I,J,K,L,M
IC201 1506780515000-A IC 1506-780515000 1 N,O,P,Q,R,S
IC202 CD1511002402080 IC 1511-002402080 1
A,B,C,D,E,F,G,H,I,J,K,L,M
IC202 CD1511002402000 IC 1511-002402000 1 N,O,P,Q,R,S
IC202 or CD1511002402080 IC 1511-002402080 1 N,O,P,Q,R,S
IC204 CD1502002314010 IC 1502-002314010 1
IC205 CD1502004453000 IC 1502-004453000 1
IC212 CD1502007492010 IC 1502-007492010 1
IC212 or CD1502007492000 IC 1502-007492000 1 N,O,P,Q,R,S
Q1 CD1421085500010 TRANSISTOR 1421-085500010 1
A,B,C,D,E,F,G,H,I,J,K,L,M
Q1 CD1421039060020 TRANSISTOR 1421-039060020 1 N,O,P,Q,R,S
Q201 CD1422080500050 TRANSISTOR 1422-080500050 1
A,B,C,D,E,F,G,H,I,J,K,L,M
Q201 CD1422039040010 TRANSISTOR 1422-039040010 1 N,O,P,Q,R,S
Q202 CD1411085500000 TRANSISTOR 1411-085500000 1
Q202 or CD1411385500000 TRANSISTOR 1411-385500000 1 N,O,P,Q,R,S
Q203 CD1422080500050 TRANSISTOR 1422-080500050 1
A,B,C,D,E,F,G,H,I,J,K,L,M
Q203 CD1422039040010 TRANSISTOR 1422-039040010 1 N,O,P,Q,R,S
Q204 CD1422080500050 TRANSISTOR 1422-080500050 1
A,B,C,D,E,F,G,H,I,J,K,L,M
Q204 CD1422039040010 TRANSISTOR 1422-039040010 1 N,O,P,Q,R,S
Q205 CD1424023010010 MOSFET 1424-023010010 1
A,B,C,D,E,F,G,H,I,J,K,L,M
Q205 CD1424023010040 MOS FET 1424-023010040 1 N,O,P,Q,R,S
Q205 or CD1424023010020 MOS FET 1424-023010020 1 N,O,P,Q,R,S
Q206 CD1422080500050 TRANSISTOR 1422-080500050 1
A,B,C,D,E,F,G,H,I,J,K,L,M
Q206 CD1422039040010 TRANSISTOR 1422-039040010 1 N,O,P,Q,R,S
Q207 CD1412080500000 TRANSISTOR 1412-080500000 1
Q207 or CD1412380500000 TRANSISTOR 1412-380500000 1 N,O,P,Q,R,S
Q212 CD1412080500000 TRANSISTOR 1412-080500000 1
Q212 or CD1412380500000 TRANSISTOR 1412-380500000 1 N,O,P,Q,R,S
Q213 CD1424230180010 MOS FET 1424-230180010 1 A,B,F,G,H,I,M
Q217 CD1422080500050 TRANSISTOR 1422-080500050 1
A,B,C,D,E,F,G,H,I,J,K,L,M
Q217 CD1422039040010 TRANSISTOR 1422-039040010 1 N,O,P,Q,R,S
Q218 CD1422080500050 TRANSISTOR 1422-080500050 1
A,B,C,D,E,F,G,H,I,J,K,L,M
Q218 CD1422039040010 TRANSISTOR 1422-039040010 1 N,O,P,Q,R,S
Q219 CD1422080500050 TRANSISTOR 1422-080500050 1
A,B,C,D,E,F,G,H,I,J,K,L,M
Q219 CD1422039040010 TRANSISTOR 1422-039040010 1 N,O,P,Q,R,S
D1 CD1321041480050 DIODE 1321-041480050 1
D1 or CD1321041480010 SWITCH DIODE 1321-041480010 1 N,O,P,Q,R,S
D2 CD1321041480050 DIODE 1321-041480050 1
D2 or CD1321041480010 SWITCH DIODE 1321-041480010 1 N,O,P,Q,R,S
D3 CD1321041480050 DIODE 1321-041480050 1
D3 or CD1321041480010 SWITCH DIODE 1321-041480010 1 N,O,P,Q,R,S
D6 CD1321041480050 DIODE 1321-041480050 1
D6 or CD1321041480010 SWITCH DIODE 1321-041480010 1 N,O,P,Q,R,S
D7 CD1321041480050 DIODE 1321-041480050 1
D7 or CD1321041480010 SWITCH DIODE 1321-041480010 1 N,O,P,Q,R,S
D201 CD1321041480050 DIODE 1321-041480050 1
D201 or CD1321041480010 SWITCH DIODE 1321-041480010 1 N,O,P,Q,R,S
D202 CD1321041480050 DIODE 1321-041480050 1
D202 or CD1321041480010 SWITCH DIODE 1321-041480010 1 N,O,P,Q,R,S
D203 CD1321041480050 DIODE 1321-041480050 1
D203 or CD1321041480010 SWITCH DIODE 1321-041480010 1 N,O,P,Q,R,S
D206 CD1321041480050 DIODE 1321-041480050 1
D206 or CD1321041480010 SWITCH DIODE 1321-041480010 1 N,O,P,Q,R,S
C1 CD1121103082020 C CAPACITOR 1121-103082020 1
C2 CD1132225083060 E CAPACITOR 1132-225083060 1
C3 CD1121103082020 C CAPACITOR 1121-103082020 1
C5 CD1121102082020 C CAPACITOR 1121-102082020 1 A,B,C,D,E,F,G,H,J,K,L,M
C5 CD1121102082021 C CAPACITOR 1121-102082021 1 I,N,O,P,Q,R,S
C6 CD1121102082020 C CAPACITOR 1121-102082020 1 A,B,C,D,E,F,G,H,J,K,L,M
C6 CD1121102082021 C CAPACITOR 1121-102082021 1 I,N,O,P,Q,R,S
C9 CD1138474091210 M CAPACITOR 1138-474091210 1
C10 CD1121105051020 C CAPACITOR 1121-105051020 1 A,B,C,D,E,F,G,H,J,K,L,M
C10 CD1121105052020 C CAPACITOR 1121-105052020 1 I,N,O,P,Q,R,S
C11 CD1121104082020 C CAPACITOR 1121-104082020 1
C16 CD1121103082020 C CAPACITOR 1121-103082020 1
C17 CD1121103082020 C CAPACITOR 1121-103082020 1
C18 CD1121103082020 C CAPACITOR 1121-103082020 1
C19 CD1121103082020 C CAPACITOR 1121-103082020 1
C20 CD1121224084020 C CAPACITOR 1121-224084020 1
C21 CD1121224084020 C CAPACITOR 1121-224084020 1
C22 CD1121224084020 C CAPACITOR 1121-224084020 1
C23 CD1121224084020 C CAPACITOR 1121-224084020 1
C7B CD1121104082020 C CAPACITOR 1121-104082020 1
C8B CD1121104082020 C CAPACITOR 1121-104082020 1
(No.MB729<Rev.004>)6/
