MODEL MARK MODEL MARK MODEL MARK MODEL MARK
UX-G375A A UX-G375B B UX-G375E C UX-G375EN D
UX-G375EV E UX-G375UP F UX-G375US G UX-G375UT H
UX-G375UW I UX-G377E J UX-G377EN K UX-G377EV L
UX-G377UT M UX-G395BE N UX-G395BEN O UX-G395BEY P
UX-G395WE Q UX-G395WEN R UX-G395WEY S
Safe Symbol No. Parts No. Parts Name Description QTY Local
L212 or CD1604101350020 INDUCTOR 1604-101350020 1 N,O,P,Q,R,S
L213 CD1604101350000 COIL 1604-101350000 1
L213 or CD1604101350020 INDUCTOR 1604-101350020 1 N,O,P,Q,R,S
CN201 CD3106121021000 FFC CONNECTOR 3106-121021000 1
CN202 CD3106101621020 FFC CONNECTOR 3106-101621020 1
CN203 CD3505090252000 CONNECTOR WIRE 3505-090252000 1
CN204 CD3101200821010 HEADER 3101-200821010 1
CN207 CD3106122021000 FFC CONNECTOR 3106-122021000 1
CN208 CD3101200321010 HEADER 3101-200321010 1
CN210 CD3101200721000 HEADER 3101-200721000 1
CN211 CD3505040252500 CONNECTOR WIRE 3505-040252500 1
CN212 CD3401000000310 SP TERMINAL 3401-000000310 1
EC1 CD1132106053060 E CAPACITOR 1132-106053060 1
FB03 CD1221000062030 CHIP RESISTOR 1221-000062030 1
A,B,C,D,E,F,G,H,I,J,K,L,M
FB03 CD1221000052030 CHIP RESISTOR 1221-000052030 1 N,O,P,Q,R,S
FB04 CD1221000062030 CHIP RESISTOR 1221-000062030 1
A,B,C,D,E,F,G,H,I,J,K,L,M
FB04 CD1221000052030 CHIP RESISTOR 1221-000052030 1 N,O,P,Q,R,S
FB07 CD1221000062030 CHIP RESISTOR 1221-000062030 1
A,B,C,D,E,F,G,H,I,J,K,L,M
FB07 CD1221000052030 CHIP RESISTOR 1221-000052030 1 N,O,P,Q,R,S
FB09 CD1221000062030 CHIP RESISTOR 1221-000062030 1
A,B,C,D,E,F,G,H,I,J,K,L,M
FB09 CD1221000052030 CHIP RESISTOR 1221-000052030 1 N,O,P,Q,R,S
FB10 CD1221000062030 CHIP RESISTOR 1221-000062030 1
A,B,C,D,E,F,G,H,I,J,K,L,M
FB10 CD1221000052030 CHIP RESISTOR 1221-000052030 1 N,O,P,Q,R,S
X203 CD1001000327130 CRYSTAL 1001-000327130 1
Z201 CD1313055510000 Z DIODE 1313-055510000 1
Z201 or CD1313000510000 Z DIODE 1313-000510000 1 N,O,P,Q,R,S
Z214 CD1313055910000 Z DIODE 1313-055910000 1
Z214 or CD1313000910010 Z DIODE 1313-000910010 1 N,O,P,Q,R,S
Z215 CD1313055330010 Z DIODE 1313-055330010 1
Z215 or CD1313055330000 Z DIODE 1313-055330000 1 N,O,P,Q,R,S
Z216 CD1313055330010 Z DIODE 1313-055330010 1
Z216 or CD1313055330000 Z DIODE 1313-055330000 1 N,O,P,Q,R,S
Z218 CD1313055560020 Z DIODE 1313-055560020 1
Z218 or CD1313079560020 Z DIODE 1313-079560020 1 N,O,P,Q,R,S
ZD1 CD1323001110000 Z DIODE 1323-001110000 1
A,B,C,D,E,F,G,H,I,J,K,L,M
ZD1 CD1313001000010 Z DIODE 1313-001000010 1 N,O,P,Q,R,S
SMPS board <02>
U1 CD1512001216020 IC 1512-001216020 1
U2 CD1415008170000 PHOTO COUPLER 1415-008170000 1
U3 CD1512000431020 IC 1512-000431020 1
U6 CD1512000431020 IC 1512-000431020 1
D1 CD1311002070020 DIODE 1311-002070020 1
D1 or CD1311002070010 DIODE 1311-002070010 1 N,O,P,Q,R,S
D2 CD1311002070020 DIODE 1311-002070020 1
D2 or CD1311002070010 DIODE 1311-002070010 1 N,O,P,Q,R,S
D3 CD1311002070020 DIODE 1311-002070020 1
D3 or CD1311002070010 DIODE 1311-002070010 1 N,O,P,Q,R,S
D4 CD1311002070020 DIODE 1311-002070020 1
D4 or CD1311002070010 DIODE 1311-002070010 1 N,O,P,Q,R,S
D5 CD1311140070020 DIODE 1311-140070020 1
D5 or CD1311140070000 DIODE 1311-140070000 1 N,O,P,Q,R,S
D6 CD1311001070050 DIODE 1311-001070050 1
D6 or CD1311001070020 DIODE 1311-001070020 1 N,O,P,Q,R,S
D7 CD1321041480050 DIODE 1321-041480050 1
D7 or CD1321041480020 DIODE 1321-041480020 1 N,O,P,Q,R,S
D8 CD1311140070020 DIODE 1311-140070020 1 A,F
D8 CD1311001040030 DIODE 1311-001040030 1
B,C,D,E,G,H,I,J,K,L,M,N,
O,P,Q,R,S
D8 or CD1311001040010 DIODE 1311-001040010 1 N,O,P,Q,R,S
D9 CD1311008200000 DIODE RECTIFIER 1311-008200000 1
D10 CD1311001040030 DIODE 1311-001040030 1
D10 or CD1311001040010 DIODE 1311-001040010 1 N,O,P,Q,R,S
D11 CD1312005600000 SCHOTTKY DIODE 1312-005600000 1
A,B,D,E,G,H,I,J,K,L,N,O,P
,Q,R,S
D11 CD1312158220010 BARRIER DIODE 1312-158220010 1 C,F,M
D12 CD1311001040030 DIODE 1311-001040030 1
D12 or CD1311001040010 DIODE 1311-001040010 1 N,O,P,Q,R,S
D13 CD1312158190000 DIODE 1312-158190000 1
D14 CD1311001040030 DIODE 1311-001040030 1
D14 or CD1311001040010 DIODE 1311-001040010 1 N,O,P,Q,R,S
D15 CD1321041480050 DIODE 1321-041480050 1
D15 or CD1321041480020 DIODE 1321-041480020 1 N,O,P,Q,R,S
D16 CD1312005600000 SCHOTTKY DIODE 1312-005600000 1
A,B,D,E,G,H,I,J,K,L,N,O,P
,Q,R,S
D16 CD1312158220010 BARRIER DIODE 1312-158220010 1 C,F,M
D17 CD1313055430000 Z DIODE 1313-055430000 1
D18 CD1311141480010 DIODE 1311-141480010 1
A,B,C,D,E,F,G,H,I,J,K,L,M
D18 CD1311141480011 DIODE 1311-141480011 1 N,O,P,Q,R,S
(No.MB729<Rev.004>)12/
